This plugin was created to allow you to easily link the clips you recorded using the camcorder to your Avid non-linear
editing system. The plugin uses Avid Media Access (AMA) architecture to link the clips in the camcorder or on a CF
card directly into a bin in Avid Media Composer. Refer also to the Avid Media Composer instruction manuals.
Preparations
This plugin is compatible with Avid Media Composer, version 4.0.5 or later*. Complete the following preparations
before using this plugin.
* As of May 2010, clips that were recorded using the 50 Mbps (4:2:2), 1280x720, 24P video configuration are not supported. Also, clips recorded
using the 25 Mbps (4:2:0), 1440x1080, 30P video configuration will be treated as 60i clips. To edit a video project as a 30p project, please use
clips recorded using the 50 Mbps (4:2:2), 30P or 35 Mbps (4:2:2), 30P video configurations.
1. When using Media Composer 4.x.x only Download and install the following plugin offered by Avid:
Avid AMA MXF Plug-in.
For details, refer to Avid’s Media Composer Web page.
2. Start up Avid Media Composer and check the AMA settings. Make sure that the Enable AMA Volume
Management option is checked.
Linking clips directly from the camcorder or from a CF card
Using AMA architecture, you can link clips to Media Composer directly from a CF card inserted into a card reader
connected to your computer. You can also connect the camcorder to the computer using a USB cable to link clips
directly from the camcorder.
For details about linking media with AMA, refer to Avid Media Composer Advanced Guide.
1. Start up Avid Media Composer.
2. Connect the camcorder or the CF card to the computer.
•CF card: Connect a commercially available card reader compatible with CompactFlash memory cards to the
computer and insert the CF card into the card reader.
• Camcorder:
햲Power the camcorder using the compact power adapter.
햳Turn on the camcorder and set in MEDIA mode.
햴Connect the camcorder to the computer using a USB cable. Use the optional IFC-400PCU USB cable or
similar mini-B USB cable.
• Avid Media Composer will automatically scan the CF card or the camcorder and link the clips into a bin (based
on the AMA settings in Avid Media Composer). The Bin window will open and show the linked clips.
3. Continue the editing operation in Avid Media Composer.
Consult the software’s guides and help files as necessary.
4. When you finish editing the clips, drag the icon of the CF card and drop it onto the trash icon (Eject) to
terminate the connection to the hardware.
5. Disconnect the card reader or camcorder form the computer and remove the CF card.
Macintosh
Canon XF Plugin for Avid Media Access Version 1.0
Instructions
COPY
2
IMPORTANT
• Please observe the following precautions. Failing to do so may result in permanent data loss.
While a CF card is connected to the computer:
- Do not remove the CF card or the CF card reader while editing or accessing the clips on the CF card.
- Do not access, change or delete any of the CF card’s folders or files directly from the computer. Always access
the files on the CF card only using the procedure described above.
When the camcorder is connected directly to the computer:
- Do not open any of the CF card slot covers and do not remove the CF cards.
- Do not disconnect the USB cable.
- Do not turn off the camcorder or the computer.
NOTES
• When using a commercially available card reader, use of a UDMA-compatible card reader is recommended.
Linking clips previously backed up onto a virtual media
Using AMA architecture, you can link clips to Media Composer directly from virtual media in local folders on the
computer to which you backed up or moved clips beforehand, using Canon XF Utility. This is convenient when you
want to use the CF card immediately to continue recording.
For details about backing up clips onto local folders in the computer, refer to Canon XF Utility Instruction Manual.
For details about linking media with AMA, refer to Avid Media Composer Advanced Guide.
1. Start up Avid Media Composer.
2. Select File > Link to AMA Volumes.
3. In the dialog box that opens, navigate to the local folder where the virtual media is stored and click Choose
or Open.
• To verify the location of the local folder where the virtual media was saved, control (^) -click on the desired
media in the media panel of Canon XF Utility and click Virtual Media Location in the contextual menu that
opens.
• The Bin window will open and show the clips saved in the selected local folder.
4. Continue the editing operation in Avid Media Composer.
Consult the software's guides and help files as necessary.
NOTES
• The clips will not be correctly recognized if any of the folder names in the selected path contains multibyte
characters. Move the files to a different folder with a directory path that includes only ASCII alphanumeric
characters and try linking the files again.
Trademark Acknowledgements
• Apple, Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.
• Avid and Media Composer are trademarks or registered trademarks of Avid Technology, Inc. or its subsidiaries in
the United States and/or other countries.
• Other names and products not mentioned above may be trademarks or registered trademarks of their respective
companies.
PUB. DIE-0372-000 © CANON INC. 2010
