Cabletron Systems MMAC-Plus 9E312-12 Technisches Dokument

MMAC-Plus

™

Module Local Management

9E312-12 Module Specific Appendix

9031505

DRAFT

Appendix

9E312-12 Module Speciﬁc

Information

Introduction

This appendix contains local management information that is speciﬁc to the 9E312-12

Ethernet Switch Module.

The 9E312-12 Ethernet Switch Module is a 13-port switching module with:

• 12 front panel Ethernet ports

• 1 Internal Network Bus (INB) backplane port

Each port of the 9E312-12 can be conﬁgured to operate in the Full Duplex mode. This

conﬁguration allows each port to provide a full 20 Mbps of bandwidth.

Modifying Fields and User Privileges

To modify ﬁelds on this module, you must have read-write or super-user privileges. If

you have read-only privileges, you can view information; however, you cannot

modify any ﬁelds. For more information about user privileges and community names,

see the

MMAC-Plus Module Local Management User’s Guide.

9E312-12 Module Speciﬁc Information

Module Interface Codes

The 9E312-12 Ethernet Switch Module has 15 interfaces. The table below lists the

identifying number, name, and description of each interface.

Use the numbers listed in Table 1 to conﬁgure the module’s default interface (see the

General Conﬁguration Screen).

Table 1. 9E312-12 Module Interface Codes

Interface

Number

Interface

Name

Interface

Description

1 SMB1 1 Mbps System Management Bus

2 SMB10 10 Mbps System Management Bus

3 INB Internal Network Bus

4 ENET1 Ethernet Front Panel Port 1

5 ENET2 Ethernet Front Panel Port 2

6 ENET3 Ethernet Front Panel Port 3

7 ENET4 Ethernet Front Panel Port 4

8 ENET5 Ethernet Front Panel Port 5

9 ENET6 Ethernet Front Panel Port 6

10 ENET7 Ethernet Front Panel Port 7

11 ENET8 Ethernet Front Panel Port 8

12 ENET9 Ethernet Front Panel Port 9

13 ENET10 Ethernet Front Panel Port 10

14 ENET11 Ethernet Front Panel Port 11

15 ENET12 Ethernet Front Panel Port 12

Appendix

Full Duplex Conﬁguration Screen

The 9E312-12 Full Duplex Conﬁguration Screen displays the port number, operation

mode, link status, and port status of the module’s 12 ports.

Figure 1. 9E312-12 Full Duplex Conﬁguration Screen

MMAC-Plus LOCAL MANAGEMENT

Full Duplex Configuration

Module Name: 9E312-12 Firmware Revision: 01.00.23B

Slot Number: 10 BOOTPROM Revision: 01.00.03

PORT# OPERATION MODE LINK STATUS PORT STATUS

1 STANDARD ENET Link ENABLED

2 STANDARD ENET Link ENABLED

3 STANDARD ENET Link ENABLED

4 STANDARD ENET Link ENABLED

5 STANDARD ENET Link ENABLED

6 STANDARD ENET Link ENABLED

7 STANDARD ENET Link ENABLED

8 STANDARD ENET Link ENABLED

9 STANDARD ENET Link ENABLED

10 STANDARD ENET Link ENABLED

11 STANDARD ENET Link ENABLED

12 STANDARD ENET Link ENABLED

SAVE SET ALL PORTS: FULL RETURN

9E312-12 Module Speciﬁc Information

Full Duplex Conﬁguration Screen Fields

PORT #

(Read-only) - Displays the numbers for each of the Ethernet ports.

OPERATION MODE

(Modiﬁable) - This ﬁeld lets you determine whether the

speciﬁed port will transmit and receive data separately or simultaneously. You can set

this ﬁeld to one of the following values:

• STANDARD ENET - The port can either transmit data or receive data, but not both

at the same time. Therefore, the port is running at 10 Mbps (this is the default).

• FULL DUPLEX - The port can transmit and receive data at the same time.

Therefore, the port is running at 20 Mbps.

To set one Ethernet port to FULL DUPLEX (for example, port 1):

1. Use the arrow keys to highlight

STANDARD ENET

in the OPERATION MODE

ﬁeld (to the right of port 1).

2. Press the

Space

Bar

until

FULL DUPLEX

appears in the ﬁeld.

3. Use the arrow keys to highlight the

SAVE

command on the bottom line of the

screen.

4. Press the

Return

key.

To set all 12 Ethernet ports to FULL DUPLEX:

1. Use the arrow keys to highlight the

SET ALL PORTS

ﬁeld.

2. Press the

Space

Bar

until you see

FULL

3. Use the arrow keys to highlight the

SAVE

command on the bottom line of the

screen.

