Buffalo HD-CELU2 DRIVESTATION Bedienungsanleitung

User Manual

HD-CELU2 DriveStation FlexNet

www.buffalotech.com v1.1

Introduction

The DriveStation FlexNet is a exible, easy to use hard drive. It can work as either a

standard external USB hard drive, or as a network attached storage device, accessible to

many computers at once. This user manual is intended to assist you in conguring it.

Because we’re constantly updating our products, the images and text in this manual may

vary slightly from the images and text displayed by your DriveStation FlexNet. These changes

are minor and should not affect the ease of setup adversely. As time passes, future user

interfaces, updated software, and later versions of this manual may be freely available for

download at our web site www.buffalotech.com.

For best results, attach the DriveStation FlexNet to an uninterruptable power supply (UPS).

Back up all your stored les regularly.

Package Contents: DriveStation USB/LAN Hard Drive

USB Cable

Ethernet Cable

Power Adaptor

DriveNavigator CD

Quick Setup Guide

Warranty Statement

Table of Contents

Front Panel Layout ........................................................................ 4

Back Panel Layout ......................................................................... 5

Installation .................................................................................... 6

LAN Mode ...................................................................................... 8

USB Mode...................................................................................... 9

Web Admin Tool........................................................................... 10

Network Settings.......................................................................... 13

Sleep Mode .................................................................................. 14

Disk Management........................................................................ 15

Security ....................................................................................... 16

Maintenance................................................................................ 17

Notes ........................................................................................... 19

Technical Specications............................................................... 20

Contact Information (USA) ........................................................... 21

Contact Information (Europe) ...................................................... 22

Front Panel Layout

Note: The DriveStation

FlexNet can be connected

to a computer as both an

Ethernet NAS and a USB

external hard drive at the

same time. To switch

between the two modes,

hold down the mode button

for a few seconds and then

release it.

Power LED

Mode Button/LED

Red - USB mode

Green - LAN mode

Back Panel Layout

Reset button

Ethernet (to router)

Power

USB (to PC)

Power button

Insert the installation CD into your PC’s CD-ROM

drive. Setup will automatically launch. Click on Begin

Installation button.

Installation

Click Install.

The wizard will guide you through installation. First, you’ll

install the DriveStation FlexNet as a USB device. Then,

you’ll switch modes and install the DriveStation FlexNet in

LAN mode as a NAS device. Follow the directions on each

screen and continue pressing Next to step through the

installation.

When installation is complete, you may close the installation

window.

In LAN mode, the mode button will glow green. If it’s red, hold it in

for a few seconds, and then release it. The LED will change to green.

After running the installation wizard, this icon will be on your

desktop: BrowseHD-CEL.

In LAN mode, clicking BrowseHD-CEL takes you directly to the main

folder on your DriveStation FlexNet.

Using your DriveStation FlexNet in LAN Mode

Using your DriveStation FlexNet in USB Mode

In USB mode, the mode button will glow red. If it’s green, hold it in

for a few seconds, and then release it. The LED will change to red.

In USB mode, the DriveStation functions as a normal external USB

hard drive. It can be accessed from My Computer. By default, it will

receive the next available drive letter and will be named HD-CELU2.

Web Administration Tool

The Web Admin tool may be accessed by typing the IP address of

your DriveStation FlexNet into the URL bar of a browser running

on a computer connected to the same network as the DriveStation

FlexNet.

Or, from your DriveNavigator CD, click Options.

Choose Browse settings page to open the Web Admin tool.
