Brighter Mini Eye Bedienungsanleitung

Mini Eye

TABLE OF CONTENTS

1. Safety Instructions ...................................................................................................... 3

2. Technical Specifications.............................................................................................. 4

3. How To Control The Device ........................................................................................5

4. Dimmer Curve...........................................................................................................12

5. Diagram.....................................................................................................................13

6. Troubleshooting........................................................................................................13

7. Cleaning the device...................................................................................................14

Statement

The product has full capability and intact packing when it leaves

factory. All the users should comply with provided warnings and

manual. Any damages caused by misuse are not included in our

guarantee. We cannot be responsible for any malfunctions &

problems owing to ignoring the manual.

1. Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to

another user, be sure that they also receive this instruction booklet.

Unpack and check carefully there is no transportation damage before using

the unit.

Before operating, ensure that the voltage and frequency of power supply

match the power requirements of the unit.

It’s important to ground the yellow/green conductor to earth in order to

avoid electric shock.

The unit is for indoor use only. Use only in a dry location.

The unit must be installed in a location with adequate ventilation, at least

50cm from adjacent surfaces. Be sure that no ventilation slots are blocked.

Disconnect main power before replacement or servicing.

Make sure there are no flammable materials close to the unit while operating

as it is fire hazard.

Use safety cable when fixes this unit. DO NOT handle the unit by taking its

head only, but always by taking its base.

Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the

temperature is higher than this Unit surface temperature may reach up to

85℃.

DO NOT touch the housing bare-hands during its operation. Turn off the

power and allow about 15 minutes for the unit to cool down before replacing

or serving.

In case of serious operating problem, stop using the unit immediately. Never

try to repair the unit by yourself. Repairs carried out by unskilled people can

lead to damage or malfunction. Please contact the nearest authorized

technical assistance centre. Always use the same type spare parts.

DO NOT touch any wire during operation as high voltage might be causing

electric shock.

Warning:

To prevent or reduce the risk of electrical shock or fire, do not expose the

unit to rain or moisture.

DO NOT open the unit within five minutes after switching off.

The housing, the lenses, or the ultraviolet filter must be replaced if they are

visibly damaged.

Caution:

There are no user serviceable parts inside the unit. DO NOT open the housing or

attempt any repairs by yourself. If your unit requires service, please contact your

nearest dealer.

Installation:

The unit should be mounted via its screw holes on the bracket. Always ensure that

the unit is firmly fixed to avoid vibration and slipping while operating. And make sure

that the structure to which you are attaching the unit is secure and is able to support

a weight of 10 times of the unit’s weight. Always use a safety cable that can hold 12

times of the weight of the unit when installing the fixture.

The equipment must be fixed by professionals. And it must be fixed at the safe place

where it is not available for other people.

2. Technical Specifications

Power Voltage: AC 100-240V, 50/60Hz

Power Consumption: 160W

Light Sources: 7 Multi-chip 4in1 RGBW 15 Watt LED sources

LED Color Temperature: 6,500K

LED Life Time: 50,000 hours.

Electronic Zoom: 4°~60°

Control

DMX Channel: 27CH / 55CH

Control Modes: DMX512, Auto, Master-Slave, Sound

Pan/Tilt

Pan/Tilt: 540°/ 220°

Pan/Tilt Resolution: 16 bit

Construction

Display: LCD Display

DMX In/Out socket: 3-pin XLR sockets

Power Socket: Powercon in/out

Protection Rating: IP20

Features

0~100% electronic linear dimming

1~25 times/sec strobe, speed adjustable.

Each LED controllable, buit-in shapes effects.

Rotation: the lens head can infinite rotation in two direction.

Fast, quiet operation and flicker free

Size

Dimension: 167*243*344mm,

Packing Size:400*260*305MM

Weight

Net Weight: 6.0Kgs

Gross Weight: 7.2Kgs

3. How to Control The Device

The DMX512 is widely used in intelligent lighting control system. You can connect

several lights together with a DMX 512 controller. DMX in and DMX out, 3 pin XLR

connectors are: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)

Display:

MENU To select the programming functions

DOWN To go backward in the selected functions

UP To go forward in the selected functions

ENTER To exit the current function

OK To confirm the selected function

SET

Main-Menu

Sub-Menu

Description

DMX

DMX State

AUTO 1

Run Mode

AUTO 2

Auto and Sound Run Functions.

AUTO 3

Master mode: will send DMX signal to

slave (synchronous operating mode).

Sound 1

Sound 2

Press “Enter” to edit, press “Up” or

DMX Address

001~512

“Down” to change the DMX address.

Press “Enter” to save the address.

