Operating instructions

KWD2330X

Refrigerator

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and checked

under the most meticulous quality control procedures, will provide you with effective

service.

For this, we recommend you to carefully read the entire manual of your product before

using it and keep it at hand for future references.

The user manual will help you use the product in a fast and safe way.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful

usage tips.

AWarning against dangerous

conditions for life and property.

BWarning against electric

voltage.

Packaging materials of the prod-

uct are manufactured from recy-

clable materials in accordance

with our National Environment

Regulations.

2 / 34 EN Refrigerator / User Manual

1 Your refrigerator 3

2 Warnings 4

3 Installation 9

3.1. Appropriate installation location . 9

3.2. Installing the plastic wedges . . . 9

3.3. Electrical connection . . . . . . . . 10

3.4. Adjusting the feet. . . . . . . . . . . 10

3.5. Illumination lamp . . . . . . . . . . . 10

3.6. Door open warning . . . . . . . . . 11

3.7. Water connection . . . . . . . . . . 11

3.8. Connecting the water hose to the

refrigerator . . . . . . . . . . . . . . . . 11

3.9. Connecting of the water hose to the

cold water mains line . . . . . . . 12

3.10.Water filter. . . . . . . . . . . . . . . . 13

3.11. Mounting the external filter onto the

wall . . . . . . . . . . . . . . . . . . . . . 13

3.12.Activating water filter change

warning . . . . . . . . . . . . . . . . . . 14

3.13. Before starting to use the water/ice

dispenser. . . . . . . . . . . . . . . . . 14

3.14Transportation of the product. . 15

4 Preparation 16

4.1. Things to be done for energy

saving . . . . . . . . . . . . . . . . . . . 16

4.2. Efficient operation . . . . . . . . . . 16

4.3. Recommendations on the fridge

compartment. . . . . . . . . . . . . . 16

4.4. Initial use . . . . . . . . . . . . . . . . . 16

5 Operating the product 18

5.1. Indicator panel. . . . . . . . . . . . . 18

5.2. NeoFrost Cooling System . . . . 20

5.3. Freezing fresh food . . . . . . . . . 20

5.4. Recommendations for preserving the

frozen food . . . . . . . . . . . . . . . 21

5.5. Placing the food. . . . . . . . . . . . 21

5.6. Deep-freeze information. . . . . . 21

5.7. Chiller compartment . . . . . . . . 22

5.8. Butter & cheese section . . . . . 22

5.9. Egg section . . . . . . . . . . . . . . . 22

5.10.Crisper . . . . . . . . . . . . . . . . . . 22

5.11.Odour filter . . . . . . . . . . . . . . . 22

5.12.Using the dispenser . . . . . . . . 23

5.13.Filling the water dispenser’s tank24

5.14.Filling the water dispenser’s tank25

5.15.Drip tray . . . . . . . . . . . . . . . . . 25

5.16.Icematic and ice storage

container . . . . . . . . . . . . . . . . . 26

5.17.Ice-maker . . . . . . . . . . . . . . . . 26

6 Maintenance and cleaning 28

6.1 Avoiding bad odours . . . . . . . . 28

6.2 Protecting the plastic surfaces 28

6.3 Cleaning of Glass Water Tank . 29

7 Troubleshooting 30

8 How To Obtain Service 33

9 Guarantee Details 34

3 / 34 EN

Refrigerator / User Manual

1 Your refrigerator

C*Optional: Figures in this user manual are schematic and may not match the

product exactly. If the relevant parts are not available in the product you purchased,

it applies to other models.

3*4

5*6

*15

*16

*17

1212

1- Freezer compartment

2- Fridge compartment

3- Fan

4- Butter-cheese compartments

5- Glass shelves

6- Fridge compartment door racks and

egg compartment

7- Minibar accessory

8- Water dispenser tank

9- Odour filter

10- Chiller compartment

11- Crisper compartment

12- Adjustable feet

13- Frozen food storage compartments

14- Freezer compartment door racks

15- Ice makers

16- Ice storage compartment

17- Ice maker decorative cover

Congratulations on your choice of a BLOMBERG quality Appliance which has been

designed to give you service for many years.

4 / 34 EN Refrigerator / User Manual

2 Warnings

• DO NOT connect your

appliance to the electricity

supply until all packing

and transit protectors

have been removed.

• Leave to stand for at least

4 hours before switching

on to allow compressor

oil to settle if transported

horizontally.

• If you are discarding an

old refrigerator with a lock

or latch fitted to the door,

disable the lock/latch,

ensure that it is left in a

safe condition to prevent

the entrapment of young

children.

• This appliance must only

be used for its intended

purpose i.e the storing of

edible foodstuff.

• Do not dispose of the

appliance on a fire.

At BLOMBERG, the

care and protection of

our environment is an

ongoing commitment.

This appliance which is

among the latest range

introduced is particularly

environment friendly.

