MAINTENANCE INSTRUCTIONS FOR SOAP VALVES

INSTALLATION INSTRUCTIONS

RBA7730-860 BOBRICK PANEL-MOUNTED SOAP DISPENSER

Keep soap and dirt from clogging spout, plunger and valve

mechanism. Clean spout with BobKey and/or remove plunger and

valve mechanism and soak in hot water. Warm water should be

pumped through supply line & valve at regular scheduled intervals.

If, after long use, valve begins to drip, replace O-rings and/or

DuckBill Valves.

SPARE PARTS

TROUBLESHOOTING

Soap does not dispense

paossehcaerebutylppusmrifnoC

ebutylppusnisegakcolbrospmirconmrifnoC

Piston does not return See‘Maintenance Instruction for Soap Valves’above

]2egapees[desugniebsipaosdeificepsmrifnoC ]wolebstraPerapSees[s

gnir-OecalpeR

Soap is aerated daerhtretpadanodesuneebsahepatnolfeTmrifnoC

Valve won’t hold prime fodnemottobnitneserpsievlavllib-kcudmrifnoC ebutylppus

Confirm sufficient soap supply

Confirm no cracks or splits in adapter or tube

Model Number

B822-95

B8601-5

RBA7780-100-001

Description

1L Bottle

Bottle Cap

Service Kit [includes O-Rings & Duckbill Valve]

RBA7737-106

Soap to suit, 15L

For further information,

contact the nearest RBA Group office:

SYDNEY • MELBOURNE • BRISBANE • PERTH

Phone: 1300 788 778 • Fax: 1300 788 878

[email protected] • www.rba.com.au

II/Model RBA7730-860/0112

RBA7730-999-001 Rubber Grommet to house the supply line as it

enters the reservoir.

B111-15 Duck-bill Valve is inserted into the end of the

supply line to assist in maintaining prime.

RBA7730-999-005 Soap Reservoir, 5L

RBA7730-999-010 Soap Reservoir, 10L

1. Conduit is recommended when tracking the supply line through walls, etc

2. To ensure effective operation of soap valve, supply line should be no greater than

1.4m from pump.

3. Thread sealing tape such as Teflon tape or similar is recommended as a sealant

on the exposed thread of the adapter where the valve attaches.

4. Soap Reservoir should always be covered to avoid dust & grit from

contaminating the soap and fouling the dispenser. RBA recommends using part

RBA7730-999-001 Rubber Grommet to house the supply line as it enters the

reservoir.

5. To avoid crushing the reservoir, the lid of the reservoir should be only lightly

tightened, allowing a minute passage of air in, as soap is drawn out.

6. To ensure effective operation of soap valve, supply line should have no crimps or

bends. Extra attention should be paid to the supply tube as it turns down from the

rear of the valve. Also, installers should ensure an additional ‘duck-bill valve’ [part #

B111-15] is inserted into the end of the supply line to assist in maintaining prime.

7. Easy access to the rear of the valve should be provided to allow for maintenance

and repair.

8. Part numbers for remote reservoirs as follows:

RBA7730-999-005 Soap Reservoir, 5L

RBA7730-999-010 Soap Reservoir, 10L

INSTALLATION

Soap Solution shall be dispensed in a liquid form and should be:

(a) vegetable oil based;

(b) anhydrous soap concentration range: 10% - 15%;

(d) viscosity range: max 1.0 centerpoise;

(e) soap shall contain a humectant (anti coagulant);

(f) soap shall be perfumed or non perfumed.

IMPORTANT: IF THE SOAP DOES NOT MEET THIS SPECIFICATION THE

WARRANTY WILL BE VOID.

LIQUID SOAP SPECIFICATION - RBA7737-106

85mm

3-1/4''

Adapter

Bottle Cap

50mm

2''

Maximum

Panel

Thickness

Container

Container Support

Not Furnished

85mm

Dia.

3-5/16''

230mm

9-1/16''

Washer

Nut

Cable Tie

Supply Tube

(1400mm) Valve

ROUGH IN DIMENSION

Panel Depth: 32mm - 50mm

Penetration: 18mm

Clearance behind wall: 90mm
