Remote Controlled
Microphone Amplifier
M16
Remote Controlled Microphone Amplifier
Installation & User Manual
M16
i
Revision MA2005-7 M16 Microphone Amplifier
Table of Contents
Table of Contents ................................................i
Introduction .......................................................iii
Features .............................................................iv
Using the M16 Manual ......................................iv
Declaration of conformity .................................v
1 Important Safety Instructions ........................1-1
1.1 Mains Cable ............................................................ 1-1
1.2 Changing the fuse ................................................... 1-1
1.3 Fuse Types.............................................................. 1-2
1.4 Servicing.................................................................. 1-3
1.5 Do not remove any covers ...................................... 1-3
1.6 Safety checklist ....................................................... 1-3
2 Important information .....................................2-1
2.1 Unpacking ............................................................... 2-1
2.2 Operational considerations...................................... 2-2
2.2.1 AC mains voltage .......................................... 2-2
2.3 Cleaning .................................................................. 2-2
2.4 Installation ............................................................... 2-2
3 The M16 Microphone Amplifier ......................3-1
3.1 M16 Front panel ...................................................... 3-1
3.2 M16 Rear Panel ...................................................... 3-2
3.3 Connecting up your M16 ......................................... 3-3
3.3.1 Mains power............................................. 3-3
3.3.2 Ground stud ............................................. 3-3
3.3.3 Audio Connections ................................... 3-3
3.3.4 Power On ................................................. 3-4
3.4 Standalone operation .............................................. 3-4
3.4.1 Channel LED indicators ........................... 3-4
3.4.2 PFL switch................................................ 3-4
3.4.3 MUTE switch ............................................ 3-5
3.4.4 Channel Control Section .......................... 3-5
3.4.5 Single Channel Selection ......................... 3-5
3.4.6 Multiple Channel Selection....................... 3-5
3.4.7 Channel Control Section Parameters....... 3-6
3.5 Headphones ............................................................ 3-7
3.6 MADI Output............................................................ 3-7
3.6.1 Connecting the MADI Output ................... 3-8
3.6.2 MADI Setup.............................................. 3-8
3.6.3 Sample Frequency Selection ................... 3-8
3.6.4 MADI Channel Selection .......................... 3-8
3.6.5 Word Clock............................................... 3-9
3.7 Monitoring the PFL bus on multiple M16 units ........ 3-9
ii
M16 Microphone Amplifier Revision MA2005-7
4 Remote control of the M16 ............................ 4-1
4.1 Introduction..............................................................4-1
4.2 RS-485 Communications Protocol...........................4-1
4.3 CADAC RM16 Remote Mic Amp. Controller ...........4-1
4.4 Front Panel ..............................................................4-2
4.5 Rear Panel...............................................................4-2
4.6 Connections.............................................................4-2
4.6.1 RM16 Power.............................................4-2
4.6.2 Remote Control Comms Backbone..........4-3
4.7 Single M16, RM16 System Connections .................4-4
4.8 Multiple M16, RM16 System Connections...............4-4
4.9 Power On Sequence ...............................................4-5
4.10 RM16 configuration .................................................4-5
4.10.1 Configuring the system.............................4-5
4.10.2 Control Menu............................................4-7
4.10.3 Naming M16 units ....................................4-7
4.10.4 Naming M16 channels..............................4-8
4.10.5 System Integrity........................................ 4-9
4.11 RM16 Meters .........................................................4-10
4.11.1 Channel Mute indication.........................4-10
4.11.2 Meter Brightness Control........................4-10
4.12 Controlling M16 microphone channels ..................4-10
4.12.1 M16 selection .........................................4-10
4.12.2 Channel Selection ..................................4-11
4.13 Gain Control ..........................................................4-11
4.14 Mute.......................................................................4-11
4.15 Pad Switch: Pad ....................................................4-11
4.16 Polarity Reverse Switch: Rev ................................4-11
4.17 Phantom Power Switch: 48v..................................4-11
4.18 High Pass Filter: ....................................................4-12
M16 Specifications .................................. SPEC1
Appendices ................................................APP-1
Connector wiring.................................................APP-1
CADAC USB ReProgramming Utility..................APP-4
M16 Software Version ........................................APP-8
Warranty ....................................... WARRANTY-1
Index ....................................................... INDEX-1
iii
Revision 2005-7 M16 Microphone Amplifier
Introduction
Thank you for purchasing the M16 Remote Controlled Microphone
Amplifier from CADAC Electronics plc.
CADAC is renowned for supplying arguably the highest quality audio
mixing consoles for the world-wide professional audio industry for
over 36 years. In all these years the driving force behind the compa-
ny’s research and development program has been to strive for prod-
ucts that not only provide the exact functionality required but also
exceptional audio performance and reliability. This can be attested
throughout the world, with many hundreds of CADAC consoles
working day in day out in many of the world’s premier venues and
tours.
