Boston Acoustics VS 224 Bedienungsanleitung

VSSeries

... a new Vision in great Sound

VS Series

Great sound has a whole new look

Boston VS Series Loudspeakers–our best performing, best-looking products

deliver a superior home theater or audio-only experience. Innovative driver

and cabinet designs yield exceptional sonic characteristics. Each VS Series

model is voiced to blend with the others so they can be combined to

deliver the best performance in any conguration.

Dispelling all notions of the typical loudspeaker “rectangular box,”

the structural elements of all VS models reect a seamless merging of

art and science. The structural elements of the cabinets are made of

high-frequency-molded MDF with “wave like”curved surfaces that reduce

internal standing waves and panel resonances. Further reecting

the seamless merging of art and science that denes the VS Series,

all VS cabinets feature an elegant piano lacquer nish and high-gloss

furniture-grade end panels.

Key features

• Super Wide Bandwidth (SWB) Tweeter featuring a Coupled Dual Concentric-

Diaphragm (CDCD) minimizes phase shift and distortion while improving

pistonic motion. (except VPS 210)

• Organic Composite Cone Material (OCCM) was developed using a mix of

select natural bers to reduce resonance and improve accuracy.

• High-frequency-molded MDF cabinet features curved surfaces,

which reduce internal standing waves and panel resonances.

• Bi-amp, Bi-wire capability (VS 336, VS344 and VS 325C)

• MagnaGuard® video shielding

• Gold-plated 5-way binding posts

• Elegant lacquer piano nish cabinet

• High-gloss multi-layer furniture-grade end panels

VS 336

3-Way Triple 6½”

Floorstanding Loudspeaker

US MAP $1699.99 each

VS 344

3-Way Quadruple 4½”

Floorstanding Loudspeaker

US MAP $1250.00 each

VS 325C

3-Way Dual 5¼”Center Channel Loudspeaker

US MAP $899.99 each

VS 224

2-Way Dual 4½”LCR Loudspeaker

US MAP $699.99 each

VS 260 and 240

VS 260 2-Way 6½”Bookshelf Loudspeaker

US MAP $699.99 each

VS 240 2-Way 4½”Bookshelf Loudspeaker

US MAP $399.99 each

VPS 210

10” High-Powered Subwoofer

500-watt RMS 1800-watt Peak Proprietary Class-D Amplier

US MAP $1699.99 each

300 Jubilee Drive, Peabody, MA 01960 bostonacoustics.com

Specications

Frequency Response 44Hz – 25kHz (±3dB)

Recommended Amplier 15 – 200 watts

Sensitivity 89dB [2.8v at 1m]

Nominal Impedance 8 ohms

Crossover Frequency 2,800Hz

Woofer Dual 6½” (165mm) copolymer

DCD with Phase Plugs

MBOS Dual 7” (178mm)

(Maximum Bass Output System) passive radiators plus

MBOS Rear Port

Tweeter 1” (25mm) Kortec®

Soft Dome

Dimensions (H x W x D) 43⁄ x 11⁄ x 9⁄”

(1096 x 302 x 242 mm)

Weight 28.2 lbs (12.9kg)

Finish black lacquer

300 Jubilee Drive, Peabody, MA 01960 bostonacoustics.com

Specications VS 240 VS 260 VS 224 VS 325C VS 344 VS 336

Frequency Range (±3dB) 70Hz – 30kHz 45Hz – 30kHz 78Hz – 30kHz 65Hz – 30kHz 42Hz – 30kHz 35Hz – 30kHz

Recommended Amplier 10 – 100Watts 10 – 250Watts 10 – 200Watts 10 – 250Watts 10 – 250Watts 10 – 400Watts

Sensitivity 86 dB SPL/2.8V/m 87 dB SPL/2.8V/m 87 dB SPL/2.8V/m 90 dB SPL/2.8V/m 87 dB SPL/2.8V/m 87 dB SPL/2.8V/m

Nominal Impedance 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms

Crossover Frequency 2,000 Hz 1,900 Hz 1,900 Hz 350 / 2,400 Hz 300 / 2,500 Hz 250 / 2,500 Hz

Bass Driver 4

⁄”(114mm) 6

⁄”(165mm) Dual 4

⁄”(114mm) Dual 5

⁄”(133mm) Quadruple 4

⁄”(114mm) Triple 6

⁄”(165mm)

Midrange Driver — — — 3”(76 mm) 4

⁄”(114mm) 4

⁄”(114mm)

High-Frequency Driver 1”(25mm) 1”(25mm) 1”(25mm) 1”(25mm) 1”(25mm) 1”(25mm)

Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth

Dimensions (H x W x D) 9

⁄ x 5

⁄x 6

⁄” 14

⁄x 9 x 10

⁄” 25 x 5

⁄x 3

⁄” 7

⁄x 28

⁄ x 6

⁄” 44x5

⁄x8

⁄” 46

⁄ x 9

⁄x 12

⁄”

(240 x 150 x 162mm) (365 x 225 x 260mm) (632 x 148 x 96mm) (181 x 716 x 161mm) (1117 x 148 x 161mm) (1170 x 250 x 325mm)

Weight: 6.3 lbs (2.9Kg) 9 lbs (4.1Kg) 18 lbs (8.2Kg) 25.9 lbs (11.78 Kg) 32.2 lbs (16.5 Kg) 66.3 lbs (30.12 Kg)

Specications VPS 210

Frequency Range 22 Hz – 150 Hz, ±3dB

Amplier Power Class D, 500 watt RMS (1,800 watt peak)

Bass Driver 10”(254mm) Long throw OCCM woofer

with 3”voice coil

Passive Radiator 10”(254mm) OCCM passive radiator

Dimensions (H x W x D) 15 x 13

⁄x 21

⁄”

(381 x 353 x 540mm)

Weight: 62 lbs (28.2kg)

Boston Acoustics continually strives to update and improve its products.

The specications and construction details are subject to change without notice.

Available end panel nishes

Cherry gloss black enclosure with gloss cherry end panels and black grille

Black gloss black enclosure with gloss black end panels and black grille
