Boss Audio Systems BV12.1BGT Handbuch

Installing The Snap On Covers

Housing Snap On Cover

(Screen Back Cab)

Snap On Cover

(Shroud 1)

Snap On Cover

(Shroud 2)

Pry Tool

1. 2. 3. 4. 5.

Place the pod on a soft surface to avoid damaging the plastic.

Installing The Shroud

Begin by hooking the area and slide the cover over the pod. The cover will snap in place.

Installing The Screen Cover

Openthescreenandhookthetwotabs(A)onthebottomedgeofthescreen.Snapthe

opposite side over the hinge.

Removing The Snap On Cover(Shroud) From The Housing

Working on a soft surface to avoid damaging the plastic.

Insert the between the and ,

then press the to release the

pry tool Housing Snap On Cover (Shroud)

pry tool

supplied

Snap On Cover (Shroud).

Removing The Snap On Cover(Screen Back) From LCD The Housing

Working on a soft surface to avoid damaging the plastic.

Insert the supplied between the and ,

then press the to release the

pry tool Housing Snap On Cover (Screen Back)

pry tool Snap On Cover (Screen Back).

1 2 3

(A) (A)

1 2

1 2

3

3
