CareCo Comet Bedienungsanleitung
Product Code: WA01083
USER MANUAL
WA01083
P. 2
PRODUCT CODE WA01083
Product Code: WA01083
N.B. This equipment must be installed by a competent person.
Maximum Load 136kg*
Maximum User Weight 136kg*
Do not exceed the weight limit stated - doing so could put the user at risk.
* For avoidance of doubt if user is 130kg then no more than 6kg can be carried.
BEFORE USE
• Carefully remove all packaging. Avoid using any knives or other sharp instruments as this
may damage the surface of the product.
• Check the product for any visible damage. If you see any damage or suspect a fault, do not
use your product, but contact your supplier for support.
INTENDED USE
Rollator has been designed to assist you when walking and carrying small items of shopping
using the bag provided. The bag was designed specically to t your rollator, please only
use the bag supplied for your rollator. Do not use or combine bags and / or baskets from
other manufacturers.
FEATURES
• User friendly loop brakes with lock
• Simple brake cable adjustment
• Soft plastic solid wheels
• Swivelling front wheels
• Folding locking mechanism
• Height adjustable
• Ergonomic handgrips to reduce pressure
• Walking stick holder
• For Indoor & Outdoor Use
• Multiple Users & Multiple Use product
i
P. 3
PRODUCT CODE WA01083
Product Code: WA01083
ASSEMBLY INSTRUCTIONS
Carefully remove all packaging, including the cardboard tubes covering the knurled tube part
of the brake assembly. Check the product thoroughly for damage or obvious faults.
Handgrip
Height Adjustable
Handles
Backrest
Cane Holder
Rear Wheels
Front Wheels
Seat
WARNING!
If you suspect the unit to faulty, please do not use, but contact
your supplier immediately for service.
P. 4
PRODUCT CODE WA01083
Product Code: WA01083
ASSEMBLY INSTRUCTIONS (CONTINUED)
The rollator is supplied fully assembled in its folded position. To unfold the rollator follow these
instructions.
Step 1:
Open the rollator by pulling the handles away from each other (see g. 1)
Step 2:
Push down on the seat (see g. 2) making sure that the seat arms click into the seat brackets
(see g. 3). DO NOT USE THE ROLLATOR UNLESS THE SEAT ARMS ARE FULLY LOCKED INTO
THE SEAT BRACKETS.
Step 3:
Lower the rear legs by pulling up both sides of the red catch (see g. 4) and lowering the leg into
position. Repeat step 3 for the other rear leg. A click will be heard when the leg has locked into
place. DO NOT USE THE ROLLATOR UNLESS THE LEG HAS SECURELY LOCKED INTO PLACE.
Step 4:
Lower the front wheels by pushing the red catch down (see g. 5) and lowering the wheel into
position. Repeat step 4 for the other front wheel. A click will be heard when the wheel has
locked into place. DO NOT USE THE ROLLATOR UNLESS THE WHEEL HAS SECURELY LOCKED
INTO PLACE.
g. 1 g. 2
g. 3
g. 5
g. 4
P. 5
PRODUCT CODE WA01083
Product Code: WA01083
HEIGHT ADJUSTMENT
g. 6
The height of the handgrips can be raised or
lowered to suit the user.
To adjust the height of the handgrips Press
the height adjustment spring button (see
g. 6). Raise or lower the handgrips to the
desired user height. You will hear a click as
the handgrip locks into one of the height
adjustment positions (see g. 6).
ENSURE THAT BOTH HANDGRIPS ARE AT
THE SAME HEIGHT BEFORE USE.
DO NOT USE THE ROLLATOR UNLESS THE HANDGRIPS HAVE LOCKED INTO ONE OF THE
HEIGHT ADJUSTMENT POSITIONS.
OPERATING THE BRAKES
g. 7
1. To stop, gently apply a gripping pressure to both brakes
simultaneously (see g. 7), this will slow down and stop your
rollator.
g. 8
2. The brakes on your rollator have a park option (see g. 8). To
operate the park option, push downwards on both brakes
simultaneously. You will feel the brake make a very slight click.
