SSM1351I

Refrigerator

User Manual

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in a 1st-class

manufacturing facility and checked under the most meticulous quality control

procedures, will provide you with years of good service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future reference.

This manual

• Will help you use your appliance quickly and safely.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

1 Your refrigerator 4

2 Warning 5

Electrical Requirements .....................7

Warning! This Appliance Must Be

Earthed .............................................7

Energy Saving Tips............................8

Compliance with WEEE Directive and

Disposing of the Waste Product: .......9

Compliance with RoHS Directive: ......9

Package information..........................9

3 Installation 10

Installation Instructions ....................10

Changing the illumination lamp .......12

4 Before operating 18

Starting............................................18

5 Using your refrigerator 19

Led Indicators And Control Panel ....19

Temperature Setting ........................20

Defrost ............................................20

6 Maintenance and cleaning 21

7 Troubleshooting 22

8 Guarantee Details 25

C Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1Your refrigerator

Congratulations on your choice of a BLOMBERG quality Appliance which has

been designed to give you service for many years.

1.Interior light

2.Movable shelves

3.Defrost water collection channel - Drain

tube

4.Crisper cover

5.Chiller compartment

6.Crisper

7.Adjustable front feet

8.Dairy compartment

9.Egg compartment

10.Adjustable door shelves

11.Shelf Divider

12.Bottle shelf

11*

*May not be available in all models

2Warning

• DO NOT connect

your appliance to the

electricity supply until

all packing and transit

protectors have been

removed.

• Leave to stand for at

least 4 hours before

switching on to allow

compressor oil to settle if

transported horizontally.

• If you are discarding an

old refrigerator with a

lock or latch fitted to the

door, disable the lock/

latch, ensure that it is

left in a safe condition to

prevent the entrapment

of young children.

• This appliance must only

be used for its intended

purpose i.e the storing of

edible foodstuff.

• Do not dispose of the

appliance on a fire.

At BLOMBERG, the

care and protection of

our environment is an

ongoing commitment.

This appliance which

is among the latest

range introduced is

particularly environment

friendly. Your appliance

contains non CFC /

HFC natural substances

in the cooling system

(Called R600a) and in

the insulation (Called

cyclopentane) which are

potentially flammable

if exposed to fire.

Therefore, take care

not to damage, the

cooling circuit / pipes

of the appliance in

transportation and in

use. In case of damage

do not expose the

appliance to fire or

potential ignition source

and immediately ventilate

the room where the

appliance is situated.

• We suggest you contact

your local authority for

disposal information and

facilities available.

• To obtain the best

possible performance

and trouble free

operation from your

appliance it is very

important to carefully

read these instructions.

• On delivery, check to

make sure that the

product is not damaged

and that all the parts

and accessories are in

perfect condition.

• Ensure that the

plug remains readily

accessible. Do not use

multiple adapter or

extension cable.

• Failure to observe these

ins

• sure or in the built-

in structure, clear of

obstruction.

• Do not use mechanical

devices or other means

to accelerate the

defrosting process,

other than those

recommended by the

manufacturer.

• Do not damage the

refrigerant circuit.

• Do not use electrical

appliances inside

the food storage

compartments of the

appliance, unless

they are of the type

recommended by the

manufacturer.

• We suggest you keep

these instructions in

a safe place for easy

reference.

• This appliance can

be used by children

aged from 8 years and

above and persons

with reduced physical,

sensory or mental

capabilities or lack

of experience and

knowledge if they have

been given supervision

or instruction concerning

use of the appliance

in a safe way and

understand the hazards

involved.

• Children should be

supervised to ensure

that they do not play with

the appliance.

Electrical Require-

ments

Before you insert the

plug into the wall socket

make sure that the volt-

age and the frequency

shown on the rating plate

inside the appliance cor-

responds to your electric-

ity supply.

Rating label is on the left

hand side of inner liner.

We recommend that this

appliance be connected

to the mains supply via a

suitable switched and

fused socket. The appli-

ance must be positioned

so that the plug is acces-

sible.

Should the mains lead

of the appliance become

damaged or should it

need

replacing at any time, it

must be replaced by a

special purpose made

mains lead which can

only be obtained from a

BLOMBERG Authorised

Service Agent.

Warning! This Appli-

ance Must Be Earthed

If the fitted moulded plug

is not suitable for your

socket, then the plug

should be cut off and

an appropriate plug fit-

ted. Destroy the old plug

which is cut off as a plug

with bared cord could

cause a shock hazard

if inserted into a socket

elsewhere in the house.

The moulded plug on

this appliance incorpo-

rates a 13 A fuse. Should

the fuse need to be re-

placed an ASTABEAB

approved BS 1362 fuse

of the same rating must

be used. Do not forget to

refit the fuse cover. In the

event of losing the fuse

cover the plug must not

be used until a replace-

ment fuse cover has

been fitted. Colour of the

replacement fuse cover

must be the same colour

as that visible on the pin

face of the plug. Fuse

covers are available from

any good electrical store.

FITTED WITH

BS 1362 13A FUSE ALWAYS

FIT BS 1362 REPLACEMENT

CARTRIDGE FUSE

GREEN &

YELLOW

GREEN

BLUE

BLACK

BROWN

RED

22mm.

6mm.

6mm. 32mm.

12mm.

