Canon VIXIA HF M30 Bedienungsanleitung

The serial number is printed on the camcorder in a four-digit by three-

line format. The location of the serial number will vary depending on

the model, so find it by referring to the illustrations below.

●Location of the serial number on the VIXIA HF M31 / HF M30 / HF

M300

The serial number is

necessary to install

ImageMixer 3

When ImageMixer 3 is in-

stalled, it will ask for the

serial number. Input the

12-digit serial number with-

out any spaces.

* Refer to the separate in-

stallation guide for details.

ImageMixer 3 must be installed in a personal computer in order to edit video, and record video on

DVDs and Blu-ray discs. Find the serial number of the camcorder and install ImageMixer 3

according to the separate installation guide.

Precautions When Installing

ImageMixer 3 SE (ImageMixer)

Finding the Camcorder Serial Number

Finding the Serial Number

Locations of Serial Numbers by Model

Where is the serial

number on the VIXIA

HF M31 / HF M30 /

HF M300

It is on the bottom of the

camcorder body. Refer to

the illustration on the right

to find the serial number.

This is the serial number. The 12-digit number is

printed in three four-digit lines. In this example the

serial number is 517006893241.

Serial number

Precautions When Installing ImageMixer 3 SE (ImageMixer)

●Location of the serial number on the VIXIA HF R11 / HF R10 / HF

R100

●Location of the serial number on the VIXIA HF S21 / HF S20 / HF

S200 Where is the serial

number on the VIXIA

HF S21 / HF S20 / HF

S200

It is below the viewfinder.

Refer to the illustration on

the left and remove the

batter y to find the serial

number.

Where is the serial

number on the VIXIA

HF R11 / HF R10 / HF

R100

It is on the bottom of the

camcorder body. Refer to

the illustration on the left

to find the serial number.

Serial number

Remove the battery.

Serial number

VIDI O

SNAP WEB

AUTO

DISP.

INDEX SEL.

ON/OFF(CHG)

Install ImageMixer 3

Refer to the separately in-

cluded instructions and in-

stall ImageMixer 3. See

pages 2 and 3 of this man-

ual on how to find the seri-

al number.

The location of the DC

IN terminal differs ac-

cording to the cam-

corder model

The location of the DC IN

terminal differs according

to the camcorder model.

Refer to the illustrations on

the right to find where to

connect the compact pow-

er adapter.

In order to edit video, it must first be imported into the computer. ImageMixer 3 will start automati-

cally when the camcorder and computer are connected with a USB cable. Follow the steps below

to import the video into the personal computer.

Importing Video

from the Camcorder

Lesson ●01 Launching ImageMixer 3 and Importing Video

Connect the Camcorder to a Wall Outlet

●Connecting the VIXIA HF M31 / HF M30 / HF M300 to a wall outlet

●Connecting the VIXIA HF R11 / HF R10 / HF R100 to a wall outlet

●Connecting the VIXIA HF S21 / HF S20 / HF S200 to a wall outlet

❶Connect the

power cord and

compact power

adapter.

❷Plug the power

cord into a wall

outlet.

VI DIO

SNAP WEB

AUTO

DISP.

INDEX SEL.

ON/OFF(CHG)

❸Connect the

compact power

adapter to the DC

IN connection on

the camcorder.

❸Connect the

compact power

adapter to the DC

IN connection on

the camcorder.

❸Connect the

compact power

adapter to the DC

IN connection on

the camcorder.

Importing Video from iVIS Camcorders

Connect the Camcorder to the Computer

Importing from SD

Memory Cards

It is also possible to import

video from SD memory

cards by using a card read-

er/writer with a USB con-

nection. In this case, the

card reader/writer is con-

nected to the computer and

the media on which the vid-

eo is recorded is inserted

into the reader/writer.

* ImageMixer 3 can only

import video from the cam-

corder with which it was

bundled.

The location of the

USB port differs ac-

cording to the cam-

corder model

The location of the USB

port also differs according

to the camcorder model.

Refer to the illustrations on

the left to find the location

of the USB port.

●Connecting the VIXIA HF M31 / HF M30 / HF M300 and the USB

cable

❷Turn on the

camcorder and set

it to video

playback mode.

❸Connect the

USB cable to the

USB port on the

computer.

❶Connect the

USB cable to the

USB port on the

camcorder.

●Connecting the VIXIA HF S21 / HF S20 / HF S200 and the USB

cable

❶Connect the

USB cable to the

USB port on the

camcorder.

