Boneco P500 Bedienungsanleitung

P500

MANUAL

READ AND SAFE THESE INSTRUCTIONS

en INSTRUCTIONS FOR USE FOR BONECO P500

DEAR CUSTOMER,

Congratulations on your purchase of the BONECO P500.

The highly efficient air purifier is equipped with a triple

filter system that rids the air of odors as well as dust,

pollen and contaminants. The filter also effectively allevi-

ates many forms of discomfort caused by allergies. This

includes hay fever or allergic reactions to dust mites and

household dust.

The BONECO P500 is designed for convenient, fully auto-

mated operation. The smart control system ensures that

the noise level remains as low as possible. In com-

fort mode, the fan works so quietly that you can even use

the BONECO P500 at night in the bedroom. And thanks to

the integrated automatic timer, cleaning starts while you

are still on the way home. This means you can always

come home to an optimal living climate.

We hope you enjoy your new BONECO P500 air puri-

fier!

SCOPE OF DELIVERY

BONECO P500 with country-

specific power cable

“BABY”, “SMOG” or

“ALLERGY” filter

CD with manuals in other

languages

Remote control

including CR 2025 battery

TECHNICAL SPECIFICATIONS*

Type designation BONECO P500

Power supply voltage 220–240V, 50Hz

Power consumption 30W

Operation noise level 31– 60 dB(A)

Recommended room size 26 m² (ALLERGY filter), 23 m² (BABY filter), 29 m² (SMOG filter)

65 m³ (ALLERGY filter), 58 m³ (BABY filter), 72 m³ (SMOG filter)

Cleaning output (CADR) 258 m³/h (ALLERGY filter), 226 m³/h (BABY filter), 295 m³/h (SMOG filter)

Air flow 300 m³/h

Dimensions L×W×H 224×450×642 mm

Weight (empty) 7.35 kg / 8.20 kg (with «ALLERGY» filter)

* Subject to change

OVERVIEW AND PART NAMES

* Depending on the model, a “BABY”, “SMOG” or “ALLERGY” filter type is included in standard delivery

1 2 3

4 5

1Front cover

2Pre-filter

3Filter*

4BONECO P500

5Touch display

6Remote control

7Fragrance container

8Power cable

en PUTTING INTO OPERATION

Take out the filter and remove the protective foil.

Remove the magnetically attached front cover.

Insert the filter back into the holder (note the markings).

Take off the pre-filter.

Reattach the front cover.

Put the pre-filter back on.

FRONT COVER AND FILTER TYPES

MAGNETIC FRONT COVER

The BONECO P500 front cover is held on by magnets. The

air purifier does not switch on if the front cover is missing

or positioned incorrectly.

NOTES ON THE FILTERS

Your BONECO P500 was shipped from the factory with

the “ALLERGY”, “SMOG” or “BABY” filter. However, the

appliance is compatible with all three filter types. The

delivered filter can be replaced by another model at any

time if your requirements change.

REPLACEMENT FILTERS

You can get the replacement filters at your BONECO spe-

cialist dealer or at the online store at www.shop.boneco.

com. The filters are identified by these labels:

A501 A503A502

BRIGHTNESS OF THE DISPLAY

The brightness of the display depends on the ambient

light. The display is dimmed automatically if the BONECO

P500 is used in a dark room (such as a bedroom).

CLEARING THE FILTER WARNING

The symbol does not go out automatically after the

filter has been replaced. Press and hold the button

for five seconds to hide the symbol. This also resets the

counter for the new filter at the same time.

INDICATORS ON THE DISPLAY

Overview of all indicators on the display

Symbol Meaning

Duration of the ON timer/OFF timer 18

Fully automated operation 17

Low-noise nighttime mode 17

Timer function 18

Air quality 17

Fan level 17

Filter used up, replace 19

The BONECO P500 can easily be adapted to suit your

needs. Whenever you switch off the unit, all settings are

saved until the next use. However, the settings are reset

whenever the unit is disconnected from the power supply.

