BT PARAGON 200 PLUS Bedienungsanleitung

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

This product is intended

for connection to analogue

public switched telephone

networks and private

switchboards in the United

Kingdom.

Paragon 200 Plus

Digital Telephone Answering Machine

User

Guide

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

Please open this page for an ‘at a glance’

guide to your Paragon 200 Plus.

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

Please open this page for a further

‘at a glance’ guide to your Paragon 200 Plus.

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

Paragon 200 Plus

Sel

Vol

Del

memo

Answer

on off Play

123

456

789

Redial

At a glance

Display

Shows the number of

messages and status information,

e.g. battery low indication.

Vol

Adjusts the volume of the

loudspeaker when playing back

messages and memos.

Del

Deletes messages.

Message and Ring indicator

Answer On/Off

Switches the answering machine

on and off. Also lets you set it to

answer only. Play/Memo

Plays back messages. Also used to

record memo messages.

 

Lets you skip forwards or backwards

through your messages during playback.

Used to select setup options.

Allows you to change the display contrast.

Inductive coupler

In the handset.

Sel

Lets you select the function you

want from the range of options.

Directory label

Secrecy

Allows you to talk to someone close

by without the person on the other

end of the line hearing your

conversation.

M -M3 One-touch buttons

Store/dial any one of your 3 most

used numbers at the touch of a

single button.

Quickdial

Lets you store and dial up to

10 numbers by pressing just

two buttons.

Redial/Pause

Redial the last number called.

Also lets you enter a pause when

storing numbers in the memory.

Recall

For use when connected to a

switchboard, or for BT Select

Services.

Microphone

For recording memos and

your outgoing message.

Confirms the setting you want.

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

CAUTION

DISCONNECT

FROM PHONE

LINE BEFORE

REPLACING

BATTERY

P

T

9V DC

LINE

HANDSET

MODE

Back up battery compartment

Takes one LR61 battery

(not supplied).

9V power socket

Mode switch

Default TB

Telephone line cord socket

Handset socket

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

In this guide

At a glance 1

Introduction 4

For your records 4

Unpacking your Paragon 200 Plus 4

Safety information 5

Setting up 6

Plan the location of your

Paragon 200 Plus 6

Using the telephone 10

Using the Inductive oupler 10

Making and ending calls 10

Using the one-touch buttons 11

Using the quickdial memory 12

Using the answering machine 13

Selecting the answering machine mode 13

To use the pre-recorded

outgoing message 13

Message and Ring indicator 15

To use aller Return (Auto 1471) 16

Using Remote Access 16

Optional settings 18

elp 20

General information 21

Guarantee 21

Technical information 22

Wall-mounting template 23

Index 25

Note

There is a detailed Index at the back of this guide, see page 25.

Note

In this user guide, we have included helpful

tips and useful notes. They are shown in a

white box like this.

Paragon200 Plus

Sel

Vol

Del

memo

Answer

on off

Play

123

456

789

Redial

Unpacking your Paragon 200 Plus

If anything is missing, please contact your place

of purchase immediately.

●Paragon 200 Plus telephone

answering machine.

●Handset and cord.

●Plug mounted, 13 amp mains

adaptor.

●Line cord.

●Wall mounting plugs and screws.

●Plinth for desk mounting

●Remote access card.

Spare memory label.

You can expect your Paragon 200 Plus to give

you many years of trouble-free service.

Please read the instructions carefully before use

and keep this User Guide for future reference.

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

For your records

For guarantee purposes, proof of purchase is

required, so please keep your receipt.

Enter your PIN here

See page 17 for more information about your PIN.

Date of purchase:

Place of purchase:

Serial number (on the underside of the telephone base):

Purchase price:

Introduction

Your Paragon 200 Plus has been designed for ease of use and

made to the high standards set by T.

INTRODUCTION

Remote access menu

Press to:

Play messages.

Skip back to previous

message.

Delete the message being

played (or delete all messages

at the end of play back .

Skip forward to the next

message.

Skip outgoing message

(OGM.

Operating your Paragon 200

Plus from another telephone

To switch the answering machine ON:

•Dial your phone number.

•Let the phone ring for 20 rings.

Your outgoing message begins to play.

Your Paragon 200 Plus is now on and

you may hang up.

To access the answering machine menu:

•Press and release the button during

the outgoing message.

•Enter your security code.

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

Safety information

General

Only use the power supply included with

the product. Using an unauthorised power

supply will invalidate your guarantee and

may damage the telephone.

The item number for the power supply is

872067.

Do not open the Paragon 200 Plus. This

could expose you to high voltages or other

risks. Contact the Helpline for all repairs.

Cleaning

Simply clean your Paragon 200 Plus with a

damp (not wet) cloth, or an anti-static wipe.

Never use household polish as this may

damage the product.

Never use a dry cloth as this may cause

static shock.

Environmental

Do not expose to direct sunlight.

We recommend that you do not place the

product on antique/veneered wood to avoid

damage.

Do not stand your product on carpets or

other surfaces which generate fibres, or place

it in locations preventing free flow of air over

its surfaces.

Do not submerge any part of your product

in water and do not use it in damp or humid

conditions, such as in bathrooms.

Do not expose your product to fire, explosive

or other hazardous conditions.

There is a slight chance that your phone

could be damaged by an electrical storm.

We recommend that you unplug the power

and telephone line cord for the duration of

the storm.

SAF TY INFORMATION

Plan the location of your

Paragon 200 Plus

Situate your Paragon 200 Plus close enough to

both the phone and mains power sockets so that

the cables will reach.

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

Setting up

Follow these steps to set up your Paragon 200 Plus

ready for use.

S TTING UP

LINE

HAN SET

2Connect handset cord to base

Note

If you require accessories or DIY telephone

extension kits, please phone our Accessories line

on 0870 240 5522. This is a chargeable service.

1Check Dial Mode setting (default T )

Use the dialling mode switch on the underside

of your Paragon 200 Plus.

Your Paragon 200 Plus should be pre-set to TB

which gives you Tone dialling. This ensures the

phone will work with all modern digital

exchanges.

P

T

HAN SET

MO E

If you do not get a dialling tone, try setting the

dialling mode to P.

If you are connecting to a switchboard, check

with your switchboard operator or

communications manager which dialling mode

you need. Your Paragon 200 Plus is approved for

all compatible switchboards.

Paragon 200 Plus ~ 4th Edition ~ 25.02.03 ~ 4983

S TTING UP

3Plug the mains adaptor cord into the

back of the telephone

CAUTION

ISCONNECT

9V C

LINE

The Paragon 200 Plus automatically goes

through a start-up process during which the

display shows init, and both the secrecy LED

and message indicator flash once.

On completion the unit will beep and the display

will show the number of messages.

Your Paragon 200 Plus is now ready to record

messages.

4Plug the mains adaptor into the wall

socket and switch on

Note

Your machine automatically adds the time and

day to each incoming message recorded.

5Insert back-up battery

Although optional we recommend fitting an

alkaline battery which will provide up to 25 hours

back-up and ensure your messages are saved

in the event of a mains power failure.

Ensure the Paragon 200 Plus is disconnected

from the telephone line.

To fit the battery.

1Lift the cover.

2Insert one new LR61 9V battery (not

supplied) on top of the red ribbon.

Battery low warning

The display indicates when the battery power is low.

If no battery is inserted, it remains on the display.