FUSE

CORD GRIP

Important! Fitting A

Different Plug

As the colours of the

wires in the mains lead

of this appliance may not

correspond with the co-

loured markings identify-

ing the terminals in your

plug proceed as follows:

(See diagram).

1. Connect the

green-yellow or green

(Earth) wire to the

terminal in the plug

marked ‘E’ or with the

symbol or coloured

green and yellow or

green.

2. Connect the

blue (Neutral) wire to

the terminal in the plug

marked ‘N’ or coloured

black.

3. Connect the

brown (Live) wire to

the terminal in the plug

marked ‘L’ or coloured

red.

4. With alternative

plugs a 13 A fuse must

be fitted either in the

plug or adaptor or in

the main fuse box. If in

doubt contact a qualified

electrician.

Energy Saving Tips

1. Ensure your

appliance is installed in a

well ventilated area.

2. Ensure the time

between buying chilled/

frozen food and placing

them in your appliance

is kept at minimum,

particularly in summer.

We recommend you use

a cool bag or a special

carrier bag to carry

perishable food.

3. Do not leave the

door (s) of your appliance

open longer than

necessary and ensure

they are closed properly

after each opening.

4.Defrost frozen food in

the fridge, so that frozen

food acts as an ice pack

to assist cooling in fridge.

Compliance with

WEEE Directive and

Disposing of the Waste

Product:

Thisproduct

complies with EU

WEEE Directive

(2012/19/EU).

This product

bears a classification

symbol for waste

electrical and electronic

equipment (WEEE).This

product has been

manufactured with high

quality parts and

materials which can be

reused and are suitable

for recycling. Do not

dispose of the waste

product with normal

domestic and other

wastes at the end of its

service life. Take it to the

collection center for the

recycling of electrical and

electronic equipment.

Please consult your local

authorities to learn about

these collection centers.

Compliance with RoHS

Directive:

The product you have

purchased complies

with EU RoHS Directive

(2011/65/EU). It does

not contain harmful and

prohibited materials

specified in the Directive.

Package information

Packaging materials

of the product are

manufactured from

recyclable materials in

accordance with our

National Environment

Regulations. Do not

dispose of the packaging

materials together with

the domestic or other

wastes. Take them to

the packaging material

collection points

designated by the local

authorities.

Installation Instructions

1. The space in the room where

the appliance is installed must not be

smaller than 10 cubic metres.

2. If possible avoid placing the

appliance near cookers, radiators or

in direct sunlight as this will cause the

compressor to run for long periods.

If installed next to a source of heat

or refrigerator, maintain the following

minimum side clearances:

From Cookers 2” (50 mm)

From Radiators 12” (300 mm)

From Refrigerators or Freezers 1”(25

mm)

3. Make sure that sufficient room

is provided around the appliance to

ensure free air circulation.

4. The appliance should be

located on a smooth surface.

The two front feet can be adjusted as

required.

To ensure that,your appliance is stan-

ding upright adjust the two front feet by

turning clockwise or anti-clockwise, un-

til the product is in firm contact with the

floor. Correct adjustment of feet avoids

excessive vibration and noise.

5. Refer to “Cleaning and Care”

section to prepare your appliance for

use.

6. A special receptacle is supplied

to store the mains plug during transit.

The receptacle is fixed at the back of

the cabinet, on the right hand side of

the compressor. (See diagram) Gently

remove the plug from the receptacle.

Never pull the mains cord, you may

damage the appliance. In the case

of transportation, ensure you locate

the plug in the receptacle provided to

avoid transit damage. transit provided

to avoid transit damage.

3Installation

Andere Handbücher für SSM1351I

Inhaltsverzeichnis

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg KND 9860 XA+ Bedienungsanleitung

Blomberg

Blomberg WKWD 1500X-1 Bedienungsanleitung

Blomberg

Blomberg KGM 1860 Bedienungsanleitung

Blomberg

Blomberg BRFB21612 Series Bedienungsanleitung

Blomberg

Blomberg KFD 9950 X Bedienungsanleitung

Blomberg

Blomberg KGM 9680 Bedienungsanleitung

Blomberg

Blomberg SSM 9450 X A+ Bedienungsanleitung

Blomberg

Blomberg FNM1541I Bedienungsanleitung

Blomberg

Blomberg FNT 9683 N Bedienungsanleitung

Blomberg

Blomberg KND 9653 A++ Bedienungsanleitung

Blomberg

Blomberg KND464VW Bedienungsanleitung

Blomberg

Blomberg KNE4564EVI Bedienungsanleitung

Blomberg

Blomberg BSBS2230SS Bedienungsanleitung

Blomberg

Blomberg KKD 1650 Bedienungsanleitung

Blomberg

Blomberg FRM1940A+ Bedienungsanleitung

Blomberg

Blomberg KQD 1253 XN-KQD1254XN Bedienungsanleitung

Blomberg

Blomberg KND9921 X Bedienungsanleitung

Blomberg

Blomberg BRFB 1452SSN Bedienungsanleitung

Blomberg

Blomberg IWD 1004 ET Bedienungsanleitung

Blomberg

Blomberg BRFB 1042 WH Bedienungsanleitung

Blomberg

Blomberg DNE 9887 X A+ Bedienungsanleitung

Blomberg

Blomberg KFI 1290 Bedienungsanleitung

Blomberg

Blomberg KNM 1551 i A+ Bedienungsanleitung

Blomberg

Blomberg DNE9840A+ Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
