BlueEyes ICam PRO Bedienungsanleitung

Operation Manual

VER V1.0.20-10-B853

2015/10/13

BlueEyes Technology

www.BlueEyes.tw

BlueEyes iCam PRO Full HD Camera

Thank you for using the product of BlueEyes Technology.

The manual will introduce the product of BlueEyes Technology. Please read the manual

before you start using the product.

Though the information in the manual has been verified before publish, the actu al

specification should be based on the actual shipment. BlueEyes Technology doesn’t

have to guarantee, proclaim or declare for the content, along with other purpose. In

addition, the product specification and information that mentioned in the manual is fo r

reference only. The content might be update at any time without notice. If there is any

mistake of the information, including software, firmware, and hardware that mentioned

in the manual BlueEyes Technology has no responsibility for the mistake.

Please reach BlueEyes website to get the upgrade of the product specification, our

company will not notice you. If you want to get the latest product information, operation

manual, firmware, or you have any question to the products of BlueEyes Technology,

please contact your local agent or go to the official website of BlueEyes Technology for

further information.

It is not allowed to copy/ use the content or to change the information and publishing of

the manual without BlueEyes Technology’s written consent.

BlueEyes Technology Corp.

Add: 7F-3, No.200, Sec. 4, Wenxin Rd., North District, Taichung City 40462, Taiwan

TEL: +886 4 2297 0977 / +886 982 842 977

Fax: +886 4 2297 0957

E-mail：support@blueeyes.com.tw

Website: www.BlueEyes.tw

BlueEyes Technology

www.BlueEyes.tw

Index

Operation manual..............................................................................................................................................1

1. Summary...........................................................................................................................................................4

1.1 Introduction..................................................................................................................................................4

1.2 Features ........................................................................................................................................................4

1.3 Composition..................................................................................................................................................5

2. Safety and Precautions................................................................................................................................6

3. Device Description ........................................................................................................................................7

3.1 Back Panel.....................................................................................................................................................7

3.2 Fixed iCam PRO Camera ...............................................................................................................................8

3.3 Scanning iCam PRO Camera .........................................................................................................................8

3.4 Live Video......................................................................................................................................................9

4. Location of Camera.....................................................................................................................................10

4.1 Location of Camera.....................................................................................................................................10

5. Adjusting Lenses..........................................................................................................................................12

5.1 Lens of iCam PRO........................................................................................................................................12

5.2 IRIS (O←→C) ..............................................................................................................................................12

5.3 Advices for Classroom Lighting Improvement............................................................................................13

5.4 Zoom (W←→T) ..........................................................................................................................................13

5.5 Focus (∞←→N) .........................................................................................................................................14

5.6 Introduction of Utensil ...............................................................................................................................15

6. Cleaning and Maintaining the Lens......................................................................................................15

7. Setting..............................................................................................................................................................17

7.1 Video Setting...............................................................................................................................................17

7.2 Camera Setting ...........................................................................................................................................18

7.3 Privacy Mask Setting...................................................................................................................................21

7.4 Audio Setting ..............................................................................................................................................24

7.5 Network Setting..........................................................................................................................................25

7.6 Network Protocol .......................................................................................................................................26

8. Watermark......................................................................................................................................................27

8.1 Trademark of Education Institute...............................................................................................................27

8.2 Making Trademark Picture .........................................................................................................................27

8.3 Upload Watermark .....................................................................................................................................27

8.4 Notices ........................................................................................................................................................29

BlueEyes Technology

www.BlueEyes.tw

9. QRcode ............................................................................................................................................................30

9.1 About QRcode.............................................................................................................................................30

9.2 Make QRcode .............................................................................................................................................30

9.3 Upload QRcode...........................................................................................................................................32

9.4 Notices ........................................................................................................................................................34

10. Motion Detection of iFollow .................................................................................................................35

10.1 Enable and Set the Motion Detection ......................................................................................................35

10.2 Notices......................................................................................................................................................37

11. Q&A................................................................................................................................................................38

【Question 1】Can the camera be on for 24 hours? ......................................................................................38

【Question 2】How to adjust if the image is blurred?....................................................................................38

【Question 3】Why the words on the board trembling? ...............................................................................38

【Question 4】How to clean the lens?............................................................................................................38

【Question 5】How long does it take to start up the camera? ......................................................................38

【Question 6】Ripple shows when using projector or digital board ..............................................................38

【Question 7】The video file cut into one or several pieces ..........................................................................39

【Question 8】How to restore to default? .....................................................................................................39

【Question 9】How to reduce background noise ...........................................................................................40

BlueEyes Technology

www.BlueEyes.tw

Most of the recording systems use traditional security camera, so the quality

was very bad. The students have to look closely to see the words on the

blackboard. This kind of camera is not suitable for education institute

environment.

