Burmester 175 Bedienungsanleitung
OWNER’S MANUAL
175 TURNTABLE
REFERENCE LINE
.....................................................
Symbols and markups used .........................................................5
Meaning of warning symbols and words ..............................................5
.........................................
The record player ..................................................................8
Rear panel of the record player ......................................................9
Tonearm .........................................................................10
Power supply unit .................................................................11
Back panel of the power supply unit .................................................12
...........................................
...............................................
Switch phase .....................................................................14
Adjust the impedance to the cartridge................................................14
Set up anti-skating ................................................................15
Adjust the colour of the Power LEDs .................................................16
Set automatic shutdown ...........................................................16
Turning the record player on and off .................................................17
Set speed ........................................................................18
Lift and lower the tone arm .........................................................18
Play a record .....................................................................19
............................................................
...........................................................
About this device
4
After more than 35 years of experience in the processing of nest audio signals,
Burmester now crowns its series of successful phono preampliers with a turntable.
Recognizable as a typical Burmester even from the very rst glance, the 175 turntable
makes use of characteristic design elements of the Reference Line. The integrated
signal processing derived from the Burmester 100 phono pre-amplier processes the
ne phono signals at the highest level.
The 175 turntable is driven by four motors located in the outer square around the sub-
platter. This squaring of the circle and the use of multiple belts ensures that no irregular
tension arises on the central bearing. The two-fold design of this arrangement shortens
the ramp-up time and improves synchronization. This simultaneously results in an
improved sound and a fast starting time for the drive.
Alongside the mechanical system and the arrangement of the drive components, the
control electronics and the motors are also crucial for a great audio experience. The AC
synchronous motors used are driven by digital motor electronics which perform their
task with a high-precision oscillator and perfect sine and cosine voltages. The
electronics are completely immune to uctuations in the mains voltage frequency. Due
to the high level of efciency of the electronics, driver stages and motors, the entire
unit remains cool and free from heat-related impairments.
• Digital motor electronics with high level of efciency
• Chassis from a massive aluminium block
• Multi-layer carbon arm tube
• Length of pick-up arm: 9 inches
• Exclusive Burmester MC pickup
• Needle: Shibata cut
• Magnetic damper in oor plate for isolation
Dear Music Enthusiast,
congratulations on your selection and thank you for your trust.
You have chosen a product that combines absolute delity and uncompromising
quality with technological innovation and maximum exibility.
Please read through these operating instructions at least once before initially installing
the product so you can fully benet from all the functions of this truly high-delity
device. Should any of your questions remain unanswered, please contact your
specialist dealer or us directly.
Talk to us about any special requests you may have – even if they seem exceptional. We
love accepting technically feasible challenges.
We wish you many hours of high-delity listening.
The Burmester team
About these operAting instructions
175 Turntable 5
These operating instructions describe the operation of the 175 turntable.
Indicates a prerequisite that must be fullled before a subsequent action can be
carried out.
►
Indicates a single action step.
Indicates a sequence of action steps that must be carried out in the order given.
Indicates the result of an action.
In this document, the following warning messages, symbols and words are used:
The general hazard symbol is used together with the words
CAUTION, WARNING and HAZARD when there is risk of serious
injury. Follow all subsequent
messages to avoid injury or death.
The lightning symbol is used with the warning word HAZARD to
warn of life-threatening electric voltage.
WARNING! The warning word CAUTION indicates a hazard that can lead to
damage of the device.
CAUTION The warning word CAUTION indicates a hazard that present a low
or moderate threat of injury.
WARNING The warning word WARNING indicates a hazard that can lead to
death or serious injury.
HAZARD The warning word HAZARD indicates a hazard that leads
immediately to death or serious injury.
►Read and follow the messages that are given, in particular safety and warning
messages.
►Keep these operating instructions.
importAnt sAfety instructions
6
►Please read the operating instructions for your device fully and keep them.
Note the following points:
• Avoid direct sunlight.
• Avoid excessive heat, cold, humidity and dust.
• Do not expose the record player to any drops or splashes of water and do not put
any container with liquid on the record player.
• The record player is not suitable for use outside.
• Only put the record player on horizontal surfaces that can carry at least 75 kg.
WARNING
Weight of the record player.
►The record player may only be unpacked and installed by a specialist who is used
to handling heavy loads.
►Turn off the amplier you are connecting to before connecting to the record player.
If not used properly, this record player poses many injury risks. Therefore, never leave
your children alone with this device.
If there is a temporary power supply interruption, the record player can switch the
operation mode from ON to STANDBY. This is not an unexpected operation mode
change, but rather to protect the device.
To completely separate the 175 from the power supply, use the easily accessible power
switch on the back of the external power supply unit and then separate the power
cable from the device.
scope of delivery
175 Turntable 7
►Please check the scope of delivery for completeness and damages. Contact you
authorised specialist dealer if parts of the delivery are missing.
• 175 Turntable
• Base plate
• Sub-platter
• 1 set of belts (4 pieces)
• Turntable
• Carbon slipmat
• External power supply unit
• Power cable
• Multi-pole power supply cable
• Burmester Reference Check record
• Operating Instructions
• Catalogue
• Warranty certicate
• Design drawing
overview of the record plAyer
8
12 3 4
5 6 7 8
1
2
3
4
5
6
7
8
overview of the record plAyer
175 Turntable 9
9 10 11 12 13
9
10
11
12
13
overview of the record plAyer
10
161514
17 18 19
14
15
16
17
18
19
