cover page
USER MANUAL
PL7100 RS2100
TABLE OF CONTENTS
Parts List - Exterior 1 Technical Specications 11
Parts List - Interior 2 Troubleshooting 12
Compatible cards and phones 3 Disclaimer 13
Phone Operations 4
Bluetooth Unlocking 5
Touchpad Operations 6
Programming Codes using Touchpad 7
VARICODE Unlocking 8
Lock-out 9
Events, Beeps and LED 10
REGULATORY COMPLIANCE
The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
FCC WARNING STATEMENT
You are cautioned that changes or modications not expressly approved by the part responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
1PL7100 / RS2100
STATUS LED
SENSOR AREA
and
TOUCHPAD
KEYWAY
PARTS LIST - EXTERIOR
STATUS LED
KEYWAY
SENSOR AREA
and
TOUCHPAD
PL7100
RS2100
2PL7100 / RS2100
SETUP
BUTTON
SETUP
BUTTON
PARTS LIST - INTERIOR
PL7100 RS2100
1. Introduction
PL7100 and RS2100 are smart locks with Bluetooth LE, NFC,
MiFARE RFID, and Touchpad capabilities.
3PL7100 / RS2100
2. Compatible cards and phones
2.1 RFID Cards / Key Fobs
• Support MiFARE Classic, MiFARE Ultralight, MiFARE DesFire,
or ISO/IEC 14443 type A with xed UID.
2.2 Phones
• iPhone 4S or above with iOS 8.0 or above
• Android 4.3 or above with Bluetooth Low Energy capability. NFC
capability is required for using the NFC feature.
3. Phone App
Download K3 Connect on App
Store or Google Play, and register an
account. For Android users, if NFC
is available, use K3 Connect+ instead
of K3 Connect. Always update the App
to the latest version.
4. Management
4.1 By Phone
A compatible phone with K3 app installed can be used as the Admin
of Locks. Management tasks can be performed in the App. An Admin
can manage multiple Locks, but a Lock can only have one Admin at a
time. A phone can be an Admin of a lock(s) and client of other lock(s)
at the same time.
4PL7100 / RS2100
4.2 By Touchpad
If Admin phone is not available, the Touchpad can also be used for
selected management tasks. See later section for the full specication.
5. Phone Operations
5.1 Pairing to Become the Admin
a. In the K3 Connect app, press the “+” on the top-right corner of the
Locks page.
b. Fill-in the DIN (pl7100 or rs2100 respectively) and your selected
Lock name, then conrm and put the phone close to the Lock (within
1 meter).
c. Push the setup button.
d. Follow the UI (you may be prompted to setup Wi-Fi SSID/password
to connect this Lock to your Wi-Fi and Internet; ignore it for now if
Gateway is not available). This is an optional device that allows a
phone to unlock the Lock using the Bluetooth Gateway option via
Wi-Fi remotely.
e. After successfully Pairing, the phone is now the Admin of the Lock.
5.2 Unlocking
An Admin or Client can unlock in different ways:
a. Bluetooth Manual Unlocking
• Open the K3 Connect app.
• In the Locks page, click on the tab of your Lock name to trigger it.
5PL7100 / RS2100
b. Bluetooth Auto Unlocking
To set up the Auto Unlocking feature, open the K3 Connect app. In the
Locks page, Select which Lock you wish to set up and slide left on the
tab. Press “Info” and navigate to the menu to enable the Auto Unlocking
features. There are 2 kinds of Auto Unlocking: trigger by touch, or trigger
by location. See the App UI for more description.
c. NFC Unlocking
With the K3 Connect+ App installed, Admin and Client phones can
unlock with NFC by waking up the phone and tapping it on the sensor/
touchpad of the lock.
5.3 Admin phone options
The App can do the following management tasks (as Admin):
• Set Names of Locks
• Lock parameters setting (such as Passage Mode or Mute)
• Add/Delete Clients (including other phones, cards, or CODEs)
• Set Client access rights (such as limited duration or only
one-time access or temporarily suspended)
• Set Client Nick-names
• Generate VARICODE
• View Audit Trail
• Check Lock Battery status
• Update Lock Firmware
6PL7100 / RS2100
6. Touchpad Operations
6.1 Wake up
Before any touchpad operations, touch the Lock sensor to wake it up.
6.2 Setting the Master Code (MC)
THE FACTORY DEFAULT MASTER CODE IS 12341234
MC length is between 6 to 12 digits. Follow these steps to change the
Maste Code:
1. Press the Setup Button
2. Wake up touchpad
3. Enter the new MC followed by #
4. Enter the new MC again and followed by #
6.3 Programming Codes using the Touchpad
1. Add Code (new CODE length is between 6 to 12 digits)
2. Add RFID Card / Key Fob
MC # 1 1 NEW
CODE #NEW
CODE #
++ + + + + +
MC # 1 2 TAP CARD
OR KEY FOB
+ + + +
7PL7100 / RS2100
3. Delete CODE
4. Delete RFID Card / Key Fob
5. Delete All Codes (exclude Master Code)
6. Delete All RFID Cards / Key Fobs
7. Delete All Phones including Admin
8. Delete All Codes/Cards/Key Fobs/Phones
including Admin
MC # 2 1 CODE #CODE #
++ + + + + +
MC # 2 2
+ + + + TAP CARD
OR KEY FOB
MC # 3 1
++ +
MC # 3 2
++ +
MC # 3 3
++ +
MC # 3 4
++ +
8PL7100 / RS2100
6.4 CODE Unlocking
Wake-up touchpad, enter CODE followed by #
6.5 VARICODE Unlocking
• VARICODE is a time-specic temporary code that can be
generated in the App. VARICODE can be generated in the
App anywhere; no need to be in front of the Lock.
• VARICODE can be obtained in the App:
In the Clients page, press the “+” on the top-right corner, and select
Type as VARICODE to see the UI. Once generated, send the
VARICODE to the users.
• For VARICODE Unlocking:
Wake-up keypad, enter #, enter VARICODE
7. Unlocking by RFID Card / Key Fob
Tap the card/key fob in front of the sensor/touchpad, and wait until the
LED ashes and you hear a sequence of beeps.
8. Low Battery Warning
There are two indicators when the batteries are running low:
• When successfully unlocked, you will hear 3 beeps then 5 beeps for
low battery warning.
• If the batteries are too low, it will not unlock even after successful
authentication using a registered RFID/Key Fob/Phone or correct
CODE, and you will hear 3 beeps then 10 beeps as warning.
**Both indicators will only stop once the batteries are replaced with new ones.
