CAS BP-DT-4 Bedienungsanleitung

CONTENTS

1. PRECAUTIONS................................................................4

2. BARCODE PRINTER...................................................5

2-1. Printer Accessories.............................................................5

2-2. General Specifications.......................................................5

2-3. Communication Interface ................................................7

2-4. Printer Parts .......................................................................8

3. PRINTER INSTALLATION....................................10

3-1. Label Installation .............................................................10

3-2. Label Roll Core Switch ...................................................12

3-3. PC Connection..................................................................13

3-4. Driver Installation............................................................14

4. ACCESSORY....................................................................16

4-1. Stripper Module Installation..........................................16

4-2. Cutter Module Installation.............................................19

5. PRINTER SETTING....................................................22

5-1. FEED Key .........................................................................22

5-2. LED Status ........................................................................22

5-3. Auto Sensing .....................................................................22

5-4. Self-Test..............................................................................23

5-5. Dump-Mode......................................................................23

5-6. Error Messages.................................................................24

6. MAINTENANCE AND ADJUSTMENT...........25

6-1. Thermal Print Head Cleaning .......................................25

6-2. Adjust the Cutter..............................................................26

6-3. Troubleshooting................................................................27

1. PRECAUTIONS

Please read the following instructions seriously.

1) Keep the equipment away from humidity.

2) Before you connect the equipment to the power outlet, please check the voltage of the power source.

3) Disconnect the equipment from the voltage of the power source to prevent possible transient over

voltage damage.

4) Don’t pour any liquid to the equipment toavoid electrical shock.

5) ONLYqualified service personnel for safety reason should open equipment.

6) Don’t repairor adjust energized equipment alone under any circumstances. Someone capable of

providing first aid must always be present foryour safety

7)Always obtain first aid or medical attention immediately after aninjury. Never neglectan injury,

no matter how slight it seems.

2. BARCODE PRINTER

2-1. PrinterAccessories

After unpacking, please checkthe accessories that comewith the package, and store appropriately.

■Barcode printer

■Powercord

■Switching Power

■USB Cable

■Label

■Quick Start Guide

■CD (includes labelediting software QLabel / Manual)

BP-DT-4

2-2. General Specifications

MODEL BP-DT-4

PrintMethod Direct Thermal

Resolution 203dpi(8 dot/mm)

PrintSpeed 4IPS(100mm/s)

PrintWidth 108mm(4.25 Inch)

PrintLength Min.10mm(0.39Inch)** ; Max. 1727mm(68 Inch)

Memory 4MBFlash(UserMemory2MB);8MB SDRAM

SensorType Adjustablereflective sensor.Fixedtransmissivesensor, central aligned

Types: Continuous form, gap labels, black mark sensing, and punched hole;

labellengthsetbyautosensing or programming

Media Width:1” (25.4 mm) Min.- 4.64” (118mm) Max.

Thickness:0.003”(0.06mm)Min. - 0.008” (0.20 mm)Max.

Labelrolldiameter:Max.5” (127 mm)

Corediameter:1”, 1.5” (25.4 mm, 38.1 mm)

PrinterLanguage EZPL,GEPL, GZPL

Software Labeldesign software:QLabel-IV (for EZPLonly)

Driver&DLL:Windows2000,XPand Vista

ResidentFonts

Bitmapfonts:6, 8, 10, 12, 14, 18, 24,30, 16X26andOCRA& B

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°

rotatable

Bitmapfonts8 times expandableinhorizontaland vertical directions

Scalablefonts90°, 180°, 270° rotatable

DownloadFonts

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°

rotatable

Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal

andverticaldirections

Scalablefonts90°, 180°, 270° rotatable

1-DBar codes:

Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart,

UCC/EAN-128, UPC A / E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping

Bearer Bars, EAN 8 / 13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN

14, HIBC, MSI (1 Mod 10), Random Weight, Telepen, FIM, China Postal

Code,RPS128and GS1 DataBar

Barcodes

2-DBar codes:

PDF417,Datamatrixcode, MaxiCode,QR code andMicro QR code

CodePages

CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866,

869,737

WINDOWS1250,1251, 1252, 1253, 1254, 1255

Unicode(UTF8,UTF16)

Graphics Resident graphic file types are BMP and PCX, other graphic formats are

downloadablefromthesoftware

Interfaces USBport:V2.0

Serialport:RS-232(DB-9)

ControlPanel OneTri-colorLED: Power (Green,Orange and Red)

Controlkey:FEED

AgencyApprovals CE(EMC), FCC ClassA, CB, CCC

Power 100-240VAC, 50-60Hz

Environment Operationtemperature : 41°F to 104°F (5°Cto40°C)

Storagetemperature:-4°F to 122°F (-20°Cto 50°C)

Humidity Operation:30-85%, non-condensing.

Storage:10-90%,non-condensing.

Dimension Length:8.58”(218 mm)

Height:6.53”(166mm)

Width:6.61” (168 mm)

Weight 1.5kg

Options

Parallelport(Centronics 36-pin)

EthernetCard

LabelStripper

CutterModule

2-3. Communication Interface

Serial Interface

Serial Default Setting : 9600 baud rate､no parity､8 data bits､1 stopbit､

XON/XOFF protocol ,RTS/CTS。

RS232 HOUSING(9-pin to 9-pin)

DB9 SOCKET DB9 PLUG

- - - 1____________________________________1 +5V, max 500mA

RXD 2____________________________________2 TXD

TXD 3____________________________________3 RXD

DTR 4____________________________________4 N/C

GND 5____________________________________5 GND

DSR 6____________________________________6 RTS

RTS 7____________________________________7 CTS

CTS 8____________________________________8 RTS

RI 9____________________________________9 N/C

PC PRINTER

Note. The total current output from serial portcan not exceed 500mA.

USB Interface

Connector Type : Type B

PINNO. 1 2 3 4

FUNCTION VBUS D - D + GND

Internal Interface

UART1 wafer Ethernet module

N.C 1____________________________________1 N.C

TXD 2____________________________________2 RXD

RXD 3____________________________________3 TXD

CTS 4____________________________________4 RTS

GND 5____________________________________5 GND

RTS 6____________________________________6 CTS

E_MD 7____________________________________7 E_MD

RTS 8____________________________________8 CTS

E_RST 9____________________________________9 E_RST

+5V 10__________________________________10 +5V

GND 11__________________________________11 GND

+5V 12__________________________________12 +5V

2-4. Printer Parts

1 LED Light

2 FEED Key

3 Top Cover

4 Power Switch

5 Cover Open Button

1 Print Head Lift

2 LabelRllHlder

3 PrinterMechanism

4 LabelRollCore

5 Labelguide

6 FrontCover Piece

1 Platen Cover

2 Label Sensor

3 Platen Roller

1 Power Socket

2 USB Port

3 Fan-fold Label Insert

4 Serial Port(RS-232)

1 Bottom Case Cover

2 Hang Holes

3. PRINTER INSTALLATION

3-1. Label Installation

1. Place the printer on a

horizontal surface and open

the Top Cover

2. Press and release the lock

of Label Roll Core

3. Pull up the Label Roll Holder

and lift the Label Roll Core

upward.

4. Place a new label roll onto

the Label Roll Core.

5. Flip the Label Roll Core

downward and pull back the

Label Roll Holder.

6. Pull and lock the Label Roll

Core to the original position.

7. Put the label under the Label

Guide and stretch it frontward.

8. Pull the Label Guide inward

and make it fit the edge of label

9. Close the Top Cover to

complete the label installation.
