QUICK START

Release 7.2

Cabletron Systems

(603) 332-9400 phone

(603) 337-3075 fax

support@ctron.com

C A B L E T R O N S Y S T E M S

QUICK START

2 SmartSwitch Remote Access Module

NOTICE

You may post this document on a network server for public use as long as no

modifications are made to the document.

Cabletron Systems reserves the right to make changes in specifications and other

information contained in this document without prior notice. The reader should in

all cases consult Cabletron Systems to determine whether any such changes have

been made.

The hardware, firmware, or software described in this manual is subject to change

without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY

INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES

WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING

OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION

CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF,

KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH

DAMAGES.

Cabletron Systems, Inc.

P.O. Box 5005

Rochester, NH 03866-5005

Order Number: 9032491

VIRUS DISCLAIMER

Cabletron Systems has tested its software with current virus checking

technologies. However, because no anti-virus system is 100% reliable, we strongly

caution you to write protect and then verify that the Licensed Software, prior to

installing it, is virus-free with an anti-virus system in which you have confidence.

Cabletron Systems makes no representations or warranties to the effect that the

Licensed Software is virus-free.

Only qualified personnel should perform installation

procedures.

CAUTION

9W006 and 9W007 3

TRADEMARKS

Cabletron Systems, CyberSWITCH, MMAC-Plus, SmartSWITCH, SPECTRUM,

and SecureFast Virtual Remote Access Manager are trademarks of Cabletron

Systems, Inc.

All other product names mentioned in this manual are trademarks or registered

trademarks of their respective companies.

COPYRIGHTS

All of the code for this product is copyrighted by Cabletron Systems, Inc.

United States of America.

Portionsofthecodefor thisproductarecopyrightedbythefollowingcorporations:

Epilogue Technology Corporation

Livingston Enterprises, Inc.

Security Dynamics Technologies Inc.

Stac Electronics

Stac Electronics 1993, including one or more U.S. Patents No. 4701745, 5016009,

5126739 and 5146221 and other pending patents.

Telenetworks

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment uses,

generates, and can radiate radio frequency energy and if not installed in

accordance with the operator’s manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause

interference in which case the user will be required to correct the interference at his

own expense.

QUICK START

4 SmartSwitch Remote Access Module

WARNING: Changes or modificationsmade to this device which are not expressly

approved by the party responsible for compliance could void the user’s authority

to operate the equipment.

DOC NOTICE

This digital apparatus does not exceed the Class A limits for radio noise emissions

from digital apparatus set out in the Radio Interference Regulations of the

Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de la class A prescrites dans le

Règlement sur le brouillage radioélectrique édicté par le ministère des

Communications du Canada.

VCCI NOTICE

This is a Class 1 product based on the standard of the Voluntary Control Council

for Interference by Information Technology Equipment (VCCI). If this equipment

is used in a domestic environment, radio disturbance may arise. When such

trouble occurs, the user may be required to take corrective actions.

CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT

IMPORTANT: Before utilizing this product, carefully read this License Agreement.

This document is an agreement between you, the end user, and Cabletron Systems,

Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the

Cabletron software program (the “Program”) contained in this package. The

Program may be contained in firmware, chips or other media.BY UTILIZING THE

ENCLOSED PRODUCT, YOU ARE AGREEING TO BECOME BOUND BY THE

TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND THE

LIMITATION OF WARRANTY AND DISCLAIMER OF LIABILITY. IF YOU DO

NOT AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN

THE UNUSED PRODUCT TO THE PLACE OF PURCHASE FOR A FULL

REFUND.

9W006 and 9W007 5

CONTENTS

Using Quick Start 6

Installing the Module 7

Overview 7

User Documentation 7

Hardware Installation 9

Installing the SmartSwitch Remote Access Module 9

Connecting the Module’s Cabling 9

Resetting the SmartSwitch Remote Access Module 11

Accessing the Module 11

Accessing a New Module 12

Remote Access using Telnet 13

Upgrading the Software 13

Installing and Launching SFVRA-CFG 14

Module Connectivity 18

Overview 18

Assigning IP Addresses 19

Configuration Using SFVRA-CFG 20

Starting SFVRA-CFG 21

Configuring a Site Template 21

Adding the Sites 21

Configuring Connection Group Information 24

Configuring IP Information 27

Generating Configuration Updates 30

Downloading Configuration Updates 31

Necessary Configuration for the Remote Devices 31

Index 33

SING

UICK

TART

Quick Start is recommended only for those userswho are experienced with hardware and software

installation procedures. Quick Start is divided into the following sections:

• Installing the Module

Provides you with information to help you install the your SmartSwitch Remote Access

Module so that it is running and ready for configuration. Information includes a description of

user documentation and instructions for hardware installation, accessing the module,

upgrading the module’s software, and installing and launching SFVRA-CFG (the

configuration utility).