Refer to the instructions for the VIXIA HF M31 / HF M30 / HF M300

and connect the camcorder to the computer.

●Connecting the VIXIA HF R11 / HF R10 / HF R100 and the USB ca-

ble

VIDI O

SNAP WEB

AUTO

DISP.

INDEX SEL.

ON/OFF(CHG)

Refer to the instructions for the VIXIA HF M31 / HF M30 / HF M300

and connect the camcorder to the computer.

VI DIO

SNAP WEB

AUTO

DISP.

INDEX SEL.

ON/OFF(CHG)

❶Connect the

USB cable to the

USB port on the

camcorder.

ImageMixer 3 System

Requirements

ImageMixer 3 operating

environment

OS: Windows XP/ Vista/7

CPU: Intel Pentium D 3.0

GHz or faster

Intel Core 2 Duo 2.13

GHz or faster

RAM: 1 GB or more for XP,

2 GB or more for Vista

or 7

Hard disk

: More than 300 MB

of free capacity

Display

: 1280 x 1024 pixels

or more, 32-bit color

or higher

Intel G965 (on-board

VGA) or higher

Sound: Mi c ro s of t D ir e ct

Sound compatible

sound card

Drive: DVD-writable drive

Others: USB 2.0, Direct X

9.0c, and an Internet

connection

*1 When using Windows

XP, only compatible with

Service Pack 2 or Service

Pack 3.

*2 When creating a disc,

free capacity that is equiv-

alent to two times the ca-

pacity of the disc is neces-

sary.

What about other ways

to start ImageMixer

If ImageMixer 3 doesn't

start automatically, then

start it with either of the

two methods below.

- Double click the "Image

Mixer 3 SE Ver. 6" short-

cut icon on the desktop.

- Fr o m the [Sta r t] menu

click [All Programs] -

[PIXELA] - [ImageMixer 3

SE Ver. 6] - [ImageMixer

3 SE Ver. 6].

Importing Video

A screen similar to this will be displayed on the camcorder LCD.

The ImageMixer 3 launcher will start.

❶Select [Compurer/

Printer].

❷Click [Video file import].

The operation will differ according

to the camcorder model.

Importing Video from iVIS Camcorders

What is the difference

between "video not

saved in the computer"

and "all video"?

When "Import the video

files which have not been

saved in the computer" is

selected, only video that

has not been saved will be

imported. When "Import all

videos" is selected, all the

video files in the " S o u rce"

are imported. In the latter

case, all video will be im-

ported, including video that

is already in the computer.

Which media to select?

The icons displayed as the

"Sources" correspond to

the following media:

…SD memory card in-

serted in the cam-

corder

…Built-in camcorder

memory

…SD memory card in-

serted in the cam-

corder and built-in

memory

…SD memory card in-

serted in a card read-

er/writer

The [Video

file import]

dialog is

displayed.

❸Select the

source.

❹Select the

import

method

❺Click [OK].

❻Click [OK].

The [Video

file import]

dialog is

displayed.

What is a project?

When editing video, one

production can be made

up of multiple video files,

and text and music can be

added. A project is a record

of all of these steps. The

se lected video files and

edited information can be

saved as a project. When

you start editing video,

think of it as, "Starting to

create a project."

How to select multiple

video files

After selecting one video,

hold down the [Shift] key

and select another. All of

the video files in between

will also be selected. Hold-

ing down the [Ctrl] key and

clicking video files will select

all the files that were click-

ed.

You can edit the video after it has been imported into the computer. First, select the video to edit

from among the imported files and then save the information as a project.

Preparing to Edit Video

Lesson ●02 Selecting Video

Selecting the Video File to Edit

Start ImageMixer

3 as described in

Lesson 1.

❶Click [Video file

management &

edit].

❷Select the

video file to be

edited.

❸Click [Movie

Edit].

Double click a

video file to start

playing it to

check its

contents.

Preparing to Edit Video

❹Click [Edit new

movie].

How to select the

resolution

This is where you select

"Full Hi-vision" or "Hi-vision"

resolution for the edited vid-

eo file.

❺Click the

resolution.

❻Click [OK].

Select a video file

and click this

button to delete it.

Drag and drop a

video file to

change the

sequence.

How to add, delete and

change the order of

video files

Videos can be added to

the project by dragging the

files from the library to the

storyboard. A video can be

deleted from a project by

selecting the video in the

storyboard and clicking on

the "wastebasket" icon.