Your brakes are now in the ‘lock’ position.
3. To unlock, simply pull up the brake again, you will hear a slight
click as the ‘park’ disengages.
Height Adjustable
Spring Button
P. 6
PRODUCT CODE WA01083
Product Code: WA01083
BRAKE ADJUSTMENT
Your rollator brake system will require
periodic adjustment. To adjust the brakes
loosen Nut B and then screw/unscrew
Nut A. When adjusted re-tighten Nut B. If
further adjustment is required then loosen
the Locking Screw and then using a pair of
pliers pull the cable down by approximately
a millimetre. Re-tighten Locking Screw. The
brakes can then be adjusted further by
loosening Nut B and screwing / unscrewing
Nut A as before (see g. 9).
g. 9
REISSUE
If you reissue or are about to reissue this product, please thoroughly check all components for
their safety.
This includes:
• Bent or damaged tubes or cracks at the tube joints
• Loose or worn horseshoe clips
• Elongated adjustment holes
• Loose handles
• Loose or worn wheels and wheel fasteners (where tted)
• Smooth, worn or split ferrules (rubber tips)
Replace all worn, missing or damaged parts where necessary. If in any doubt, please do
not issue or use, but immediately contact your supplier for service support.
Nut A
Nut B
Spring
Cable
Locking
Screw
P. 7
PRODUCT CODE WA01083
Product Code: WA01083
CARE AND MAINTENANCE & YOUR OBLIGATION
1. Only use your rollator for the purpose for which it intended, which is as an aid to walking. It
is intended your rollator is only used on standard pavements or at home. It should not be
used on rough terrain or pot-holed surfaces. The use of your rollator on these surfaces can
seriously compromise your safety and may damage your rollator beyond repair.
2. Keep your rollator clean by wiping down with a damp cloth with a mild detergent. Do not
under any circumstances use an abrasive or solvent based cleaner, as this will seriously
damage the rollator and void your warranty.
3. Wipe o all surfaces with a dry cloth and use a water dispersing agent such as WD40 on all
metal joints.
4. Check that all wheels and the folding mechanism function correctly and that all wheels
move freely. Pay particular attention to the front wheels, ensuring that they rotate freely
and without obstruction and that they are attached securely to the frame.
5. Monthly Checks - Check that no components are loose. Check the adjustment to your brakes
(g. 9). Check castors.
6. Do not t any parts or accessories to your rollator manufactured by another company.
To do so will annul your warranty and may seriously compromise your safety.
7. We suggest that you check your rollator visually every day. However we recommend that
you should have your rollator serviced every three months or less if used by, or issued to,
various users.
MAINTENANCE
Please conduct a safety check of the product at regular intervals or if you have any concerns.
WARRANTY
This product carries a 12 month warranty from the date of purchase against manufacturing
defects. Misuse or Damage is not covered. This warranty does not aect your statutory rights.
WARNING!
Withdraw your rollator immediately if any of the wheels become
dicult to turn or do not feel securely attached to the frame or if
you suspect damage or any other fault.
SEE PRODUCT LABEL
SEE PRODUCT LABEL
PRODUCT CODE WA01083
Product Code: WA01083
TECHNICAL SPECIFICATIONS
Min height 78.5cm / 785mm
Max height 96cm / 960mm
Length 66cm / 660mm
Width 64.5cm / 645mm
Folded width 27cm / 270mm
Folded height 34cm / 340mm
Folded length 60cm / 600mm
Min / Max seat height 53.5cm / 535mm
Seat width 46cm / 460mm
Seat depth 25cm / 250mm
Total weight (kg) 8.2
Carry weight (kg)
Rear wheel size 19.9 x 3cm / 199x30mm
Front wheel size 19.9 x 3 / 199x30mm
Max user weight (kg) 136
Frame material Aluminium
Wheel material PP rim+PVC tyre
Handle material PA6+30%GF
Suspension No
Bag depth 34cm / 340mm
Bag width 10cm / 100mm
Bag length 38cm / 380mm
5 056059 113722