Channel Mode

27CH(STANDARD)

Two DMX channel modes, 27CH mode

55CH(SHAPES)

(Default).

No DMX Signal

KEEP

Keep the state and continues to run.

CLEAR

Stop run.

Invert Pan

ON/OFF

Invert Pan

Invert Tilt

ON/OFF

Invert Tilt。

Pan-Tilt Encoder

ON/OFF

Readable (ON), Unreadable (OFF)

LINE

Dimmer Curve

SCUR

LINE (Default)

INSQ

SQUA

When the temperature exceeds the set

Top

Temp

value, led power slowly reduced to

25~125

half-power state , when the temperature

Protection

is below the temperature will slowly

return to normal power state.

Load Default

Ok/Cancel

Press “OK” to restore defaults

Main-Menu

Sub-Menu

Description

Reset

Ok/Cancel

Press “OK” to reset

Pan

000~255

Tilt

000~255

Zoom

000~255

Rotation

000~255

Red

000~255

Green

000~255

Blue

000~255

White

000~255

Sys

Sub-Menu

Description

Software

Version

Displays the current version of the software

（Ver)

Total

Fixture

Displays the total used time information

Hours

Partial

Fixture

Displays the using time information

Hours

Current Temp

Advan

Main-Menu

Sub-Menu

Description

Zoom Hall State

If magnetic is detected then 00, else

Sensor Monitor

Rotation Hall State

If magnetic is detected then 00, else

XY Hall State

If magnetic is detected then 00, else

Pan

Codewheel

Step

+0000

Pan

CodeWheel

Step

+0000

Pan Calibration

-128~127

Reset Calibration

Tilt Calibration

-128~127

Zoom Calibration

-128~127

Rotation Calibration

-128~127

ColorR1 Calibration

255

-128~127

Color Calibration

…

-128~127

ColorR7 Calibration

255

-128~127

ColorG1 Calibration

255

-128~127

…

ColorG7 Calibration

255

ColorB1 Calibration

255

…

ColorB7 Calibration

255

ColorW1 Calibration

255

…

ColorW7 Calibration

255

All

-128~127

Test

Color

-128~127

Pan&Tilt

-128~127

Zoom&Rotation

-128~127

EN/中

Description

EN/中

English and Chinese language selection

180↑

Description

180↑

Display rotate 180 degrees

DMX Channels Mode

27 CH

55 CH

Function

Value

Description

Pan

0~255

Pan Movement

Pan Fine

0~255

Pan 16Bit Movement

Tilt

0~255

Tilt Movement

Tilt Fine

0~255

Tilt 16Bit Movement

Dimmer

0~255

Dimmer 0%~100%

0~3

Off

3~103

Strobe Slow to Fast, Led On

104~107

Strobe Off

Strobe

108~207

Jump Strobe Slow to Fast

208~212

Strobe Off

213~251

Split Strobe Slow to Fast

252~255

Strobe Off

Red

0~255

Red Dimmer 0%~100%

Green

0~255

Green Dimmer 0%~100%

Blue

0~255

Blue Dimmer 0%~100%

White

0~255

White Dimmer 0%~100%

Linear CTO

0~255

White led power adjustment

Macro Color

0~255

Macro Color

0~11

Empty

Function

12~24

XY Speed，Fastest Speed

25~37

XY Speed，Normal Speed

38~42

Dimmer Curve 1，LINE Curve

43~47

Dimmer Curve 2，SCUR Curve

48~52

Dimmer Curve 3，INSQ Curve

53~57

Dimmer Curve 4，SQUA Curve

58~62

Delay Curve 1

63~67

Delay Curve 2

68~72

Delay Curve 3

73~255

LED power adjustable

Zoom

0~255

Zoom

0~127

Rotation

Zoom Rotation

128~190

CCW Rotation, Fast to Slow

191~192

Stop

193~255

CW Rotation，Slow to Fast

Shape Selection

0~255

Shape Selection

Shape Speed

0~255

Shape Speed

Shape Fade

0~255

Shape Fade

Shape Red

0~255

Shape Color: Red

Shape Green

0~255

Shape Color: Green

Shape Blue

0~255

Shape Color: Blue

Shape White

0~255

Shape Color: White

ForeColor

0~255

Shpae: ForeColor Dimmer

Dimmer

BackColor

0~255

Shape: BackColor Dimmer

Dimmer

Shape Transition

0~255

Shape Transition

Shape Effect Auto Mode, back

Shape Offset

0~255

several steps and continue auto

run

0~25

Empty

Reset

26~76

Effect Motor Reset (5 sec.)

77~127

XY Motor Reset (5 sec.)

128~255

All Reset (5 sec.)
