RAILSTOP RS S06 IN USE
USING THE FALL ARRESTER
CAUTION:
Before using, ensure there is enough clearance
to the ground below the user to prevent a fall
onto a protruding obstacle or the ground.
CAUTION:
When starting to ascend near the ground
(approx. . m), it is possible, under un-
favourable circumstances, that the legs will
hit the ground when the fall is arrested.
When climbing horizontally pull backwards on
the karabiner A (ventral multifunctional D-ring)
(horizontal pull = back support) and keep
unlocked in this way.
• Climb onto or o evenly in front of the middle
of the ladder and allow the fall arrester to
move with you.
• Do not allow loads to be exerted onto the
chest attachment! Keep the upper body
upright. If the upper body tilts out of the
normal position (due to a fall, unconscious-
ness etc.), the additional pawl B will block
immediately!
• The user can achieve an ergonomic resting
position quickly and safely by manually lifting
and blocking the fall arrester and assuming a
sitting/suspended position in the full body
harness. Does not serve workplace positio-
ning!
CAUTION:
The fall arrester must be blocked before the
user is suspended or sits in the harness!
CAUTION:
The weight of the user with tools and equip-
ment may not exceed kg!
CAUTION:
The weight of the user without tools and equip-
ment may not undercut kg!
CAUTION:
When using the fall arrester, ensure that the
function of the pawls and their attachments
are not obstructed. Otherwise, the locking
function may be disabled.
• The arrested fall arrester can be released by
slightly lifting the karabiner.
• When working on the ascent, always secure
with an additional holding rope in compliance
with EN (e.g. LORY HOLD) or with a fall
arrester rope in compliance with EN /
EN (e.g. PYTHON). Lateral inclined loads on
the fall arrester are not allowed.
Application
situation
