Boneco P400 Bedienungsanleitung

S.V.P. lire et conserver ces instructions

Please read and save these instructions

P400

MANUAL

Instructions for use 6

Instructions d’utilisation 14

Instrucciones de uso 22

en INSTRUCTIONS FOR USE FOR BONECO P400

DEAR CUSTOMER,

Congratulations on your purchase of the BONECO P400.

The highly efficient air purifier is equipped with a triple

filter system that rids the air of odors as well as dust,

pollen and contaminants. The filter also effectively allevi-

ates many forms of discomfort caused by allergies. This

includes hay fever or allergic reactions to dust mites and

household dust.

The BONECO P400 is designed for convenient, fully auto-

mated operation. The smart control system ensures that

the noise level remains as low as possible.

We hope you enjoy your new BONECO P400

air purifier!

SCOPE OF DELIVERY

BONECO P400 with country-

specific power cable

“ALLERGY”, “BABY” or

“SMOG” filter

Printed manual

TECHNICAL SPECIFICATIONS*

Type designation BONECO P400

Power supply voltage 120 V, 60 Hz

Power consumption 27 W

Operation noise level 30–58 dB(A)

Suitable for room size by

air exchange per hour

“ALLERGY” Filter “BABY” Filter “SMOG” Filter

Cleaning output (CADR) 221 m³/h | 131 cfm 211 m³/h | 124 cfm 248 m³/h | 146 cfm

Air flow 280 m³/h | 167 cfm

Dimensions L×W×H 224 × 420 × 562 mm | 8.8 × 16.5 × 22.1 in.

Weight (empty) 7.2 kg / 7.9 kg | 15.9 lbs / 17.4 lbs (with “ALLERGY” filter)

* Subject to change

1.5 x

3 x

5 x

600 sq ft (56 m2)

300 sq ft (28 m2)

175 sq ft (16 m2)

562 sq ft (52 m2)

281 sq ft (26 m2)

174 sq ft (16 m2)

668 sq ft (62 m2)

334 sq ft (31 m2)

189 sq ft (18 m2)

OVERVIEW AND PART NAMES

* Depending on the model, a “ALLERGY”, “BABY” or “SMOG” filter type is included in standard delivery

1 2 3

4 5

1Front cover

2Pre-filter

3Filter*

4BONECO P400

5Touch display

6Fragrance container

7Power cable

en PUTTING INTO OPERATION

Take out the filter and remove the protective foil.

Remove the magnetically attached front cover.

Insert the filter back into the holder

(note the markings).

Take off the pre-filter.

Reattach the front cover.

Put the pre-filter back on.

FRONT COVER AND FILTER TYPES

MAGNETIC FRONT COVER

The BONECO P400 front cover is held on by magnets. The

air purifier does not switch on if the front cover is missing

or positioned incorrectly.

NOTES ON THE FILTERS

Your BONECO P400 was shipped from the factory with

the “ALLERGY”, “SMOG” or “BABY” filter. However, the

appliance is compatible with all three filter types. The

delivered filter can be replaced by another model at any

time if your requirements change.

REPLACEMENT FILTERS

You can get the replacement filters at your BONECO

specialist dealer or at the online store at www.shop.

boneco.com. The filters are identified by these labels:

A401

ALLERGY

A403

SMOG

BRIGHTNESS OF THE DISPLAY

The brightness of the display depends on the ambient

light. The display is dimmed automatically if the BONECO

P400 is used in a dark room (such as a bedroom).

CLEARING THE FILTER WARNING

The symbol does not go out automatically after the

filter has been replaced. Press and hold the button

for five seconds to hide the symbol. This also resets the

counter for the new filter at the same time.

INDICATORS ON THE DISPLAY

Overview of all indicators on the display

Symbol Meaning

Fan level 9

Filter used up, replace 10

The BONECO P400 can easily be adapted to suit your

needs. Whenever you switch off the unit, all settings are

saved until the next use. However, the settings are reset

whenever the unit is disconnected from the power supply.

BASIC FUNCTIONS

MANUALLY CONTROLLING THE FAN LEVEL

The fan level of the BONECO P400 can be controlled

manually, such as if you want the air to be thoroughly

purified in the shortest possible time.

Push the button repeatedly until the desired fan set-

ting is achieved.

POWER LEVEL

“Power Level” (P) can be achieved by pressing the

button. The fan is working at its maximum output under

Power Level (P).

USING FRAGRANCES

The fragrance container for adding fragrances is on the

backside of the BONECO P400.

1. Briefly push on the fragrance container to unlock it and

then remove the compartment.

2. Insert the fragrance into the fragrance container.

3. Push the fragrance container into the air purifier until

it clicks into place.

REPLACING THE FILTER

The filter is worn out if the symbol is illuminated. The

filter must be replaced at this point to continue to ensure

optimal air purification.

The filter must be replaced as soon as possible after the

reminder is displayed but after one year at the latest.

The procedure for replacing the filter corresponds to the

figures on page 6.

1. Replace the filter in accordance with the instructions

on page 6.

2. Hold the button for 5 seconds to the hide the symbol

CLEANING THE PRE-FILTER

The pre-filter prevents excessive dust accumulation from

getting inside the BONECO P400.

1. Clean the pre-filter under running water or using a

vacuum cleaner.

2. Allow the pre-filter to dry completely before re-insert-

ing it.

CLEANING AND MAINTENANCE
