BV9362BI 6.2

And

Warmly Suggestion

Notice Item

Features

1.Front Panel Function Instruction

2.Basic Function

3.Remote Control Function

4.Main menu touch operation

5.RDS User Operation

6.Radio Operation

7.Audio

8.Disc Play Touch Operation

9.DVD Basic Operation

10.VCD Basic Operation

11.CD Basic Operation

12.MP3/USB/SD Operation

13.Bluetooth Function Instruction

15.Other Play Mode

16.Trouble Shooting

17.Wiring Diagram

18.Specifications

19.Accessory

19.ACCESSORY

User Manual

Accessory Quantity

Wire

USB Cable

Remote Controller

Warranty card

1PC

2PCS

14.IPOD READY

Welcome 18.SPECIFICATIONS

Amp Rating 80 WattsX4 Channels

European frequency range

USA frequency range 87.5-107.9MHz

European frequency range

USA frequency range 530-1710kHz

522-1620kHz

20-30dBuv

NOTE

: Be sure the unit is connected to a 12 Volts battery,

not connected to a 24 Volts battery.

Yellow with yellow tip: rear view video input (optional)

Black with black tip: IPOD connection (optional)

Black with black tip: radio antenna

Black with black tip: back USB (optional)

Black with yellow tip: external video input

grey with yellow tip/Dark grey with yellow tip: 2

channel video output

Black with black tip: rear USB connection (optional)

Dark grey with red-white tip: front RCA audio output

(red right white left)

Grey with red-white tip: rear RCA audio output

(red right white left)

Black with red-white tip: AUX audio input

(red right white left)

Blue with red-white tip: background audio output

(red right white left) (optional)

Brown with brown tip: subwoofer output (optional)

17.WIRING DIAGRAM

This player is equipped with ISO standard connector, please follow below instruction:

● Yellow – 12 V Constant

● Black – Ground wire

● Blue - Power Antenna / Remote Amp Turn On

● Orange – Back-Up Camera Trigger (+) ● Pink – Parking Brake (-)

● White/White black - Left front speaker (+-)

● Purple/Purple black - Right rear speaker (+/-)

● Green/Green black - Left rear speaker (+/-)

● Red - ACC ON (+12V) ● Grey/Grey black - Right front speaker (+/-)

Note:

The “PARKING BRAKE” wire must be connected to the parking brake system

of your car. When the parking brake is engages, the LCD will be allowed to view

your video. If not, the screen will produce an image saying, “PARKING BRAKE”.

This is a safety feature designed for the driver not to watch a video while driving.

The video output on this unit will not be affected by this.

DVD PLAYER

1.MPEG-4 Decoder Technology

2.Compatible with MP4(AVI/5.X),DVD(DVD-R/DVD-RW),VCD,SVCD,CD-RW,

WMA,MP3,JPEG

3.Supporting Multiles Subtitles,Angles,Languages

4.Child lock function

5.4-Channel Audio Output

6.Pause, play, UP/Down, Stop, Zoom, PBC Function

RADIO

1.AM/FM Radio Tuner

2.30 Radio Preset Stations (18FM, 12AM)

BULETOOTH FUNCTION

1.Bluetooth wireless transfers

2.Displaying bluetooth paring and connection status, call status, and caller's ID

3.Fast performance, fast connection, accurate and sensible search of devices in range

4.Support A2DP, AVRCP, HS/HF for handing calls and playing music

FEATURES 16.TROUBLE SHOOTING

15.OTHER PLAY MODE

9 10 11

1.SRC Button

2.MUTE/TFT on/off Button

3.MODE Button

4.SD Slot

5.RESET Button

6.SEL/VOL Button

7.AUX IN

8.USB Slot

9.Disk Load Slot

10.OPEN Button

11.Remote Control Receiver

12.MIC Input

INSTRUCTIONS

“Ipod” Video mode setting:

Select “Video” on the main menu of the “ipod” player. If not ready the video

mode setting, will never play the video file. The setting instruction as below:

(1) TV Out : ON

(2) TV signal : PAL/NTSC

(3) Full Screen: OFF

When selecting video mode, must switch to “ipod”" operation mode. Unless the

unit will only with voice but not picture.

