Cannondale Kids with Training Wheels Bedienungsanleitung

Kids with

Training Wheels

Quick Start Guide

Applies to: Kids Trail 12 & 16

Welcome to the Cannondale family.

WARNING

SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK

This is a Quick Start Guide, not an

Owner’s manual.

Bicycling is an active sport with

inherent risk. A wide range of injuries

are possible. Due to the nature of

bicycle riding, the situations you

encounter while riding, you will be

exposed to the risk of serious injury,

paralysis or death. This risk cannot

be eliminated. You can minimize the

risk in many ways. Begin by reading

the complete Cannondale Bicycle

Owner’s manual accompanying

this bike and available online at

www.cannondale.com, particularly

section “IMPORTANT SAFETY

INFORMATION”.

First up, thank you for buying a new Cannondale bike – we’re excited to

have you on board and to get you out riding as soon as possible. Our new

assembly process is easy-to-follow – using methods outlined in this guide

to assemble your new Cannondale at home, plus it’s even easier to do so

with a friend. Our guide will take you through the simple steps from start

to nish – you can also follow along with a how-to video, as you build your

bike, just visit: [email protected]

If you still have any questions, then our Cannondale rider support sta are

ready to help you. Feel free to give us a call at

Also, when your new bike is all assembled and ready to ride, we’d love to

check it out – please don’t forget to tag #ridecannondale in your social

media. Enjoy the ride!

SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK



Install your

handlebars



Install your

seat post



Install your

training wheels



Install your

front wheel



Install your

pedals





This video applies to one Cannondale Platform:

• Kid’s Trail 12 & 16

Tools Needed:

• Flat-Head Screwdriver

• Phillips-Head Screwdriver

• Box Cutter

• Scissors

Tools Included:

• Torque Wrench

• Allen Keys

• Pedal Wrench

Gently lift your bike out of the box and set it

on the ground.

Inside the box, you’ll nd a smaller box of parts, necessary tools,

documentation and manuals. Once the bike is assembled, but

before you ride, please read the owner’s manual.

First, locate the staples on the top of the box and carefully remove

them with a screwdriver. Use caution: the staples are sharp.

Remove the small parts box and saddle/seatpost and set them aside.

Push the hand aps from the inside to the outside of the box. This

will make removing the bike easier.

Carefully lift the bike out of the box and set it onto the top of the box.

Once the bike is assembled, but before you ride, please read the

owner’s manual.

Locate your warranty card and set it aside with your owner’s manual.





SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK

 J

The stem should be pointing forward. Using the included Allen

wrench, loosen and remove the bolts and faceplate from the stem.

The stem connects the handlebar to the fork. Set the bolts and

faceplate aside together, so you don’t lose anything.

Insert the handlebar into the stem and loosely reattach the faceplate

to the stem. Take care to not tighten one bolt more than another.

Your goal is a consistent gap between the stem and faceplate from

top to bottom.

Center the handlebar in the stem using the markings on the bar and

roll the handlebar back into a comfortable position. Hand-tighten the

stem faceplate bolts using the Allen key. You will fully tighten these

bolts later.



SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK



On the seatpost, locate the minimum insertion line.

Insert the seatpost into the frame past this line.

Hand-tighten the seatpost collar, so you can’t pull the seatpost from

the frame. You will fully tighten this later.

Remove any additional packaging from the rear of the bike.



SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK



Insert the pin on the training wheel bracket into the top hole of the

rear axle dropout.

Install the training wheel bolt and tighten rmly with your hand.

Repeat steps 1. and 2. on the opposite side of the bike.



SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK



Completely remove the axle nuts and tabbed washers from the front

wheel.

Install the hub guards so the tabs are pointed out.

Remove the axle spacer from the fork dropouts.

Lower the fork dropouts onto the hub axle and rotate the hub guards

so the hub guard tab aligns with the channel of the dropout.



SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK



Install the tabbed washers to the axle ends with the tab facing the

fork. Rotate the washers so the tabs fall into the hole in each dropout.

Hand-tighten the axle nuts to retain the tabbed washers.

Use an open-end or adjustable wrench to tighten both axle nuts very

rmly.



SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK



Install the pedals by turning the pedal spindle in the direction of the

front wheel. Insert the right pedal (marked with R on the body and/or

spindle) into the crank and tighten with your ngers.

Repeat with the left pedal (with an L on it). Remember, both pedals

will always tighten toward the front of the bike.

Tighten both pedals down very rmly using the provided pedal

wrench.



SET-UP STEP 2STEP 1 STEP 3 STEP 4 STEP 5 PRE-RIDE CHECK