Dragging and dropping a

video file to the left or right

in the storyboard will change

the order of the videos.

Saving the Project

Input the file name in the

displayed screen, and then click

[Save] to save the project.

❶Click [File].

❷Click [Save project].

Add a video file

by dragging it to

the storyboard.

When to save a proj-

ect

The project should be saved

after deleting unneeded

videos, adding text, adding

music or doing any other

editing.

Recorded video sometimes includes unwanted scenes. In such cases, you can cut the unneces-

sary scenes and keep only the scenes you want. This process is called trimming. ImageMixer 3

allows trimming of multiple scenes from one video.

Cutting Unwanted Video

Lesson ●03 Trimming Multiple Scenes

Trimming One Scene

Selecting and Trimming Multiple Scenes

Select the video

file as described

in Lesson 2.

❶Right click the

video file to be

trimmed.

❷Click [Trim

multiple ranges].

What are the IN-point

slider and OUT-point

slider?

"The range of the video to

be kept" is specified with

two points. The IN-point

slider is used to specify

the star ting point of "the

range of the video to be

kept," then the OUT-point

slider is used to specify

the end point.

Select the video

file as described

in Lesson 2.

Select the

starting point of

the scene to be

kept.

Select the end

point of the

scene to be kept.

❶Drag the

[IN-point slider] to

the desired

location.

❷Drag the [OUT-

point slider] to the

desired location.

Andere Handbücher für VIXIA HF M30

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Canon Camcorder Handbücher

Canon

Canon LEGRIA HF20 Bedienungsanleitung

Canon

Canon 2686B001 Bedienungsanleitung

Canon

Canon VC 20 Bedienungsanleitung

Canon

Canon VIXIA HF G30 Bedienungsanleitung

Canon

Canon ZR100 Bedienungsanleitung

Canon

Canon ZR20 Bedienungsanleitung

Canon

Canon ZR400 Bedienungsanleitung

Canon

Canon XC10 Bedienungsanleitung

Canon

Canon ELURA 2 MC Bedienungsanleitung

Canon

Canon EOS C300 Bedienungsanleitung

Canon

Canon MVX460 Bedienungsanleitung

Canon

Canon Optura 100 MC Bedienungsanleitung

Canon

Canon opture S1 Bedienungsanleitung

Canon

Canon LEGRIA HF M506 Bedienungsanleitung

Canon

Canon EOS C100 Mark II Bedienungsanleitung

Canon

Canon XL H1S Bedienungsanleitung

Canon

Canon VIXIA HF R10 Bedienungsanleitung

Canon

Canon VIXIA HF R80 Stücklistenhandbuch

Canon

Canon MVX10 Bedienungsanleitung

Canon

Canon Vixia HF R20 Bedienungsanleitung

Canon

Canon XA10 Bedienungsanleitung

Canon

Canon XL1SA Bedienungsanleitung

Canon

Canon EOS C100 Bedienungsanleitung

Canon

Canon VIXIA HF R400 Bedienungsanleitung

Beliebte Camcorder Handbücher anderer Marken

Toshiba

Toshiba CAMILEO Z100 Bedienungsanleitung

Panasonic

Panasonic NV-VS40B Bedienungsanleitung

Sony

Sony Handycam DCR-DVD7E Bedienungsanleitung

Brinno

Brinno TimeLapse TLC200 Bedienungsanleitung

JVC

JVC GR-SXM68AC Kurzanleitung

Panasonic

Panasonic AG-HMC152EN Bedienungsanleitung

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Bedienungsanleitung

MYDLINK

MYDLINK DCS-6100LH Bedienungsanleitung

Sony

Sony video Hi8 Handycam CCD-TR555 Bedienungsanleitung

SECURECOM

SECURECOM V-5014B Bedienungsanleitung

Panasonic

Panasonic HDC-SD100 Bedienungsanleitung

Sharper Image

Sharper Image U-VIDEO Bedienungsanleitung

JVC

JVC AA-V15EG Bedienungsanleitung

Sony

Sony Handycam DCR-VX2000 Bedienungsanleitung

RCA

RCA CC616 Bedienungsanleitung

Panasonic

Panasonic NVM40 Bedienungsanleitung

ATIK Cameras

ATIK Cameras Horizon Bedienungsanleitung

Sony

Sony Handycam HDR-CX580V Bedienungsanleitung
