Cabletron Systems 9E133-36 Bedienungsanleitung

SmartSwitch 9000

9E132-15, 9E133-36

9E138-12 & 9E138-36

User’s Guide

9031173-02

Notice

Cabletron Systems reserves the right to make changes in speciﬁcations and other information

contained in this document without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT,

SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED

TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION

CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Cabletron Systems, Inc.

35 Industrial Way

Rochester, NH 03867-5005

Printed in the United States of America

Order Number: 9031173-02

LANVIEW

is a registered trademark, and

SmartSwitch

is a trademark of Cabletron Systems, Inc.

CompuServe

is a registered trademark of CompuServe, Inc.

i960 microprocessor

is a registered trademark of Intel Corp.

Ethernet

is a trademark of Xerox Corporation.

Notice

FCC Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment uses, generates, and can radiate radio frequency energy and if not installed in

accordance with the operator’s manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause interference in which case the user

will be required to correct the interference at his own expense.

WARNING:

Changes or modiﬁcations made to this device which are not expressly approved by the

party responsible for compliance could void the user’s authority to operate the equipment.

VCCI Notice

This is a Class A product based on the standard of the Voluntary Control Council for Interference by

Information Technology Equipment (VCCI). If this equipment is used in a domestic environment,

radio disturbance may arise. When such trouble occurs, the user may be required to take corrective

actions.

DOC Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques de la class Aprescrites dans le Règlement sur le brouillage radioélectrique

édicté par le ministère des Communications du Canada.

iii

Notice

DECLARATION OF CONFORMITY

ADDENDUM

Application of Council Directive(s):

89/336/EEC

73/23/EEC

Manufacturer’s Name:

Cabletron Systems, Inc.

Manufacturer’s Address:

35 Industrial Way

PO Box 5005

Rochester, NH 03867

European Representative Name:

Mr. J. Solari

European Representative Address:

Cabletron Systems Limited

Nexus House, Newbury Business Park

London Road, Newbury

Berkshire RG13 2PZ, England

Conformance to Directive(s)/Product Standards:

EC Directive 89/336/EEC

EC Directive 73/23/EEC

EN 55022

EN 50082-1

EN 60950

Equipment Type/Environment:

Networking Equipment, for use in a

Commercial or Light

Industrial Environment.

We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with

this notice conforms to the above directives.

Manufacturer Legal Representative in Europe

Mr. Ronald Fotino Mr. J. Solari

____________________________________________________ ______________________________________________________

Full Name Full Name

Principal Compliance Engineer Managing Director - E.M.E.A.

____________________________________________________ ______________________________________________________

Title Title

Rochester, NH, USA Newbury, Berkshire, England

____________________________________________________ ______________________________________________________

Location Location

Notice

Contents

Chapter 1 Introduction

Features...........................................................................................................................1-1

Related Manuals............................................................................................................1-4

Getting Help .................................................................................................................. 1-4

Chapter 2 Installing the Modules

Installing EPIMs............................................................................................................2-3

EPIM Revisions ...................................................................................................... 2-3

Installing the EPIM................................................................................................2-4

The Reset Switch ........................................................................................................... 2-5

User-Accessible Components......................................................................................2-6

Setting the Module Card DIP Switch.........................................................................2-7

Chapter 3 Operation

Flexible Network Bus (FNB)........................................................................................3-2

System Management Buses .........................................................................................3-2

SMB-1 Bus...............................................................................................................3-2

SMB-10 Bus.............................................................................................................3-2

System Diagnostic Controller...................................................................................... 3-3

DC/DC Converter ........................................................................................................3-3

FNB Interface.................................................................................................................3-3

i960 Core......................................................................................................................... 3-4

Chapter 4 LANVIEW LEDs

Chapter 5 Speciﬁcations

Safety...............................................................................................................................5-1

Service............................................................................................................................. 5-1

Physical...........................................................................................................................5-2

Dimensions.............................................................................................................5-2

Weight......................................................................................................................5-2

Environment...........................................................................................................5-2

Contents

Appendix A EPIMs

EPIM-T...........................................................................................................................A-1

EPIM-F1 and EPIM-F2.................................................................................................A-2

EPIM-F3.........................................................................................................................A-3

EPIM-C...........................................................................................................................A-5

Connector Type .....................................................................................................A-5

Grounding..............................................................................................................A-5

EPIM-A and EPIM-X (AUI Port)................................................................................A-5

1-1

Chapter 1

Introduction

The 9E132-15, 9E133-36, 9E138-12, and 9E138-36 MicroLAN™ Switch Modules,

shown in Figure 1-1, are four channel Ethernet bridges and routers. Up to three

front panel Ethernet networks can be connected to this module and they can be

bridged/routed to any other Ethernet segment and to any other SmartSwitch

9000 module via the FNB bus (acting as the fourth port).

Features

Processor

The Ethernet MicroLan Switch Modules are equipped with an advanced Intel i960

microprocessor. This microprocessor provides a platform for all management

functions within a scalable RISC-based architecture.

System Management

The Ethernet MicroLan Switch Modules provide interfaces to the two System

Management Buses (SMB-1 and SMB-10) for intermodule management.

Connectivity

The 9E132-15 provides four RJ-45 ports and one EPIM slot for each of the three

channels. See Chapter 5 for information on the use of EPIMs.

The 9E133-36 has one 50-pin front panel for each of the three channels, providing

12 individual Ethernet connections each.

The 9E138-12 provides four ST-type multi-mode ﬁber optic connections for each

of the three channels, for a total of 12 connections.

The 9E132-15, 9E133-36, 9E138-12, and 9E138-36 MicroLAN™ Modules will

be referred to collectively as the Ethernet MicroLan Modules.

NOTE

Introduction

1-2

The 9E138-36 provides 12 ST-type multi-mode ﬁber optic connections for each of

the three channels, for a total of 36 connections.

All ports function as repeaters for incoming data which retime and retransmit all

packets.

Bridging/Routing

The Ethernet MicroLan Switch Modules provide Bridging/Routing between the

front panel channels and/or to any other module in the chassis via FNB -1 or

FNB -2 of the FNB bus. IEEE 802.1d Spanning Tree Protocol is supported in all

bridging functions.

Management Information Base (MIB) Support

All concentrator modules provide MIB support including the following:

• IETF FDDI MIB

• IETF MIB II

• Cabletron Enterprise MIBs

RMON

RMON support (RFC1271).

LANVIEW LEDs

The Ethernet MicroLan Switch Modules use LANVIEW: the Cabletron Systems

built-in visual diagnostic and status monitoring system. With LANVIEW LEDs,

you can quickly identify the device, port, and physical layer status at a glance.

Hot Swapping

The Ethernet MicroLan Switch Modules can be installed or removed from the

chassis while the SmartSwitch 9000 is powered up without affecting the operation

of the remaining modules in the chassis.

For a complete list of supported MIBs, refer to the release notes provided in the

module package.

NOTE
