C.E.C. tl53z Bedienungsanleitung
CD PLAYER TL53Z
2
• Introduction ……………………………………………………………………… 2
• Important Safety Instructions …………………………………………………… 4
• Handling Precautions …………………………………………………………… 6
• Compact Disc Handling ………………………………………………………… 8
• Accessories ………………………………………………………………………10
• Front Panel Functions ……………………………………………………………11
• Inside the CD Door ………………………………………………………………13
• Rear Panel Functions ……………………………………………………………14
• Operation …………………………………………………………………………16
• Remote Control Unit ……………………………………………………………18
• Programmed Playback ………………………………………………………… 20
• Precautions on Using the Remote Control Unit ……………………………… 22
• Cautions Regarding Handling ………………………………………………… 23
• Maintenance …………………………………………………………………… 24
• Troubleshooting ……………………………………………………………… 25
• Specications ………………………………………………………………… 26
Contents
Thank you for purchasing the TL53Z.
Please read through and refer to this Owner's Manual to use your TL53Z safely and
adequately. It is recommended that you keep the unit's packaging available for future
transportation needs.
• The TL53Z CD player uses CEC's proprietary belt drive mechanism that minimiz-
es the vibration and electromagnetic noise from the motors, enabling the precise
reproduction of music signals. The top-loading design allows the use of a stabi-
lizer for maximum disc stability.
• The TL53Z uses the Burr Brown "PCM1792" DAC in a left/right-independent
dual/mono configuration with balanced current output. The ΔΣ-Over sampling
setting allows ne adjustment of the sound characteristics (32fs, 64fs,128fs), and
the Digital Filter can be set to 2 different characteristics: "Flat", which offers best
Introduction
Features:
TL53Z User's Manual
3
frequency response and sharp ltering of ultrasonic noise, and "Pulse”, which is
optimized for the best dynamic response.
• The TL53Z uses a newly developed low-jitter crystal oscillator circuit, which forms
the basis for accurate and dynamic playback.
• The cutting-edge version of CEC's proprietary Current-Injection circuit, which
convers the DAC output current into an output voltage without any negative feed-
back circuitry, combined with the TL53Z's unique LEF circuit, offers even more
improvement in sound quality. The analog circuit is basically a balanced design
with an extremely short signal path.
• The TL53Z uses an advanced switching power supply with an integrated AC line
power purier to avoid issues caused by the AC power line. It also has separate
power supplies for its Transport and DAC sections, and independent voltage for its
motor, servo, display, digital and analog circuitries.
CD PLAYER TL53Z
4
Important Safety Instructions
#!54)/.4/2%$5#%4(%2)3+/&%,%#42)#3(/#+
$/./42%-/6%4(%#/6%2/22%!20!.%,)4$/%3
./4#/.4!).!.953%23%26)#%!",%0!2432%&%2
3%26)#).'4/15!,)&)%$3%26)#%0%23/..%,
The lightning ash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to potential electric shock
hazards within the product’s enclosure.
The exclamation point within an equilateral triangle is intended to
notify the user to the presence of important operating and mainte-
nance (servicing) instructions in the accompanying documentation.
WARNING : TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions
5) Do not use the TL53Z near water.
6) Clean only with a dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufac-
turer’s instructions.
8) Do not install the TL53Z near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9) (For USA, Canada: ) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades, with one blade wider
than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the pro-
vided plug does not t your outlet, consult an electrician for replacement of the
obsolete outlet. (For European Countries: ) Do not defeat the safety purpose of
the grounding-type plug. This plug has two poles and a third grounding hole.
The third hole is provided for your safety. If the provided plug does not t your
outlet, consult an electrician for replacement of the obsolete outlet.
TL53Z User's Manual
5
10) Protect the AMP53’s power cord from being walked on or pinched, especially
around the plugs, convenience receptacles, and where it exits the TL53Z’s cas-
ing.
11) Only use attachments/accessories specied by the manufacturer.
12) Only use the TL53Z with a cart, stand, tripod, bracket, or
table specied by the manufacturer or sold with the unit.
If using a cart, exercise caution when moving the cart/
unit combination to avoid injury from it tipping over.
13) Unplug the TL53Z during lightning storms or when leav-
ing it unused for extended periods of time.
14) Refer all servicing to qualied service personnel. Servicing is required when
the TL53Z itself, its power-supply cord, or plug has been damaged in any way,
when liquids have been spilled onto the TL53Z, when foreign objects have
fallen into the TL53Z, when the TL53Z has been exposed to rain or moisture,
when the TL53Z does not operate normally, or when the TL53Z has been
dropped.
• Do not expose the TL53Z to drips or splashes.
• Do not place any objects filled with liquids, such as vases, on the TL53Z.
• Do not install the TL53Z in a confined space, such as within a bookcase or
similar piece of furniture.
• Plug the AC power cord into an easily accessible AC wall outlet, so it can
be quickly unplugged in case of emergency.
CAUTION
• DO NOT REMOVE THE PROTECTIVE HOUSING WITH A SCREWDRIVER.
• USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PRO-
CEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
• IF THE TL53Z SEEMS TO BE MALFUNCTIONING, CONTACT A QUALIFIED
SERVICE STATION. DISCONTINUE USE OF ANY MALFUCTIONING UNIT.
