FACSIMILE EQUIPMENT

PARTS REFERENCE LIST

MODEL: MFC860

(For Germany / United Kingdom / France

Norway / Belgium / Netherlands /

Switzerland / Ireland / Denmark / Austria /

Spain / Italy / Sweden )

©Copyright Brother 2000

No part of this publication may be reproduced in any form

or by any means without permission in writing from the

publisher.

Specifications are subject to change without prior notice.

NOTES FOR USING THIS PARTS REFERENCE LIST

1. In the case of ordering parts, it needs mentioning the following items:

(1) Code

(2) Q' ty

(3) Description

Note: No orders without Parts Code or Tool No. can be accepted.

[Example] (1) (2) (3)

REF.NO. CODE Q' TY DESCRIPTION REMARKS

2. Parts change will be informed by the technical information.

COUNTRIES

GERMANY ----- GER

UNITED KINGDOM ----- UK

FRANCE ---- FRA

NOEWAY ---- NOR

BELGIUM ---- BEL

NETHERLANDS ---- NLD

SWITZERLAND ---- CHE

IRELAND ---- IRE

DENMARK ---- DEN

AUSTRIA ---- AUT

SPAIN ---- SPA

ITALY ---- ITA

SWEDEN ---- SWE

LIST 1(ADF)

REF No. CODE Q'TY DESCRIPTION REMARKS

1LE3857001 1ADF UNIT

1-1 UG6609001 1DOCUMENT SENSOR PCB ASSY

1-2 LG2926001 1DOCUMENT SENSOR HARNESS

1-3 UF7026001 1DOCUMENT FRONT SENSOR ACTUATOR

1-4 LE2008001 1DOCUMENT REAR SENSOR ACTUATOR

1-5 LE2011001 1COMPRESSION SPRING

1-6 LE2551001 1RUBBER HOLDER

1-7 UU2055001 1SEPARATION RUBBER

1-8 LE2550001 1SPRING PLATE A

1-9 LE2470001 1ADF FILM

1-10 UF6116001 1TAPTITE, PAN B M3X6

1-11 UF9009001 2PRESSURE ROLLER

1-12 LE2471001 1PRESSURE ROLLER SHAFT

1-13 LE2472001 2PRESSURE ROLLER SPRING

1-14 LE2566001 1ADF MOTOR

1-15 LG2015001 1ADF MOTOR HARNESS

1-16 0A4300605 2SCREW, PAN (S/P WASHER) M3X6

1-17 LG2016001 1GROUNDING WIRE

1-18 087310815 2 TAPTITE, CUP B M3X8

1-19 LE2026001 1UPPER LF ROLLER(GRAY)

1-20 UF8105001 3CONDUCTIVE BUSHING

1-21 UU7039001 4LF ROLLER GEAR 27

1-22 LE2029001 1LOWER LF ROLLER(BLACK)

1-23 LE2028001 1DOCUMENT EJECTION ROLLER

1-24 LE2030001 1WHITE ROLLER

1-25 LE2032001 2WHITE ROLLER BUSHING

1-26 LE2033001 2SPRING

1-27 LE2919001 1DOCUMENT FEED ROLLER ASSY

(1-27-1) LE2037001 2DOCUMENT FEED ROLLER(RUBBER)

1-28 UU1290001 4PAWLED BUSHING

1-29 UU7505001 1ANTI-STATIC BRUSH

1-30 087320616 3 TAPTITE, CUP S M3X6

1-31 UF0208001 1ARM

1-32 LE2048001 1DOCUMENT EJECTION CHUTE ASSY

1-32-1 LE2582001 2PINCH ROLLER

1-32-2 UU2009001 2PINCH ROLLER SHAFT(SPRING)

1-33 LE2050001 1ADF SIDE COVER F, WHITE(1495)

1-34 LE2051001 1ADF SIDE COVER R, WHITE(1495)

1-35 LE2534001 1ADF COVER ASSY, WHITE(1495)

1-36 087320816 2 TAPTITE, CUP S M3X8

2UF8088001 1PLASTIC RETAINING RING

3LE2053001 2ADF SUPPORT

4 087310816 2 TAPTITE, CUP B M3X8

5LE3426001 1DOCUMENT CHUTE ASSY

6LE2487001 1SPONGE

7LE2056001 1DOCUMENT TRAY

8 087320816 1 TAPTITE, CUP S M3X8

9LE2567001 2HINGE A

10 087311017 6 TAPTITE, CUP B M3X10

11 LE2568001 2HINGE HOLDER A

12 LE2777001 1DOCUMENT SUPPORT, WHITE(1495)

13 LE2498001 1COLOR MARK

MFC860

LIST 2(SCANNER)

REF No. CODE Q'TY DESCRIPTION REMARKS

1LE3763001 1SCANNER UNIT (SP)

1-1 LE3338001 1CCD MOTOR

1-2 0A4300605 2SCREW, PAN (S/P WASHER) M3X6

1-3 LG2776001 1PANEL-MAIN HARNESS

1-4 LE3417001 1CCD IDOL PULLEY HOLDER

1-5 LE3764001 1CCD UNIT (SP)

