CARDO SYSTEMS, INC. QUICK GUIDE

Cardo S-800™

Bluetooth®Headset

Cardo S-800™

Congratulations and thank you for choosing the Cardo S-800

Bluetooth®headset. This Quick Guide will help you learn about

the Cardo S-800’s many features, allowing you to make the best

use of your headset.

Cardo S-800 Overview

1 Microphone

2 Multi-Function Wheel (MFW)

3 LED Status Indicator

4 Power and Hot Dial

Button

5 Charging Jack

6 Control Button

(CTRL)

7 Speaker

8 Earloop

1 4 7

Cardo S-800™

Getting Started

To use your Cardo S-800 (“the headset”), please follow these

initial steps:

• Charge your headset

• Pair your headset with a Bluetooth®-enabled mobile phone.

1. Charging your Headset

The headset comes with a built-in rechargeable battery. Prior to

using the headset, make sure to charge the headset for at least 4

hours. Normally it takes approximately 2 hours to fully charge the

headset.

1. Connect the charger to an AC wall outlet and the charger plug to

the headset’s Charging Jack. The headset’s LED status indica--

tor will be red during charging.

2. When the battery is fully charged, the red LED will turn off.

3. Disconnect the charger from AC wall outlet and the headset.

NOTE: Charging indication may be delayed for a few seconds if the

headset has not been used for a long time or the battery is drained.

Cardo S-800™

The fully charged battery offers up to 8 hours talk time and up to

one week standby time.

2. Pairing your Headset

Before you can use your headset you must pair the headset to your

Bluetooth-enabled mobile phone. If you do not have a Bluetooth-enabled

mobile phone, please visit http://cardosystems.com/adapter2.php for

information on the Cardo BTA II Bluetooth Adapter.

1. Turn on your phone and turn ON its Bluetooth function.

2. Make sure the headset is turned OFF, then press and hold the

Power Button for approximately 8 seconds until the LED status

indicator begins alternating blue and red, indicating that the

headset is in Pairing Mode.

3. Set the phone to search for Bluetooth devices by following the

instructions in the phone’s user guide. This is usually found in the

phone’s Bluetooth menu and may referred to as “discover” or

“add” a device.

4. After a few seconds, the phone will list the “Cardo S-800” as a

discovered device. Select it from the list and press “OK” or “Yes”.

Cardo S-800™

5. When prompted, enter the passkey “0000” (4 zeros) and press

“OK” to complete the pairing.

6. When the pairing is complete, your phone will conrm that the

pairing was successful and the headset’s LED status indicator

will begin ashing slowly in blue.

You should now be able to make and receive calls using your

headset. To initially connect the headset to your phone, you may

need to tap the CTRL Button once on the headset.

IMPORTANT: If the pairing is not completed within 2 minutes while

the Pairing Mode is activated, the headset will return to Standby

mode, ashing blue once every three seconds and you must start

the Pairing process again from Step 2 above.

NOTE: Your headset can pair with up to 8 phones, and will

automatically connect to the last phone connected to the headset. To

connect to a different paired phone, go to the Bluetooth menu of the

active phone and disconnect the headset. Then go to the Bluetooth

menu of the phone you wish to connect and connect the headset by

selecting it from the list of Paired Devices.

Cardo S-800™

3. Wearing your Headset

The S-800 headset can be worn on either your left or right ear.

There are two ways in which you can wear the S-800 headset.

1. Without the earloop: Gently insert the headset without an earloop

into your ear, and it will hold itself in place securely.

2. With the earloop: Insert the straight portion of the pin of the ear--

loop to a suitable depth so that the speaker ts snugly in your ear.

The earloop is exible, and may be adjusted for

maximum comfort.

The lanyard for the S-800 provides an easy and

convenient way of carrying your headset while it is

not in use.

1. To attach the headset to the lanyard, insert

the speaker into the upper loop of the lanyard.

Then pull the headset downwards into the lower

loop, until it is held securely in place.

2. To release the headset from the lan--

yard, simply pull the headset upward.

Upper

loop

Lower

loop

Cardo S-800™

4. Using your Headset – Basic Functions

Function Required Action

Turn ON/OFF the

headset

Press and hold the Power Button for at

least 4 seconds

Answer a call Tap the CTRL Button*

End a call Tap the CTRL Button

Make a call from

your phone

Dial normally from your phone and the

call will be transferred to the headset

(subject to phone settings).

Make a call using

Voice Dial

During Standby, tap the CTRL Button,

wait for the tone and say the name

of the person you wish to call. (Your

mobile phone must support the Voice

Dial feature.)

Increase the volume Move the MFW up by steps. When you

hear a beep, it is at maximum.

Decrease the volume Move the MFW down by steps.When

you hear a beep, it is at minimum.

Mute the microphone During a call, tap the MFW inwards to

turn on/off mute.

* NOTE: Wait until you hear the incoming call on the headset (not

only on the phone)

Cardo S-800™

5. Using your Headset – Advanced Functions

1. Redial the last dialed number*

During Standby, press the MFW inwards to redial the last dialed number.

2. Reject an incoming call*

During an incoming call, press and hold the CTRL Button for 3 seconds.

3. Call waiting / Toggling between calls*

During an incoming call and one call on hold or waiting, tap the MFW

inwards to answer the incoming call or toggle between calls.

4. Conference call*

During an active call and one call on hold or waiting, tap the MFW

inwards for 3 seconds to combine both calls into a Conference call.

5. Transfer calls to/from headset*

During a call, press and hold the CTRL Button for 3 seconds to

transfer the call between the headset and the mobile phone.

NOTE: On some phones, transferring a call to the headset

requires just a tap of the CTRL Button.

* These features are only supported by mobile phones that include the Bluetooth

Handsfree prole.

Cardo S-800™

6. Hot Dial Function

The S-800 allows you easily call any of three different phone

numbers at the press of a button.

In order to use the Hot Dial function, you must rst congure

your mobile phone’s Speed Dial settings. Please refer to your

mobile phone’s user guide or our website (www.cardosystems.com)

for instructions on saving Speed Dial numbers.

To Hot Dial:

• Speed dial #2: Tap the Hot Dial Button once.

• Speed dial #3: Tap the Hot Dial Button twice rapidly.

• Speed dial #4: Tap the Hot Dial Button three times rapidly.

7. SWAP (Swapping connection between two active mobile

phones)

The S-800 allows you to swap, i.e. to alternately use one among

the last two phones to which it has been connected.

To SWAP between phones:

• While both phones are turned on and the headset is in

Standby mode, double-press the MFW inwards.

Cardo S-800™

• The headset will switch to the second phone.

• Each time you double-press the MFW, the alternate phone

connects to the headset.

NOTE: This feature may only be used when the headset

and both phones are in Standby mode.

8. Battery Status Indicator

To check the status of the headset’s battery, press and hold the CTRL

Button for at least four seconds while the headset is in Standby mode.

The LED Status Indicator will ash for two seconds as follows:

• Blue Full charged

• Red and Blue Medium charge

• Red Weak charge

9. Locating the Headset (Buzzer Function)

The S-800 allows you to locate the headset by activating an

audible buzzer.

To activate the Buzzer:

• Dial a number with the mobile phone and press Send/Talk.

• While the call is in progress (or even while still ringing), turn