• Module Connectivity

Using an example network configured through SFVRA-CFG, this section provides instructions

for module and other device connectivity using IP.

NSTALLING

THE

ODULE

OVERVIEW

Installing the Module provides you with information to help you install the SmartSwitch Remote

AccessModule so that it is running and ready for configuration. We include information regarding:

• User Documentation

A description of user documentation included with the module.

• Hardware Installation

Step-by-step instructions for installing the module and completing its cabling.

• Accessing the Module

Instructions for first-time module access and for subsequent remote access.

• Upgrading Software

Instructions for upgrading system software (not required for new installations).

• Installing and Launching SFVRA-CFG

Instructions for installing and starting-up the SFVRA-CFG configuration utility.

USER DOCUMENTATION

We include user documentation for the module itself, for the SFVRA Manager applications that are

included with the module, and for the Central Site CyberSWITCH. A summary of user

documentation follows.

9W006 & 9W007 DOCUMENTATION

This guide, the 9W006 & 9W007 Remote Access Module Quick Start, provides abbreviated installation

and configuration instructions. It is intended to help you quickly get your module up and running.

Instructions for setting up specific types of remote devices are also included. The Quick Start and

the User’s Guide are included on the 9W006 &9W007 Remote Access Module CD-ROM.

The 9W006 & 9W007 Remote Access Module User’s Guide provides more detailed information for

installing your system. It also provides information to help keep your module running efficiently.

The 9W006 & 9W007 Release Notes provide release information and highlights.

SFVRA MANAGER DOCUMENTATION

The SFVRA Configuration Manager User’s Guide provides detailed information for installing,

configuring, and using the module’s configuration utility, SFVRA Configuration Manager

(SFVRA-CFG). The SFVRA Configuration and SFVRA Connection Manager User’s Guides are

included on the SFVRA Manager CD-ROM.

QUICK START

8 SmartSwitch Remote Access Module

The SFVRA Connection Manager User’s Guide provides detailed information for installing,

configuring, and using the SFVRA Connection Manager (SFVRA-CONN). SFVRA-CONN

communicates in real time with the module to provide centralized, policy-based connection

management for remote and central site users.

The SFVRA-CFG and SFVRA-CONN Release Notes provide release information and highlights. The

Release Notes are provided in a file that can be accessed under the applications’ Help menus.

CENTRAL SITE CYBERSWITCH DOCUMENTATION

The primary configuration utility included for configuring your module is SFVRA-CFG. The

SmartSwitch Remote Access Module documentation was written with SFVRA-CFG in mind. This

configuration utility will be sufficient for most configurations, however, if you will be setting up a

complex configuration, you may need to use CFGEDIT, a more comprehensive configuration

utility. Note that once you use CFGEDIT, you will be unable to go back to using SFVRA-CFG

(except under one special circumstance — if you configure IP filters using CFGEDIT and you make

no other changes except for the IP filter configuration, you can then go back to SFVRA-CFG).

The following is a list of some of the major features that cannot be configured through SFVRA-CFG:

• AppleTalk Remote LAN port

• Bridge filters

•DHCP

• File attributes configuration

•FrameRelay

• IP filters

• IPX static routes and services

• Off-node authentication databases

• TFTP configuration

•X.25

If you will be using any of the above features, you will need to use CFGEDIT to configure your

module. In result, you will need to refer to supplemental user documentation provided on the

9W006 &9W007 Remote Access Module CD-ROM for configuration, verification, and diagnosis

instructions (and any other activities that use SFVRA-CFG). This documentation is the

CyberSWITCH Central Site User Documentation. Note that although the supplemental

documentation is for a different Cabletron product, the CFGEDIT instructions included can be

applied to the SmartSwitch Remote Access Module. This documentation includes:

The CyberSWITCH Central Quick Start provides abbreviated installation and configuration

instructions for experienced users. Specific instructions for setting up various types of remote

devices are also included.

The CyberSWITCH Central Site User’s Guide provides information to install and configure your

system. It also provides information you may need to refer to keep your system running efficiently

after it is up and running. For example, it provides a listing of system messages. Many other

subjects are covered, including routine maintenance, hardware information, system verification,

and problem diagnosis.

The Example Networks Guide includes several example networks, beginning with a simple network,

and progressing to more complex networks. These example network chapters provide

configuration instructions that you may find helpful in configuring your own similar network.

9W006 and 9W007 9

NSTALLING

THE

ODULE

Hardware Installation

HARDWARE INSTALLATION

This section provides instructions for:

• installing the 9W006/9W007 module in to a SmartSwitch 9000

• completing the module’s cabling

In case you need to restart the module during installation, instructions are also included for

resetting the module.

