Briggs & Stratton 44L700 Series Einrichtungshandbuch

Not for

Reproduction

in any form or by any means, electronic or mechanical, including photocopying,

recording or by any information storage and retrieval system, without permission

in writing from Briggs & Stratton Corporation.

PRINTED IN U.S.A.

FORM MS--3580--02/21/2011

REPLACES FORM MS--3580--09/16/2010

FILE IN SECT. 2 OF SERVICE MANUAL

44L700

Illustrated Parts List

Model Series

44L700

TYPE NUMBERS

0025 through 3137

TABLE OF CONTENTS

Air Cleaner 6.........................

Alternator 8..........................

Blower Housing/Shrouds 6............

Camshaft 2...........................

Carburetor 5..........................

Controls 7............................

Crankshaft 2..........................

Cylinder 2............................

Cylinder Head 4.......................

Electric Starter 9......................

Engine Sump 3.......................

Exhaust System 5.....................

Flywheel 7............................

Fuel Supply 5.........................

Ignition 8.............................

Gasket Set -- Engine 2.................

Gasket Set -- Valve 4..................

Kit--Carburetor Overhaul 5.............

Lubrication 3.........................

Piston, Rings, Connecting Rod 2.......

Valves 4..............................

Not for

Reproduction

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--2 Assemblies include all parts shown in frames. 02/21/2011

252

718

250

718

850

1058 OPERATOR’S MANUAL

1319 WARNING LABEL

REQUIRED when replacing parts

with warning labels affixed.

1330 REPAIR MANUAL

741

146

883

943

1022

358A ENGINE GASKET SET

868

842

691

524

163

51E

943A

51A

51B

Not for

Reproduction

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--3 Assemblies include all parts shown in frames. 02/21/2011

287

842

524

523

525

847

512

186A

1017

239

943

1035

965

1024

1027

415

1013

552A

15A

552

691

404

742

616

1017A

1024A

965A

943A

750A

750

Not for

Reproduction

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--4 Assemblies include all parts shown in frames. 02/21/2011

337

383

798

192

1022

1100

1029

868

798

883

1022

1100

1029

36 35

868

192

1023A

1023

1022

1022 868

1095 VALVE GASKET SET

163

883

1022

1026

1026A

914

654

51E

635

918A 918

617

Not for

Reproduction

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--5 Assemblies include all parts shown in frames. 02/21/2011

628

788

300

883

613

613A

601

187A

601

187E

788A

601

240B

387

385

50A

929

212

163

617

186

415

51B

104

987

150

1128

105

1126

1124

633

108

135

231

130

141

125

133

131

142

117A117

142

51E

217

1124A 1127

137

975

276A

947

51B

163

672

418

51B

118A

118 NOTE: Carburetor Illustrations Represents

Several Carburetors. Parts Shown In The

Service Box May Not Be Included In All Kits.

121 CARBURETOR OVERHAUL KIT

104

105

137

987

633

672

1124

150

276A

1124A

163

217

51A

51B

1169

Not for

Reproduction

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--6 Assemblies include all parts shown in frames. 02/21/2011

304C

445B

1036 EMISSIONS LABEL

967B

307A

306

573

306A

307

865B

447

405A

1040

968 467A

305

305B

163

431D 918B

964

186B

964

Not for

Reproduction

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--7 Assemblies include all parts shown in frames. 02/21/2011

363

1070

332

668

165

695

726

742

552

616

213

216

220

615

209

211

265

219

552A

404

552A

691

1005

562

505

227

278

212

668A

221

267 267A 267B

929

949A

563A

188

222A

222B

222C

1012

222D

222E

V3 V3

1012

V3 V3

Not for

Reproduction

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--8 Assemblies include all parts shown in frames. 02/21/2011

1054

851

334

635 333

877D

789B

789D

789J

729A

405A

878

474B

877

878A

474C

877B

526A

501A

1059 474C

877B

1059 1059

474D 1059

501D

526B

578A

789K

789F

318A

493

318

1438

640

1439

789G

5/9 AMP TRI CIRCUIT DUAL CIRCUIT

10/16 AMP

1119

NOTE: All stators use

NOTE: The proper flywheel part number and/or the alternator magnet size will

determine the alternator type or output. See repair instruction manual

for additional information.

