Installation Instructions

For Models:

Model Number / Description File Name

B-155 ClassicSeries® Surface-Mounted LiquidMate® Soap Dispenser B-150.pdf

Designer’s Notes:

These dispensers should be mounted over a sink or

lavatory. Provide 1-1/2" (38mm) minimum clearance

above container for reﬁlling. The four #8 x 1-1/4" (4.5 x

32mm) screws furnished with unit should be used for

mounting unit on most wall surfaces. In some cases, wall

anchors will be required (not furnished).

HOW TO INSTALL DISPENSER:

1. Align the assembled unit vertically.

2. Mark the bottom edge and two bottom mounting holes.

3. Remove the container and realign the bracket with

your marks.

4. Mark the two top mounting holes.

5. Predrill mounting holes with 1/16" to 3/32" (1.6–

2.4mm) drill bit.

6. Screw bracket into place.

7. Fill container per instructions and return to bracket.

HOW TO REMOVE AND FILL CONTAINER:

1. Unscrew retaining collar under bracket until container

is free.

2. Turn container upright and unscrew liquid valve.

3. Fill container with thin, free-ﬂowing liquid soap or

detergent, then reinstall dispenser mechanism. Finger

tighten liquid valve onto bracket.

4. Finger tighten retaining collar onto container.

MAINTENANCE:

Use warm water and mild soap to clean all parts. NEVER

USE ABRASIVE CLEANERS.

REPLACEMENT PARTS LIST

Part Name Part No.

Liquid Valve – Charcoal 150-4

Liquid Valve – Beige 151-4

24-ﬂ oz (0.7-L) Container 155-7

Form No. 150-69 r12/29/10 Printed in U.S.A.

24-fl oz (0.7-L)

Bottle

155-7

Washer

150-4

151-4

Liquid

Valve

Mounting

Screw

Bracket

Retaining

Collar

Mounting

Screw

INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE

BOBRICK MODELS B-155 AND B-156 LiquidMate®SOAP DISPENSERS

LiquidMate®Soap Dispensers

In the U.S.A.: BOBRICK WASHROOM EQUIPMENT, INC.

#OMMERCE$RIVE#LIFTON0ARK.EW9ORKs4ELs&!8

(ART3TREET.ORTH(OLLYWOOD#ALIFORNIAs4ELs&!8

In Canada: BOBRICK WASHROOM EQUIPMENT COMPANY

2OLARK$RIVE3CARBOROUGH/NTARIO-2"s/NTARIO%AST4EL&!8

s-ANITOBA7EST4EL&!8

716954 00008 8

B-156

716954 00003 3

B-155

QA010511