“AUTO” COMFORT MODE

In the mode, the BONECO P500 is fully automatic

and controls the fan levels, achieving an optimum effect.

“SLEEP” COMFORT MODE

In comfort mode, the fan operates at the lowest

level to keep the noise level as low as possible. This set-

ting is suitable for use in a bedroom, nursery or baby's

room.

COMFORT MODE SWITCH

1. On the keypad or the remote control, push the

button to switch between and comfort

modes.

BASIC FUNCTIONS

AIR QUALITY INDICATOR

The air quality is shown on the display by 8 segments. The

better the air quality, the more segments are displayed

in white:

MANUALLY CONTROLLING THE FAN LEVEL

The fan level of the BONECO P500 can be controlled

manually, such as if you want the air to be thoroughly

purified in the shortest possible time.

1. Push the button repeatedly until the desired fan

setting is achieved.

2. On the keypad or the remote control, push the

button to switch back to the or comfort

mode.

POWER LEVEL

The power level (P) can only be selected manually using

the button. The fan is now working at its maximum

output.

USING FRAGRANCES

The fragrance container for adding fragrances is on the

backside of the BONECO P500.

1. Briefly push on the fragrance container to unlock it and

then remove the compartment.

2. Insert the fragrance into the fragrance container.

3. Push the fragrance container into the air purifier until

it clicks into place.

TIMER FUNCTION

The timer function lets you determine how long the

BONECO P500 should run before it switches off auto-

matically (OFF timer).

Alternatively, you can specify a time for when the ap-

pliance should switch on automatically (ON timer). Use

this function, for example, to activate the BONECO P500

before you return home, so that you have the perfect liv-

ing climate waiting for you.

The maximum duration of the timer is 19 hours.

SETTING THE OFF TIMER

1. Switch on the BONECO P500 using the button.

2. Select the desired operating setting and the desired

comfort mode.

3. Press the button once.

4. Use the button to set how long the appliance oper-

ates (1 to 19 hours).

The appliance then runs for the specified period and then

switches itself off.

5. To deactivate the timer early, press the button again

and select . Alternatively, you can switch off the

BONECO P500 using the button.

SETTING THE ON TIMER

1. Select the desired operating setting and the desired

comfort mode.

2. Switch off the BONECO P500 using the button.

3. Press the button once.

4. Use the button to set the start preselection time

(1 to 19 hours).

The BONECO P500 switches on after the defined time and

operates with the selected program.

5. To deactivate the ON timer early, press the button

again and select . Alternatively, you can switch on

the BONECO P500 using the button.

TIMER FUNCTION

REPLACING THE FILTER

The filter is worn out if the symbol is illuminated. The

filter must be replaced at this point to continue to ensure

optimal air purification.

The filter must be replaced as soon as possible after the

reminder is displayed but after one year at the latest.

The procedure for replacing the filter corresponds to the

figures on page 14.

1. Replace the filter in accordance with the instructions

on page 14.

2. Hold the button for 5 seconds to the hide the symbol

CLEANING THE PRE-FILTER

The pre-filter prevents excessive dust accumulation from

getting inside the BONECO P500.

1. Clean the pre-filter under running water or using a

vacuum cleaner.

2. Allow the pre-filter to dry completely before re-insert-

ing it.

CLEANING THE PARTICLE SENSOR

The particle sensor detects the amount of dirt in the air

in the room by analyzing a passing air stream. Over time,

dirt can accumulate and affect measuring accuracy.

The flap over the particle sensor has to be closed during

operation to ensure the measurement is correct. It should

only be opened to clean the sensor.

1. Wipe the sensor with a damp cotton swab.

2. Dry the sensor with a dry cotton swab.

Do not use alcohol or corrosive cleaning agents for

cleaning.

CLEANING AND MAINTENANCE

V-03

www.boneco.com

BONECO is a registered trademark of PLASTON Group, Switzerland
