SX-60 Standmount Speakers

Manual Generated: 22/11/2023 - 16:58

Table of Contents

SX-60 Standmount Speakers 3 ...................................................................................................................................................................................

Introduction 4 ................................................................................................................................................................................................................

What's included with the SX-60's? 5 ..........................................................................................................................................................................

Front panel 6 .................................................................................................................................................................................................................

Rear panel 7 ...................................................................................................................................................................................................................

Installation instructions 8 ...........................................................................................................................................................................................

Technical Speciﬁcations 10 .........................................................................................................................................................................................

Frequently asked questions 11 ...................................................................................................................................................................................

Troubleshooting 12 .......................................................................................................................................................................................................

SX-60 Standmount Speakers

Last updated: December 7, 2022 01:32. Revision #9807

Users Manual

Introduction

Last updated: January 19, 2023 01:56. Revision #9808

Thank you for purchasing these Cambridge Audio SX-60 stand mount loudspeakers. We hope that you enjoy many years of listening pleasure from

them. Your loudspeakers can only be as good as the system it is connected to. Please do not compromise on your ampliﬁer or cabling. Naturally we

particularly recommend ampliﬁcation from the Cambridge Audio range, which has been designed to the same exacting standards as our

loudspeakers. Your dealer can also supply excellent quality speaker cable to ensure your system realises its full potential.

Thank you for taking the time to read this manual; we do recommend you keep it for future reference.

For upcoming news on future products, software updates and exclusive oﬀers, make sure you register your product at

http://www.cambridgeaudio.com/register

What's included with the SX-60's?

Last updated: January 19, 2023 01:56. Revision #9809

1. 2 x SX-60 speakers.

2. Installation guide.

3. 8 x rubber pads.

4. 2 x foam bungs.

Front panel

Last updated: January 19, 2023 01:57. Revision #9810

1. 1” (25mm) Silk Dome Tweeter.

2. 6.5 ”(165mm) Doped Paper Cone Bass/Mid Driver.

3. Front Bass Port.

Rear panel

Last updated: January 19, 2023 01:57. Revision #9811

1. +/- Speaker Connection Terminals.

Installation instructions

Last updated: January 19, 2023 01:57. Revision #9812

1. Firstly, using high quality speaker cable connect the SX-60 standmount speakers to the speaker terminals on your ampliﬁer. Ensure that you pay

close attention to match the polarity of each connection.

2. For the best results we would recommend using speaker stands to mount your SX-60 speakers. Alternatively, the speakers can be placed on a

shelf, and in either case we would suggest leaving at least a 5cm space behind the rear of each speaker.

3. If placed on a desk, or close to a wall you may beneﬁt from using the included foam bass tuning bungs. These can be placed into the front port of

each speaker to reduce the low frequency output.

4. Finally, when positioning, we would suggest that the distance between speakers and the listening position is equal. However, we would

encourage experimentation until you ﬁnd a solution that works for your space.

Technical Speciﬁcations

Last updated: January 19, 2023 01:57. Revision #9813

Sensitivity (SPL)

89dB

Frequency Response

41Hz - 22kHz

Impedance

8 Ohms

Drivers

1 x 6.5” (165mm) doped paper cone.

1 x 1” (25mm) tweeter.

Crossover

2 Way

Recommended Ampliﬁer Power

20 - 100 Watts

Porting

1 Front

Speaker Dimensions (H x W x D)

340 x 200 x 272mm.

Weight

5.0kg (11lbs)