4. Press the

Return

key.

LINK STATUS

(Read-only) - Indicates whether there is a physical connection from

this port to another 10 Base-T device. One of the following values appears:

• Link - There is a 10 Base-T link signal present; there is a valid physical connection

from this port to another 10 Base-T device.

• No Link - There is no 10 Base-T link signal present; there is no valid physical

connection from this port to another 10 Base-T device.

Appendix

PORT STATUS

(Read-only) - Indicates whether the port has been turned on or off

administratively. You will see one of the following values:

• ENABLED - The port is turned on administratively.

• DISABLED - The port is turned off administratively.

Enable or disable ports from the Bridge Conﬁguration screen.

NOTE

9E312-12 Module Speciﬁc Information

Port Statistics Screen

The 9E312-12 Port Statistics Screen displays information and statistics about the

module’s 12 Ethernet ports.

Figure 2. 9E312-12 Port Statistics Screen

MMAC-Plus LOCAL MANAGEMENT

PORT STATISTICS

Module Name: 9E312-12 Firmware Revision: 01.00.23B

Slot Number: 10 BOOTPROM Revision: 01.00.03

PORT #: 1

OCTETS: 2294091

PACKETS: 8425 LINK STATUS: Link

TOTAL ERRORS: 0

COLLISIONS: 0 PORT TYPE: RJ45

CRC/ALIGNMENT ERRORS: 0

UNDERSIZE PACKETS: 0 PORT STATUS: ENABLED

OVERSIZE PACKETS: 0

FRAGMENTS: 0 APPLICATION: BRIDGING

JABBERS: 0

OPERATION MODE: STANDARD ENET

PORT #: 1RETURN

Appendix

Port Statistics Screen Fields

PORT #

(Read-only) - Indicates the current port for which statistics are displayed.

OCTETS

(Read-only) - Displays the number of bytes transmitted and received.

PACKETS

(Read-only) - Displays the number of frames transmitted and received.

TOTAL ERRORS

(Read-only) - Displays the total number of errors on this port.

COLLISIONS

(Read-only) - Displays the total number of collisions detected on this

port.

CRC/ALIGNMENT ERRORS

(Read-only) - Displays the number of packets with bad

Cyclic Redundancy Checks (CRC) that have been received from the network. The

CRC is a 4-byte ﬁeld in the data packet that ensures that the transmitted data that is

received is the same as the data that was originally sent. Alignment errors are due to

misaligned packets.

UNDERSIZE PACKETS

(Read-only) - Displays the number of packets received

whose size was less than the minimum Ethernet frame size of 64 bytes, not including

preamble.

OVERSIZE PACKETS

(Read-only) - Displays the number of packets received whose

size exceeded 1518 data bytes, not including preamble.

FRAGMENTS

(Read-only) - Displays the total number of packets received that were

not an integral number of octets in length or that had a bad Frame Check Sequence

(FCS), and were less than 64 octets in length (excluding framing bits but including

FCS octets).

JABBERS

(Read-only) - Displays the total number of packets received that were

longer than 1518 octets (excluding framing bits, but including Frame Check Sequence

(FCS) octets), and were not an integral number of octets in length or had a bad Frame

Check Sequence.

LINK STATUS

(Read-only) - Displays one of the following values:

• Link

• No Link

• N/A

PORT TYPE

(Read-only) - Displays one of the following values:

• AUI

• BNC

• EPIM-x

• MMF SMA

• MMF ST

• RJ45

• RJ71

• SMF ST

9E312-12 Module Speciﬁc Information

PORT STATUS

(Read-only) - Indicates the status of the selected port. Possible values

are ENABLED and DISABLED.

APPLICATION

(Read-only) - Displays BRIDGING, indicating that the port is

operating as a bridge with a high-speed backbone connection.

OPERATION MODE

(Read-only) - Displays one of the following values:

• STANDARD ENET - The port can either transmit data or receive data, but not both

at the same time. Therefore, the port is running at 10 Mbps.

• FULL DUPLEX - The port can transmit and receive data at the same time.

Therefore, the port is running at 20 Mbps.

Port Statistics Screen Commands

To display statistics for another port:

1. Use the arrow keys to highlight the

PORT #

command at the bottom of the screen.

2. Press the

Space

Bar

to increment (or press the

Delete

key to decrement) the port

number.

3. Press the

Return

key (neither the read-only

Port #

ﬁeld nor the statistics will

change until you press the

Return

key).

To exit the Port Statistics screen:

Use the arrow keys to highlight

RETURN

and press the

Return

key.