1436

1437 929

789M

877C

1119

703 729

Not for

Reproduction

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--9 Assemblies include all parts shown in frames. 02/21/2011

1090

797

311

579

802

310

801

1051

783

513

309

510

697

503

462

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

44L700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

3580--10 Assemblies include all parts shown in frames. 02/21/2011

1 793564 Cylinder Assembly

2 797673 Kit--Bushing/Seal

(Magneto Side)

3 391086s Seal--Oil

(Magneto Side)

4B 796307 Sump--Engine

5 796231 Head--Cylinder

(Cylinder 1)

5A 796232 Head--Cylinder

(Cylinder 2)

7 693997 Gasket--Cylinder Head

8 792185 Breather Assembly

9 690937 Gasket--Breather

10 697551 Screw

(Breather Assembly)

11 792184 Tube--Breather

12 697227 Gasket--Crankcase

13 791130 Screw

(Cylinder Head)

(Used Before Code

Date 08070100).

-- -- -- -- -- -- N o t e -- -- -- -- -- --

793988 Screw

(Cylinder Head)

(Used After Code Date

08063000).

15 691680 Plug--Oil Drain

(Used Before Code

Date 08071800).

15A 690946 Plug--Oil Drain

(Used After Code Date

08071700).

16 796237 Crankshaft

-- -- -- -- -- -- N o t e -- -- -- -- -- --

796257 Crankshaft

Used on Type No(s).

0025, 0035, 0135.

796256 Crankshaft

Used on Type No(s).

0026, 0036, 0136.

20 795387 Seal--Oil

(PTO Side)

22 694966 Screw

(Crankcase

Cover/Sump)

23 691053 Flywheel

-- -- -- -- -- -- N o t e -- -- -- -- -- --

691054 Flywheel

Used on Type No(s).

0100, 0118, 0130.

24 222698s Key--Flywheel

25 792023 Piston Assembly

(Standard)

-- -- -- -- -- -- N o t e -- -- -- -- -- --

792072 Piston

Assembly

(.020” Oversize)

26 792026 Ring Set

(Standard)

-- -- -- -- -- -- N o t e -- -- -- -- -- --

792073 Ring Set

(.020” Oversize)

27 690975 Lock--Piston Pin

28 690229 Pin--Piston

-- -- -- -- -- -- N o t e -- -- -- -- -- --

696581 Pin--Piston

Used on Type No(s).

0025, 0026, 0027,

0035, 0036, 0037,

0110, 0117, 0118,

0119, 0128, 0130,

0131, 0132, 0135,

0136, 0137, 0138,

0139, 0144, 0145,

0160, 0162, 0279,

0282, 0719, 0723,

0757, 0763, 0769,

1224, 2119, 2139,

3137.

29 796209 Rod--Connecting

32 690976 Screw

(Connecting Rod)

33 697576 Valve--Exhaust

34 792200 Valve--Intake

35 694865 Spring--Valve

(Intake)

36 694865 Spring--Valve

(Exhaust)

42 499586 Keeper--Valve

45 690977 Tappet--Valve

46 790562 Camshaft

-- -- -- -- -- -- N o t e -- -- -- -- -- --

796853 Camshaft

Used on Type No(s).

0110, 0119, 0135,

0132, 0162, 0136,

0137, 0138, 0139,

0145, 0160, 0279,

0282, 0757, 0763,

0769, 2119, 2139,

3137.

50 695241 Manifold--Intake

51A 795123 Gasket--Intake

51B 690950 Gasket--Intake

51E 690949 Gasket--Intake

53 690951 Stud

(Carburetor)

54 699816 Screw

73 494439 Screen--Rotating

74 698425 Screw

(Rotating Screen)

75 691056 Washer

(Flywheel)

95 690718 Screw

(Throttle Valve)

98 699721 Kit--Idle Speed

104 694918 Pin--Float Hinge

105 797410 Valve--Float Needle

108 699723 Valve--Choke