INSTALLING THE SMARTSWITCH REMOTE ACCESS MODULE

1. The module fills two SmartSwitch 9000 slots. Remove the SmartSwitch panels that cover the

two slots into which the module will be installed. For proper airflow and cooling, cover any

empty slots.

2. Before installing the module into the chassis, ensure that the bottom and top plastic tabs are

unlocked.

3. Slide the module into the available slots making sure that the module is between the guides.

Take care that the module engages the backplane connectors properly.

4. Lock down the top and bottom plastic tabs at the same time, applying even pressure.

CONNECTING THE MODULE’SCABLING

Installing the module into the SmartSwitch 9000 automatically completes its power supply and

SMB connections.What you will need to complete, though, is the Ethernet and PRI cabling. In

addition, U.S. and European installations need a Mod-Tap adapter for each PRI port.

We include an illustration of the 9W006-400. You may find this illustration helpful for locating the

module’s Ethernet and PRI ports. Instructions for each cabling requirement follow the illustration.

The SmartSwitchRemote Access Moduleand the host SmartSwitch 9000 are

sensitive to static discharges. Use a grounding strap and observe all static

precautions during this procedure. Failure to do so could result in damage

to the SmartSwitch 9000 or the module.

CAUTION

QUICK START

10 SmartSwitch Remote Access Module

ETHERNET CABLES

1. Insert the RJ-45 adapter at one end of the provided Ethernet cable into the module’s Ethernet

port 1.

2. Insertthe RJ-45 adapter at the otherend oftheEthernet cableinto one ofthe SmartSwitch 9000’s

Ethernet ports.

3. Repeat steps 2 and 3 for Ethernet port 2 if you will be using a second Ethernet connection.

MOD-TAP ADAPTER

Thesystem'sPRI RJ-45adapter uses the international standardof pins 3,4, 5,and 6 fortransmitand

receive. Most T1 lines in the United States and Europe use the traditional 1, 2, 4, and 5 pins. We

provide an RJ-45 to RJ-45 Mod-Tap adapter that will convert between the two wiring systems.

MMAC

BUSMMAC

Smart

SWITCH

9W006-400

WAN

Ejector Tabs

External Floppy

Drive Connector

RS232 Console

Connector

Ethernet Ports

VGA Video Ports

Ethernet 1 & 2

Activity LEDs

Keyboard Connector

SMB LED

Power LED

Parallel Port

PRI/TI

Ejector Tab

The 9W006-400

PRI Ports

Andere Handbücher für SmartSwitch 9W006

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Cabletron Systems Schalten Handbücher

Cabletron Systems

Cabletron Systems SmartSTACK ELH100 Bedienungsanleitung

Cabletron Systems

Cabletron Systems SMALL OFFICE CyberSwitch 150 Bedienungsanleitung

Cabletron Systems

Cabletron Systems STHI Bedienungsanleitung

Cabletron Systems

Cabletron Systems 6H128-08 Bedienungsanleitung

Cabletron Systems

Cabletron Systems MMAC-Plus 9H423-28 Handbuch

Cabletron Systems

Cabletron Systems Spectrum 2E42-27 Bedienungsanleitung

Cabletron Systems

Cabletron Systems ESX-1320 Bedienungsanleitung

Cabletron Systems

Cabletron Systems SmartCell ZX-250 Bedienungsanleitung

Cabletron Systems

Cabletron Systems MicroMMAC-24E Bedienungsanleitung

Cabletron Systems

Cabletron Systems SmartCell 6A000 Bedienungsanleitung

Cabletron Systems

Cabletron Systems MMAC-Plus 9T122-24 Bedienungsanleitung

Cabletron Systems

Cabletron Systems TRMIM 24A TRMIM-24A Bedienungsanleitung

Cabletron Systems

Cabletron Systems SmartStack STS-8SU Bedienungsanleitung

Cabletron Systems

Cabletron Systems SmartSwitch 9A100 Bedienungsanleitung

Cabletron Systems

Cabletron Systems 7C03 MMAC SmartSWITCH Bedienungsanleitung

Cabletron Systems

Cabletron Systems MMAC-Plus 9T125-24 Handbuch

Cabletron Systems

Cabletron Systems MicroMMAC 22ES Bedienungsanleitung

Cabletron Systems

Cabletron Systems FN10 Bedienungsanleitung

Cabletron Systems

Cabletron Systems SEH-24 Bedienungsanleitung

Cabletron Systems

Cabletron Systems DLE22-MA Bedienungsanleitung

Cabletron Systems

Cabletron Systems Cabletron CyberSWITCH CSX5500 Bedienungsanleitung

Cabletron Systems

Cabletron Systems MMAC-Plus 9H531-18 Bedienungsanleitung

Cabletron Systems

Cabletron Systems FlowPoint 2100 12 Bedienungsanleitung

Cabletron Systems

Cabletron Systems SmartSwitch 2500 Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
