FormNo.MSC09482RevC
CasterandDollyKit
PartNo.MSC01141
PartNo.MSC09215
PartNo.MSC09216
PartNo.MSC09235
PartNo.MSC09249
InstallationInstructions
ForStraight-Bladeand
HTX/SportPlows
ModelMSC09215andMSC09249
1.AssemblethecastersasshowninFigure1.
g038527
Figure1
1.Nut(5/16inch)6.Nut(3/8inch)
2.Washers7.Largecaster
3.Smallcastershoebase8.Smallcaster
4.Kickstandcasterbase9.Bolt(5/16inch)
5.Carriagebolt
2.Parkthemachineonalevelsurface,raisethe
plowfully,andplace2safetyjackstandsunder
theplowcuttingedge.
3.Shutofftheengine,waitforallmovingpartsto
stop,engagetheparkingbrake,andremove
thekey.
4.Slidethesmallcastershoesintotheshoe
holdersontheplowandsecurethemwitha
quickpin(Figure2).
Note:Adjustthenumberofwashersaboveand
belowtheshoeholderasneeded.
g038528
Figure2
1.Quickpin3.Smallcastershoe
2.Shoeholder4.Washers
5.Removetheexistingkickstandandreplaceit
withthekickstandcastershoe(Figure3).
g038529
Figure3
1.Kickstandspringpin2.Kickstandcastershoe
©2019—BOSSProducts
P .O.Box787
IronMountain,MI49801
Registeratwww.bossplow.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*MSC09482*C
6.Fullyraisethekickstandcastershoeandlockit
intoplacewiththeexistingkickstandspringpin
(Figure3).
7.Removethesafetyjackstandsandlowerthe
plow.
8.Lowerthekickstandcastershoeandlockitinto
place.
9.FollowtheplowingproceduresinyourOwner’s
Manual.
ForXTV-BladePlows
ModelMSC09216
1.AssemblethecastersasshowninFigure4.
g038530
Figure4
1.Nut(5/16inch)5.Nut(3/8inch)
2.Washers6.Largecaster
3.Smallcasterbase7.Smallcaster
4.Carriagebolt8.Bolt(5/16inch)
2.Parkthemachineonalevelsurface,raisethe
plowfully,andplace2safetyjackstandsunder
theplowcuttingedge.
3.Shutofftheengine,waitforallmovingpartsto
stop,engagetheparkingbrake,andremove
thekey.
4.Slidethelargecastershoesintotheshoe
holdersontheplowandsecurethemwitha
quickpin(Figure5).
Note:Adjustthenumberofwashersaboveand
belowtheshoeholderasneeded.
g038531
Figure5
1.Quickpin3.Largecastershoe
2.Shoeholder
5.Slidethesmallcastershoeintothecentershoe
holderandsecureitwithaquickpin(Figure6).
Note:Adjustthenumberofwashersaboveand
belowthecenterbushingasneeded.
g038532
Figure6
1.Quickpin3.Washers
2.Smallcastershoe
6.Removethesafetyjackstandsandlowerthe
plowinthe“V”position.
7.FollowtheplowingproceduresinyourOwner’s
Manual.
2
ForHTXandUTVV-Blade
Plows
ModelMSC09235
1.AssemblethecastersasshowninFigure7.
g038533
Figure7
1.Nut(5/16inch)4.Smallcaster
2.Washers5.Bolt(5/16inch)
3.Smallcasterbase
2.Parkthemachineonalevelsurface,raisethe
plowfully,andplace2safetyjackstandsunder
theplowcuttingedge.
3.Shutofftheengine,waitforallmovingpartsto
stop,engagetheparkingbrake,andremove
thekey.
4.Slidethesmallcastershoesintotheshoe
holdersontheplowandsecurethemwitha
quickpin(Figure8).
Note:Adjustthenumberofwashersabove
andbelowtheshoeholderorcenterbushingas
needed.
g038534
Figure8
1.Quickpin3.Washers
2.Smallcastershoe
5.Removethesafetyjackstandsandlowerthe
plowinthe“V”position.
6.FollowtheplowingproceduresinyourOwner’s
Manual.
ForDXTV-BladePlows
ModelMSC01141
1.AssemblethecastersasshowninFigure9.
g038535
Figure9
1.Washers4.Centercaster
2.Carriagebolt5.Nut(3/8inch)
3.Plasticknob6.Caster
3
2.Parkthemachineonalevelsurface,raisethe
plowfully,andplace2safetyjackstandsunder
theplowcuttingedge.
3.Shutofftheengine,waitforallmovingpartsto
stop,engagetheparkingbrake,andremove
thekey.
4.Slidethelargecastershoesintotherearshoe
holdersontheplowandsecurethemwitha
quickpin(Figure10).
Note:Adjustthenumberofwashersaboveand
belowtheshoeholderasneeded.
g038531
Figure10
1.Quickpin3.Largecastershoe
2.Shoeholder
5.Partiallyinserttheplasticknobonthecenter
castershoeintotheplowcenterbushing(Figure
11).
g038536
Figure11
1.Plasticknob2.Centercastershoe
6.Slidethecentercastershoeontotheplow
centerbottomplate,ensuringthattheplastic
knobfacesforward(Figure11).
7.Tightentheplasticknobtosecurethecenter
castershoetotheplow.
8.Removethesafetyjackstandsandlowerthe
plowinthe“V”position.
9.FollowtheplowingproceduresinyourOwner’s
Manual.
4
