User Manual

CloudStor

CS-WX/1D and CS-WV/1D

www.buffalotech.com v1.4

™

Introduction

Thank you for purchasing the Buffalo CloudStor. This simple device gives you the exibility

of cloud-based storage without the worries that come with storing your important data

on someone else’s servers. Using Pogoplug software, the CloudStor lets you serve up les,

photos, and multimedia over the Web to any of your devices, wherever you may be.

Turn to page 4 to set up your CloudStor.

Because we’re constantly updating our products, the images and text in this manual may vary

slightly from the images and text displayed by your CloudStor. As time passes, future user

interfaces, updated software, and later versions of this manual may be available for download

from www.buffalotech.com. For more information on CloudStor, see buffalocloudstor.com.

Table of Contents

Introduction

Setup 4

Diagrams and Layout 7

Power Mode Switch 10

Using your CloudStor

Uploading 12

Downloading 13

Pogoplug Applications 14

Sharing 15

Search 18

Slideshows 19

Creating New Folders 20

Renaming Files and Folders 21

Renaming Devices 22

Active Copy 23

Settings and Conguration

General Settings 24

Social Settings 25

Media Settings 27

Security Settings 29

Upload Settings 30

Adding a Printer 31

Device Settings 34

Local Settings 35

Adding a Second Drive 38

Time Machine 40

BitTorrent Client 44

Direct Copy 46

Troubleshooting

Status LED Flash Codes 47

Appendix

Specications 49

Contact Information (USA) 50

Contact Information (Europe) 51

GPL Information 52

Open a browser window on your computer and go to https://mycloudstor.com/. Click Set Up

Your CloudStor.

Plug one end of the included Ethernet cable into the Ethernet port on your CloudStor and the

other end into any available LAN port on your router.

In the browser window, click Next.

Setup

USB

FUNCTION

AUTO

OFF

DC-IN

LAN

WAN

LAN LAN

Now, plug your CloudStor into a surge protector, wall socket, or power strip.

Move the power mode switch on the back of the unit to the on (middle) position. The blue power

LED will begin to blink.

Wait for the CloudStor to boot. This will take about 5 minutes. When the power LED on the

front panel stops blinking and glows steadily, the unit has nished booting. The Info/Error LED

should not be blinking. If it is, turn to the next page to troubleshoot.

In the browser window, click Next. Follow the instructions on the screen to nish installing your

CloudStor.

USB

FUNCTION

AUTO

OFF

DC-IN

LAN

If you’ve connected your CloudStor to a power source and to a router, but the Info/Error LED

is ashing amber or your CloudStor suddenly turned off by itself, here are some things you can

check:

Is the power mode switch on the back of the CloudStor in the On position? If it’s in the Auto

(top) position, the CloudStor may suddenly shut down after a few minutes. Move it to the On

(bottom) position until you’ve installed NAS Navigator software on your computers.

Is the Info/Error LED on the front of your CloudStor ashing amber? Check the following:

Is the Ethernet cable connected to your CloudStor and to your router?

Is your router turned on?

Is your router congured to automatically assign IP addresses (DHCP)?

Do you have a rewall installed that blocks UDP, or is UDP disabled on your router?

If you have veried all of the above and the Info/Error LED on the front of your CloudStor is

still ashing, please move the power mode switch to the Off position, wait until the Power LED

turns off, and then move it back to the On position. It will take several minutes to boot.

If you continue to have problems, please contact tech support. Tech support contact

information is available on pages 50 and 51.

Troubleshooting

Back Panel Layout

Front

Power LED

Function LED

Info/Error LED

Front Cover

(pull straight

toward you to

remove)

Back Panel Layout

Front Panel Removed

Spare drive bay

for optional 2nd

drive

Main hard drive

Press tab to

release drive

Front Panel Layout

Rear

Function Button

USB

Fan

Auto Power

Power On

Power Off

Ethernet

(to router)

Power

Socket for

Kensington-style lock

Power cord

stress relief

The “Power Mode” switch on the back of the

unit has three positions: Auto, On, and Off.

The Auto position automatically powers the

unit on or off with your PC. If your PC is turned

on the CloudStor will power up; if the PC is

turned off the CloudStor will power down.

You must have installed the NAS Navigator

software (available from www.buffalotech.com)

on your PC for this feature to work. Otherwise,

if you move the switch to Auto, your unit will

power down by itself and you will have to

manually turn it back on.

Move the switch to the On (middle) position to

have the CloudStor turn on and stay on.

To turn off the CloudStor, move the switch to

the Off position. It will take several minutes to

fully shut down. Do not unplug the unit until

shutdown is complete and the power LED is no

longer lit.

Power Mode Switch

Power

Mode