Your appliance contains

non CFC / HFC natural

substances in the cooling

system (Called R600a) and

in the insulation (Called

cyclopentane) which are

potentially flammable if

exposed to fire. Therefore,

take care not to damage,

the cooling circuit /

pipes of the appliance in

transportation and in use.

In case of damage do not

expose the appliance to

fire or potential ignition

source and immediately

ventilate the room where

the appliance is situated.

• We suggest you contact

your local authority for

disposal information and

facilities available.

• To obtain the best possible

performance and trouble

free operation from

your appliance it is very

important to carefully read

these instructions.

• On delivery, check to make

sure that the product is

not damaged and that all

the parts and accessories

are in perfect condition.

• Ensure that the plug

remains readily accessible.

Do not use multiple

adapter or extension

cable.

5 / 34 EN

Refrigerator / User Manual

Important instructions for safety and environment

2 Warnings

• Failure to observe these

instructions may invalidate

your right to free service

during the guarantee

period.

• Keep ventilation openings,

in the appliance enclosure

or in the built-in structure,

clear of obstruction.

• Do not use mechanical

devices or other means to

accelerate the defrosting

process, other than those

recommended by the

manufacturer.

• Do not damage the

refrigerant circuit.

• Do not use electrical

appliances inside the food

storage compartments

of the appliance, unless

they are of the type

recommended by the

manufacturer.

• We suggest you keep

these instructions in a safe

place for easy reference.

• This appliance can be

used by children aged

from 8 years and above

and persons with reduced

physical, sensory or

mental capabilities or

lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the appliance in a safe

way and understand the

hazards involved.

• Children should be

supervised to ensure that

they do not play with the

appliance.

Electrical Requirements

Before you insert the plug

into the wall socket make

sure that the voltage and

the frequency shown on

the rating plate inside the

appliance corresponds to

your electricity supply.

Rating label is on the left

hand side of inner liner.

We recommend that this

appliance be connected to

the mains supply via a

suitable switched and

fused socket. The appliance

must be positioned so that

the plug is accessible.

Should the mains lead

of the appliance become

damaged or should it need

replacing at any time, it must

be replaced by a special

purpose made mains lead

which can only be obtained

from a BLOMBERG

Authorised Service Agent.

6 / 34 EN Refrigerator / User Manual

Important instructions for safety and environment

Warning! This Appliance Must

Be Earthed

If the fitted moulded plug is

not suitable for your socket,

then the plug should be cut

off and an appropriate plug

fitted. Destroy the old plug

which is cut off as a plug

with bared cord could cause

a shock hazard if inserted

into a socket elsewhere in

the house.

The moulded plug on this

appliance incorporates

a 13 A fuse. Should the

fuse need to be replaced

an ASTABEAB approved

BS 1362 fuse of the same

rating must be used. Do not

forget to refit the fuse cover.

In the event of losing the

fuse cover the plug must not

be used until a replacement

fuse cover has been fitted.

Colour of the replacement

fuse cover must be the same

colour as that visible on the

pin face of the plug. Fuse

covers are available from

any good electrical store.

Important! Fitting A Different

Plug

As the colours of the

wires in the mains lead

of this appliance may

not correspond with

the coloured markings

identifying the terminals

in your plug proceed as

follows: (See diagram).

1. Connect the green-

yellow or green (Earth)

wire to the terminal in the

plug marked ‘E’ or with

the symbol or coloured

green and yellow or green.

2. Connect the blue

(Neutral) wire to the

terminal in the plug

marked ‘N’ or coloured

black.

3. Connect the brown

(Live) wire to the terminal

in the plug marked ‘L’ or

coloured red.

7 / 34 EN

Refrigerator / User Manual

Important instructions for safety and environment

4. With alternative plugs

a 13 A fuse must be

fitted either in the plug

or adaptor or in the

main fuse box. If in

doubt contact a qualified

electrician.

and ensure they are

closed properly after each

opening.

4. Defrost frozen food in the

fridge, so that frozen food

acts as an ice pack to

assist cooling in fridge.

Compliance with WEEE

Directive and Disposing of the

Waste Product:

Thisproduct complies

with EU WEEE

Directive (2012/19/

EU). This product

bearsaclassification

symbol for waste electrical

and electronic equipment

(WEEE).This product has

been manufactured with

high quality parts and

materials which can be

reused and are suitable for

recycling. Do not dispose of

the waste product with

normal domestic and other

wastes at the end of its

service life. Take it to the

collection center for the

recycling of electrical and

electronic equipment. Please

consult your local authorities

to learn about these

collection centers.

FITTED WITH

BS 1362 13A FUSE ALWAYS

FIT BS 1362 REPLACEMENT

CARTRIDGE FUSE

GREEN &

YELLOW

GREEN

BLUE

BLACK

BROWN

RED

22mm.

6mm.