About ”ipod” players operation instruction, please refer to the ipod player's

instruction manual.

After plugging in ipod player and switch to ipod mode, and enter the ipod UI

screen. At that time ipod player will display the “Sunplus” logo as the picture

bleow.

When you see this picture, the ipod player is out of control

Above operation instruction is according to the “ipod” edition 1.3

Note:

Since “ipod” edition keeping up-date, some edition software of the “ipod” player

may not working with this unit, Sometimes, may happen compatible problem.

Sorry for the inconvenience.

1.SRC Button

2.MUTE/TFT on/off Button

3.MODE Button

Bluetooth

4.SD Slot

This is a high-spees transmission interface, which can read high-capacity date in

MP3 or MP4 format.

5.RESET Button

Press this button and this unit will be restored to the initial state.

6.SEL/VOL Button

Turn this button can adjust the volume,Press this button can adjust the

mode according to personal likes.

08 45

For example: As PIC 2, touch certain category you want, then touch “ok” to inter

the category. After that, touch any file to play. It shows like the PIC 3 below.

4. Video Play

In the files menu, touch any part of the touch screen, then touch the

”MOD” on the screen control (see PIC 4) to enter the “ipod” mode.

Main menu, picture 4:

Touch “VIDEO“ on the main menu and the unit will switch to " ipod "operation

mode, while, control the “ipod” player, and select the video file you want to play,

while the video picture will transfer to the unit screen. During the unit playing

the video, ”ipod” player must set as Video mode, if not the unit only with audio

but not video.

8.USB Slot

9.Disk Load Slot

Opening for disks to enter or retreat.

10.OPEN Button

Press this button can eject the disc

11.Remote Control Receiver

12.MIC Input

Bluetooth MIC input.

14. IPOD READY

MODE

VOL

10 43

4.Incoming display

If there is incoming, under any mode, system will automatically switch to

Bluetooth hand-free function interface. And it have incoming sound and

incoming display note you to answer telephone.

5.Answer phone

When there is an incoming call, Touch to connect and touch

to refuse to connect.

6.Call logs

Under Bluetooth mode, press call logs button will enter call logs interface, as following:

(1)Press [dialed calls] function position, you will search

telephone number which you have dialed.

(2)Press [received calls] function position, you will

search telephone number which you have answered

(3)Press [missed calls] function position, you will

search telephone number which you have missed.

11 42

1.Enter/exit

Touch on main menu interface to enter Bluetooth interface;

Press will exit Bluetooth interface and return main menu interface.

2.Match/connection

If you want to use Bluetooth function, you must establish a connection first.

Matching unit with Bluetooth cell phone..

[operation way]

Set your cell phone to Bluetooth mode, and use cell phone to search equipment.

After Bluetooth equipment of this unit has been search by cell phone, cell phone will

Ask you for Bluetooth matching password.. touch matching setup button on unit and input

Bluetooth Password(0000) on cell phone and confirm it. Cell phone will note to whether authorize

Connection with this equipment. Please select “yes” . cell phone will auto establish connection

with Bluetooth of the equipment within 20seconds. Under any mode(radio, DVD etc. if there is an

incoming call to your cell phone, the unit will switch from current statue to Bluetooth. It will

automatically restore current mode after hang-up.

Note: if Bluetooth equipment matching with this unit correctly, it will display “LINK OK”

otherwise it display “NO LINK”.

3.Dial

You can use cell phone or touch digital key on display to input telephone number. If input wrong,

you can press to delete. After enter telephone number, press to dial.. Touch

to hang-up.

During call period, press “CHANGE” will let phone sound switch between speaker

of unit and speaker of Phone.

13.

12 41