AC POWER CORD CONNECTION
CAUTION:
TO PR EVE NT E LECTR IC SHOCK, MATC H THE BLADE
WIDTH OF THE PLUG TO THE SLOT WIDTH. THE PLUG
MUST BE FULLY INSERTED TO THE SLOT.
For CANADA
CD PLAYER TL53Z
6
1. Connecting Other Devices
Unplug the TL53Z's AC power cord from the outlet before connecting or discon-
necting other devices. Exercise caution when handling the AC power cord. When
disconnecting the AC cord from a socket, make sure you pull the plug, and not the
cord itself.
2. Turning Power On/Off
Your system components should be turned on/off in the following order to avoid
generating noise from your speakers and damaging the speakers themselves or other
devices:
Turning power on: Turn on the TL53Z's power rst, before turning on the amplier
connected to the TL53Z.
Turning power off: Turn off the amplier's power rst, before turning off the
TL53Z.
3.Optical Semiconductor Laser Pickup
The optical pickup is one of the important components that determine the perfor-
mance of a CD player. Never touch the optical lens of the pickup with your ngers,
etc. Close the CD door to keep the lens clean when not in use.
4. CD Stabilizer
Only use the provided CD stabilizer with the TL53Z. Commercially available stabi-
lizers may cause the unit to malfunction.
5. Handle With Care
Avoid exerting excessive force on the knobs, the cabinet and the CD-turntable on
the TL53Z.
6. Installation
Use of an audio rack is recommended to maximize the sound quality and perfor-
mance of the TL53Z. Installation and use of the TL53Z in the locations described
below may cause deterioration in sound quality or malfunction:
• Locations exposed to direct sunlight, such as windowsills, and other exceptionally
warm locations, such as near heating appliances (surrounding temperature higher
Handling Precautions
TL53Z User's Manual
7
than 35 °C), or exceptionally cold locations (surrounding temperature lower than
10 °C), may prevent the TL53Z from functioning adequately.
• Damp locations exceeding 90% humidity may cause the TL53Z's metal parts to
rust, causing the unit to malfunction.
• Dusty locations may cause the TL53Z to malfunction. The accumulation of dust
inside the CD door may lower the performance of music signal reading. It may
also cause contact failure of the switches, and/or noise.
• Otherwise, avoid installing the TL53Z close to other transformers and electrical
motors, so as to prevent the pickup of induction hum. Also, avoid mounting the
unit on surfaces that may be affected by vibration.
7. Avoid lightning strikes
Disconnect the AC power cord from the AC outlet when there is a thunderstorm in
your vicinity.
8. Condensation
When the TL53Z is brought into a warm room when the exterior temperature is cold,
or when the room temperature rises sharply from using a heater, condensation may
form both inside and outside the unit, hampering its performance. If this happens,
leave the TL53Z unused in the room for 1 to 2 hours (depending on the amount of
condensation), so as to bring the unit's temperature closer to the room temperature.
The condensation should go away gradually.
9. Listening etiquette
When adjusting the sound volume level, make sure you do not disturb other people
and your neighborhood.
CD PLAYER TL53Z
8
Compact Disc Handling
• Since a compact disc can be played or recorded only on one side, discs should al-
ways be placed on the turntable with the label side up.
• When taking a compact disc from its case, lift it out by holding the edge of the disc
while pressing down on the center button of the case.
• Handle compact discs with care so as not to scratch their surfaces. Scratches, n-
gerprints or soiling may cause reading errors during playback.
• If a compact disc's surface becomes soiled, wipe it directly away from the disc's
center with a soft, dry cloth. Try to keep the discs clean at all times.
• Never use chemicals such as record sprays, anti-static sprays, benzene or thinner to
clean a disc. These may corrode the surface of a disc.
• Do not place discs in any locations subject to high temperatures and high humidity,
or that receive direct sunlight. Keep discs away from radiators and electrical heat-
ers. CD-R and CD/RW discs are especially sensitive to ultraviolet rays, so keep
TL53Z User's Manual
9
them out of direct sunlight.
• To avoid dust and scratching or warping of discs that could cause reading errors,
replace discs in their cases after use.
• Do not attach any labels on a disc surfaces. Do not use discs that have Scotch
tape, labels, excessive label glue exposed on the surface. These may cause the the
TL53Z to malfunction.
• Do not use cracked discs or an irregularly shaped discs (octagonal, heart-shaped,
or any other special shapes). These may cause the unit to malfunction.
• The TL53Z is able to playback CD-R/RW discs recorded in audio CD format and
finalized. Some CD-R/RW discs may be unplayable due to the quality of the
CD-R/RW disc and/or the quality of the recording.
• Do not attach stickers or protective seals on discs and do not use any protective
coating sprays. If you wish to label a disc, only write on the label side using soft-
tipped insoluble pens. Never use ballpoint pens or hard-tipped pens.
• Copy-protected discs and nonstandard discs may not be playable with this player. If
you experience any problems with non-standard discs, contact the manufacturer of
the disc rst.
CD-R/RW DISC
NONSTANDARD DISC
CD PLAYER TL53Z
10
The packaging for the TL53Z should contain the following:
1. TL53Z unit
2. Stabilizer
3. AC power cord
4. Remote control unit
5. Two AA batteries for the remote control unit
6. Owner's Manual
Note: Keep the packaging available for future transportation needs.
The AC power cord is for use with the TL53Z exclusively, and should not be used for
other devices.
210
-%3
BELT DRIVE CD PLAYER
取扱説明書
210
Accessories