6mm. 32mm.

12mm.

FUSE

CORD GRIP

Energy Saving Tips

1. Ensure your appliance

is installed in a well

ventilated area.

2. Ensure the time between

buying chilled/frozen

food and placing them in

your appliance is kept at

minimum, particularly in

summer. We recommend

you use a cool bag or a

special carrier bag to carry

perishable food.

3. Do not leave the door

(s) of your appliance open

longer than necessary

8 / 34 EN Refrigerator / User Manual

Important instructions for safety and environment

Compliance with RoHS

Directive:

The product you have

purchased complies with EU

RoHS Directive (2011/65/

EU). It does not contain

harmful and prohibited

materials specified in the

Directive.

Package information

Packaging materials of the

product are manufactured

from recyclable materials

in accordance with our

National Environment

Regulations. Do not dispose

of the packaging materials

together with the domestic

or other wastes. Take them

to the packaging material

collection points designated

by the local authorities.

9 / 34 EN

Refrigerator / User Manual

3 Installation

Always have the repair procedures carried

out by the Authorised Service Agent.

Manufacturer shall not be held liable for

damages that may arise from procedures

carried out by unauthorised persons.

To make the product ready for use, make

sure that the electricity installation is

appropriate before calling the Authorised

Service Agent. If not, call a qualified

electrician to have any necessary

arrangements carried out.

Preparation of the location and

electrical installation at the place

of installation is under customer's

responsibility.

Product must not be plugged

in during installation. Otherwise,

there is the risk of death or

serious injury!

WARNING:Manufacturer shall

not be held liable for damages

that may arise from procedures

carried out by unauthorised

persons.

WARNING: Prior to installation,

visually check if the product

has any defects on it. If so, do

not have it installed. Damaged

products cause risks for your

safety.

Make sure that the power cable

is not pinched or crushed while

pushing the product into its

place after installation or cleaning

procedures.

3.1. Appropriate

installation location

WARNING: If the door of the

room where the product will be

placed is too small for the product

to pass, then the product's doors

can be removed and the product

turned aside to pass it through.

• Choose a place at where you would

use the product comfortably.

• Install the product at least 30 cm away

from heat sources such as hobs, ovens,

heater cores and stoves. Product must

not be subjected to direct sun light and

kept in humid places after installation.

• Appropriate air ventilation must be

provided around your product in order

to achieve an efficient operation. If the

product is to be placed in a recess in

the wall, pay attention to leave at least

5 cm distance with the ceiling and side

walls.

• Do not place the product on the

materials such as rugs or carpets.

• Place the product on an even floor

surface to prevent jolts.

• Do not install the product in places

where the temperature falls below -5°C.

If two coolers are to be installed

side by side, there should be at

least 4 cm distance between them.

3.2. Installing the

plastic wedges

Plastic wedges are used to create the

distance for the air circulation between

the product and the rear wall. Insert the

2 plastic wedges onto the rear ventilation

cover as illustrated in the figure. To install

the wedges, remove the screws on the

product and use the screws given in the

same pouch with the wedges.

Inhaltsverzeichnis

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg KQD 1253 XN Bedienungsanleitung

Blomberg

Blomberg SSM 1350 iF Bedienungsanleitung

Blomberg

Blomberg BRFB21612 Series Bedienungsanleitung

Blomberg

Blomberg DSM 1650 Bedienungsanleitung

Blomberg

Blomberg KQD 1620 GB Bedienungsanleitung

Blomberg

Blomberg FRM1970A++ Bedienungsanleitung

Blomberg

Blomberg KQD 1360X Bedienungsanleitung

Blomberg

Blomberg KND9753XN Bedienungsanleitung

Blomberg

Blomberg KNE4564EVI Bedienungsanleitung

Blomberg

Blomberg BRFB 0900 Bedienungsanleitung

Blomberg

Blomberg SSM1351I Bedienungsanleitung

Blomberg

Blomberg BRFB1 22SS Series Bedienungsanleitung

Blomberg

Blomberg KND9921 X Bedienungsanleitung

Blomberg

Blomberg SSM4450 Bedienungsanleitung

Blomberg

Blomberg DNE 1870 Bedienungsanleitung

Blomberg

Blomberg KFD 9950 XA+ Bedienungsanleitung

Blomberg

Blomberg BRFB 1450 SS Bedienungsanleitung

Blomberg

Blomberg KWD 9440 X A+ Bedienungsanleitung

Blomberg

Blomberg DSM 1510 Stücklistenhandbuch

Blomberg

Blomberg BRFB 1452SSN Bedienungsanleitung

Blomberg

Blomberg KND 9950 XDA+ Bedienungsanleitung

Blomberg

Blomberg KND 9651 A Plus Bedienungsanleitung

Blomberg

Blomberg SSM 1450 IN Bedienungsanleitung

Blomberg

Blomberg KKD 1650 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