1-6 LE3951001 1CCD FLAT CABLE BY4

1-7 LE3423001 1CCD DRIVE BELT

1-8 LE2082001 1CCD LOCK

1-9 LE2079001 1SPRING

1-10 LE2098001 2HINGE PLATE

1-11 085411216 4 TAPTITE, BIND B M4X12

1-12 087310815 10 TAPTITE, CUP B M3X8

1-13 LE2805001 2TAPTITE, PAN B M3X10

1-14 087411216 4 TAPTITE, CUP B M4X12

1-15 LG2018001 1SCANNER OPEN SENSOR PCB ASSY

1-16 LG2137001 1COVER SENSOR HARNESS

1-17 087310815 2 TAPTITE, CUP B M3X8

1-18 LE2542001 1CORE STOPPER

1-19 LG2020001 1FLAT CORE

2LE2095001 1OPEN SENSOR ACTUATOR

3LE3500001 1HARNESS SUPPORT

4LG2737001 1FB COVER SWITCH ASSY

5LE0832001 1TAPTITE, PAN P 1.6X8

6 087310816 1 TAPTITE, CUP B M3X8

7LG2020001 1FLAT CORE

8 087310815 1 TAPTITE, CUP B M3X8

9LE2808001 1CCD LOCK LABEL

MFC860

LIST 3(MAIN FRAME)

REF No.

CODE

Q'TY

DESCRIPTION

REMARKS

LE3132001

PURGE GEAR 18

LE3133001

PURGE GEAR 19

LE3134001

PURGE BEVEL GEAR 18

LE3135001

GEAR STOPPER

LE3136001

PURGE GEAR SPRING

LE3939001

CARRIAGE MOTOR

LE3142001

CARRIAGE ASSY

7-1

UU1061001

CARRIAGE PRESSER

7-2

UU1062001

PRESSER SPRING

LE3166001

ECCENTRIC BEARING L

LE3167001

ECCENTRIC BEARING R

0A5300605

SCREW, PAN (S/P WASHER) M3X6

UU1080001

REEL PRESSURE SPRING

UU1454001

CARRIAGE TIMING BELT

LE3169001

IDLE PULLEY HOLDER

LE3170001

IDLE PULLEY

UD6025001

IDLE PULLEY SHAFT

LE3171001

SPRING

LE3172001

ENCODER STRIP

UD6012001

ENCODER STRIP SPRING

LG2606001

HEAD FLAT CABLE 2, (23-PIN)

LG2605001

HEAD FLAT CABLE 1, (22-PIN)

LE3175001

IDLE PULLEY STOPPER

LE3178001

PURGE LEVER

LE3179001

PURGE LEVER SPRING

LE3180001

PURGE SHAFT

UU1088001

FFC HOLDER 1

LE3176001

FFC HOLDER 2

LE3183001

PAPER FEED ROLLER ASSY

048080345

RETAINING RING, E8

LE3187001

PF ROLLER PULLEY L

LE3188001

PAPER EJECTION ROLLER

LE3190001

EJECTION ROLLER PULLEY

UF0026001

PAWLED BUSHING

UF8105001

BUSHING

048050345

RETAINING RING, E5

LE3191001

PF TIMING BELT S

LE3195001

PAPER PRESSURE HOLDER

LE3198001

SPRING

LE3201001

PAPER FEED MOTOR

0A4300605

SCREW, PAN (S/P WASHER) M3X6

LE3207001

PF TIMING BELT L

LE3208001

TENSION PLATE

LE3600001

SPRING, EXTENSION 4.2X10

LG2597001

CARRIAGE PCB ASSY

087310616

TAPTITE, CUP S M3X6

UG5569000

FLAT CORE 33.5-12

LE3911001

PLATEN

US2967001

STAR WHEEL

LE3606001

STAR WHEEL SPRING

LE3881001

STAR WHEEL RETAINER

087320515

TAPTITE, CUP S M3X5

LE3347001

LOWER PAPER CHUTE ASSY

51-1

UG6609001

PAPER EJECTION/CASSETTE SENSOR PCB ASSY

51-2

LG2827001

PAPER EJECTION/CASSETTE SENSOR HARNESS

51-3

LE3349001

PAPER EJECTION SENSOR ACTUATOR

51-4

LE2120001

CASSETTE SENSOR ACTUATOR

51-5

UD4336001

ACTUATOR SPRING

51-6

LE2491001

ANTI-STATIC BRUSH

087320616

TAPTITE, CUP S M3X6

UF7010000

GEAR 45

UF8034001

GEAR 39

048060345

RETAINING RING, E6

LE3355001

PAPER FEED SHAFT ASSY

LE2225001

GEAR M0.5/25

LE2226001

ONE WAY ARM ASSY

UF8105001

CONDUCTIVE BUSHING

048050345

RETAINING RING, E5

UF5519000

LF ROLLER GEAR

087320515

TAPTITE, CUP S M3X5

LK0220001

0.1

PRINT HEAD UNIT(INCLUDING 10 PAIRS OF UNITS)

LK0610001

PRINT HEAD UNIT (INCLUDING 1 PAIR OF UNIT)

63-1

LK0198001

MANIFOLD CAP S

63-2

LK0199001

NOZZLE PROTECTOR

LE3182001

MANIFOLD CAP L

MFC860

LIST 3(MAIN FRAME)

REF No.

CODE

Q'TY

DESCRIPTION

REMARKS

LE3155001

HEAD DRIVER CLAMP L

LE3158001

HEAD DRIVER CLAMP R

LE3162001

INK CARTRIDGE GUIDE

MFC860