For over 30 years CADAC has been receiving high praise for its very
natural sounding microphone amplifier, and the release of the new
CADAC M16 encompasses the sound of that classic amplifier in a
compact 19” 3U rack multi-channel format that is equally suitable for
live, broadcast, as well as general applications. The M16 has been
engineered to deliver exceptional quality and reliability. Premium
quality performance is maintained throughout the signal path, result-
ing in a very wide bandwidth, flat frequency response, impressive
phase response and generous headroom.
We trust that the CADAC M16 will bring many years of satisfaction
and thank you for your patronage.
The CADAC team
iv
M16 Microphone Amplifier Revision MA2005-7
Features
■16 channels of high performance microphone amplifiers.
■Ideal solution for touring, broadcast or recording applications
when high quality microphone amplifiers are required.Each
channel output is provided with an integral 3-way active splitter.
■Each output is designed to drive over long cable lengths in
excess of 500m
■All channels are fitted with a switchable high pass filter.
■An optical MADI output is provided to allow multi-channel con-
nection to digital consoles or workstations.
■High build quality with hand tuned Common Mode Rejection and
Balanced circuitry on all I/O.
■Front Panel control of all parameters, or remote control options.
■Up to 32 x M16 units can be connected to one control system.
■Audio interfaces directly with the CADAC D16, 16 x 16 Digital
Mix Matrix via dedicated buss link connectors.
■Designed to exceed current EMC directives, and immune from
receiving or transmitting radio frequency interference.
Using the M16 Manual
In order to obtain the most out of your M16, please read the User
Manual carefully.
Prior to installing and using the M16, it is also important that you
have read both Safety Instructions and Important Information.
If you still have a problem that cannot be resolved by referring to this
manual, then please contact your local CADAC distributor.
All information provided within this user manual is provided in good
faith. CADAC follows a policy of continual product development;
changes to equipment specification may be made without prior no-
tice.
v
Revision 2005-7 M16 Microphone Amplifier
Declaration of conformity
The Directives covered by this Declaration
89/336/EEC Electromagnetic Compatibility directive, amended by
92/31/EEC & 93/68/EEC
The Products Covered by this Declaration
M16 remote controlled microphone amplifier.
RM16 remote controller
The Basis on which Conformity is being Declared
The products identified above comply with the requirements of the
above EU Directives by meeting the following standards:
BS EN 55103-1:1997 Electromagnetic compatibility - Product
family standard for audio, video, audio-
visual and entertainment lighting control
apparatus for professional use.
Part 1 – Emissions
BS EN 55103-2:1997 Electromagnetic Compatibility - Product
family standard for audio, video, audio-
visual and entertainment lighting control
apparatus for professional use.
Part 2 – Immunity
BS EN 60065:1998 Audio, Video and similar electronic appa-
ratus. Safety requirements.
Signed:............................
Authority: General Manager
Date: 24 January 2005
Attention!
The attention of the specifier, purchaser, installer, or user is drawn
to special measures and limitations to use which must be observed
when these products are taken into service to maintain compliance
with the above directives. Details of these special measures and lim-
itations to use are available on request, and are also contained in the
M16 Installation & User manual.
vi
M16 Microphone Amplifier Revision MA2005-7
1-1
Revision MA2005-7 M16 Microphone Amplifier
1 Important Safety Instructions
1.1 Mains Cable
The supplied IEC mains cable must be correctly terminated before
use. Use only an approved AC plug or power distribution device.
Safety ground must be connected at all times.
Safety Earth = Green/Yellow
Live = Brown
Neutral = Blue
1.2 Changing the fuse
To avoid the risk of fire, use only the recommended fuse type as in-
dicated in this manual and on the M16. Do not short-circuit the fuse
holder.
Before changing the fuse, always switch off the unit and remove the
IEC mains cable.
NOTE: Both Live and Neutral are fused, therefore the M16 fuse
holder contains TWO fuses. Do not make the mistake of think-
ing that one is a spare!
To replace a fuse, remove the fuse holder (located adjacent to the
IEC mains socket) by pulling the tab that projects slightly over the lip
of the socket.
FIG 1-1. Remove the fuse holder
Fuse holder
1-2
M16 Microphone Amplifier Revision MA2005-7
Replace the blown fuse with an identical type. See Fuse Types be-
low for further details.
Refit the fuse holder, taking care to align it properly. The guide arm
of the fuse holder slots into the power connector assembly.
Once in place, push the fuse holder home and confirm that it is fully
seated.
1.3 Fuse Types
Live: 90v - 250v: 2A Type T
Neutral: 90v - 250v: 2A Type T
FIG 1-2. Replace the fuse
Fuses
FIG 1-3. Refit the fuse holder Fuse holder
FIG 1-4. Push the fuse holder
home
Push in fuse holder
Inhaltsverzeichnis