BlueEyes Technology develops the Full HD Camera especially for the

education institute environment and registers the trademark as iCam® . Now

we have iCam PRO. It not only reserves the high quality of shooting, but also

upgrades the sound receiver which build-in camera and have the best

distance---38 mm between two microphones. In order to enhance the

characters on the whiteboards, digital boards, and projectors, iCam PRO can

detect the external environment automatically and make the characters

clearer. Watching the iCam PRO videos is like watching Blu-ray movies in the

movie theaters.

PS: iCam PRO is unlike normal camera, it is designed for education institute

environment with full HD camera.

BlueEyes Technology

www.BlueEyes.tw

More information and features, please check official website of BlueEyes

Technology:

http://www.blueeyes.com.tw/iLearning_iCam.php

BlueEyes Technology

www.BlueEyes.tw

–Please do not leave or install the device in damp, direct sunlight, hot or confined

spaces.

–Do not put anything that would fall into the machine on top of the machine.

–Do not place the machine on an unstable place. It may fall down, resulting in an

injury.

–Please use this machine in a place with good ventilation. Do not block the heat

dissipation vents. Poor heat dissipation can lead to a rise internal temperatures

and cause malfunctions

–Use dry rag to clean the machine. Do not use solvent.

–We will not be liable for any damage caused by the use of third party power

supplies in this machine

–Never plug the machine into a power socket that is shared with other equipment

(extension load/cord, 2- or 3-way adapter, etc.). This may result in fire or electrical

shock or fire.

–To prevent the machine from thunder, please make sure there is a ground

connection.

–Please do not disassemble, re-design or maintain the device by yourself.

–The processors and accessories all pass the safety test of CE and FCC.

Please turn off iCam PRO, including power, network, sound

and video to avoid the damage from thunder. According to

BlueEyes warranty rules, thunder is one of natural disaster

which has no guarantee. Welcome visit:

http://www.BlueEyes.com.tw/warranty.php

BlueEyes Technology

www.BlueEyes.tw

-- Back panel --

Back panel descriptions:

DC12V

DC12V power input.

LAN

Attach the provided RJ-45 cable and the port is auto-sensing and supports negotiations

at 10/100 speeds.

VIDEO

Connect to video equipment, such as a monitor or projector.

LINE IN

Connect to an audio input source.

Do not test or connect the interface not commonly used. It

may cause instability of the system.

BlueEyes Technology

www.BlueEyes.tw

Fixed iCam PRO camera diagram:

Scanning iCam PRO camera diagram:

–The small monitor can suck on the direction controller. If you worry that it is not

steady enough, you can stick directly on the monitor.

–There are two control buttons on the direction controller of the scanning iCam PRO

camera, and the left and right controller is for SES. If you worry that the students

might drop it on the floor, you can stick it on the table with double-sided tape or

silicone as some of the education institutes do.

–Use flexible wire for network cable, video cable and audio cable to avoid fixed

screw loosening or interfaces dropping after long use.

–Put termination plug at the end of the left and right turn.

–After installing, you must rotate to the end and see the image simultaneously to

make sure the cables would not be pulled or the fixed screw of the camera would

BlueEyes Technology

www.BlueEyes.tw

not loosen when rotating.

–Use [double tone] for audio cable.

Follow these steps to watch live video on the notebook:

1. Open Microsoft Internet Explorer(IE) browser.

2. Enter the camera IP (192.168.1.171-176) on address bar.

3. Enter username and password.

4. Choose “Live View” to watch the video.

The operator username is sesuser. As a default, check the

factory configured list. You can edit account name or

password in setting. We recommend using Microsoft

Internet Explorer version 10 or higher web browser.
