Boneco H680 Bedienungsanleitung

H680

MANUAL

INSTRUCTIONS FOR USE

BONECO H680

en TABLE OF CONTENTS

Technical specifications 40

Introduction 41

Relief from allergies 41

Valuable information about humidity 41

Scope of delivery 41

Overview and part names 42

Start-up 44

Indicators on the display 46

Keypad and remote control 47

Two types of operation 47

The “Hybrid” operating mode 48

Operating mode at initial start-up 48

Using the “Hybrid” operating mode 48

Air quality indicator 48

Basic settings 48

Only air humidification / Only air purification 49

“Air humidification” operating mode 49

“Air purification” operating mode 49

Use without water or HYBRID filter 49

Selecting the various comfort modes 50

Comfort modes 50

Switching the comfort mode 50

“AUTO” comfort mode 50

“SLEEP” comfort mode 50

“BABY” comfort mode 50

Manually regulating humidity and fan level 51

Perfect humidity 51

Controlling humidity 51

Maximum humidification 51

Regulating the fan level 51

Power level (P) 51

Timer function 52

Setting the OFF timer 52

Setting the ON timer 52

Display lock 53

Activating the display lock 53

Deactivating the display lock 53

Automatic cleaning function 56

Evaporator mat 56

Preparing for first use 56

Descaling 57

Assembly 57

Changing the cleaning time 57

Replacing the Ionic Silver Stick® 58

Important notes on cleaning 60

General 60

Important safety notes 60

Hidden dirt and grime 60

Recommended cleaning agents 60

Monthly cleaning 61

Cover 61

Pre-filter 61

HYBRID filter 61

Filter holder 61

Water tank 62

Water base 62

Drum 62

Evaporator mat 63

Fan blade 63

Housing 63

Particle sensor 64

Assembling the appliance 64

Clearing a notice 64

Replacing the HYBRID filter 68

Malfunctions and troubleshooting 69

en TECHNICAL SPECIFICATIONS

Type designation BONECO H680

Power supply voltage 100–240 V, 50–60 Hz

Power consumption 30 W

Humidity output 1000 g/h* (6.340 gal/day)

Air purification performance 190 m3/h (112 CFM) (CADR)

For room sizes up to 100 m2(1080 sq ft)

Capacity 10 l (2.64 US gal)

Dimensions L 347 × W 435 × H 490 mm (13.6”x17.1”x19.3”)

Operating noise level < 25 dB(A)

Weight (empty) 10.4 kg (22.3 lbs)

Accessories Ionic Silver Stick®A7017, HYBRID filter

* For operation without HYBRID filter depending on temperature and humidity

INTRODUCTION

DEAR CUSTOMER,

Congratulations on your purchase of the BONECO H680.

Its hybrid design cleans and humidifies room air in one

step. Its smart control system keeps operating noise to a

minimum, even allowing you to use the BONECO H680 in

a bedroom or baby’s room.

The BONECO H680 is designed for convenient, fully

automated operation. However, you can adjust all of its

features according to your preferences and requirements.

This manual shows you how you can create your own

comfortable climate.

RELIEF FROM ALLERGIES

The BONECO H680 is equipped with a triple filter system

that rids the air of odors as well as dust, pollen and con-

taminants. The HYBRID filter also effectively alleviates

many forms of discomfort caused by allergies, such as

hay fever or allergic reactions to dust mites and house-

hold dust.

VALUABLE INFORMATION ABOUT HUMIDITY

The right humidity is very important for our health. Dry

room air in winter leads to skin that cracks and itches. It

makes your eyes and throat feel dry while significantly af-

fecting physical comfort. Not only does this affect adults,

it is especially true for babies, small children and even

pets. Dry mucous membranes in winter also make us

more prone to colds and other infections.

The BONECO H680 makes these problems a distant

memory. Its intelligent automatic controls always keep

the air clean and the humidity at the ideal level, even in

large rooms with an area of up to 100 square meters

(1080 square feet).

Regardless of whether it is summer or winter: You

will not want to give up your newly gained comfort.

SCOPE OF DELIVERY

BONECO H680

with HYBRID filter

Power supply unit with

country-specific adapter

OOOOOOO

OOOO

“CalcOff” cleaning and des-

caling powder A7417

CD with manuals in other

languages

Remote control

including CR 2025 battery

en OVERVIEW AND PART NAMES

1 2 3 4

1110 12 13 14

6 8 97 1Front cover

2Pre-filter

3HYBRID filter

4Filter holder

5Drum

6Evaporator mat

7Ionic Silver Stick®

8BONECO H680

9Water tank

10 Fragrance container

11 Water base

12 Remote control

13 Fan blade

14 Power supply

START-UP AND USE

en START-UP

Lift the appliance out of the box

together with the inner packaging.

Take out the HYBRID filter and remove the

protective foil.

Remove the front cover using the tabs on the sides.

Insert the HYBRID filter

(note the direction the arrow is pointing).

Take off the pre-filter.

Put the pre-filter back on.

START-UP (CONTINUED)

Reattach the front cover.

Connect the power supply to the BONECO H680 first

and then to the power outlet.

Fill the water tank with cold tap water.

Switch the appliance on using the button on the

display or on the remote control.

Connect the adapter provided to the power supply

unit.
