CAS DB-1H Bedienungsanleitung
9002-DBH-0033-2
2002. 3
DB-1H
Bench Scale
OWNER’S MANUAL
CAS Bldg. # 440-1, Sungnae-Dong,
Kangdong-Gu Seoul Korea
CONTENTS
PRECAUTIONS 4
PREFACE 6
NAMES AND FUNCTIONS 6
INSTALLATIONS 7
OPERATIONS 8
1. General Weighing 8
2. Weighing with Tare 9
ERROR MESSAGES 9
SPECIFICATIONS 10
SPECIFICATIONS FOR CE MARKED PRODUCT 11
45
Keep the scale away from strong EMI noises may cause incorrect weight
readings.
Do not subject the scale to sudden
temperature changes.
PRECAUTIONS
Place the scale on a flat and stable
surface.
If the scale is not properly
level, please adjust the 4 legs
at the bottom of the scale
(turn legs clockwise or
counterclockwise) so as to
center the bubble of the
leveling gauge inside the
indicated circle (See Fig.)
Do not subject the platter to sudden
shocks. This scale must be installed in a dry
and liquid free environment.
Leveling gauge
Make sure that you plug your scale into the proper power outlet.
Plug into a power outlet 30 minutes before operations.
7
6
PREFACE
NAMES AND FUNCTIONS
Thank you for purchasing our CAS DB-1H series scale.
These series have been designed with CAS reliability, under rigid quality control
and with outstanding performance. Your specialty departments can enjoy these
high quality reliable CAS products.
We believe that your needs will be satisfied and you will have reliability.
This manual will help you with proper operation and care of the DB-1H series.
Please keep this handy for future reference.
OVERALL VIEW
DISPLAY
PLATTER
LEVELING GAUGE
SUPPORT
DISPLAY
HEAD KEYBOARD
ADJUSTING BOLT
Max 300kg Min 1kg e=d=50g
NET kg
KEYBOARD
*
Turn the displays on or off.
Used to correct the zero point.
Used to enter a tare weight.
Used to clear a tare weight.
No function key.
KEYS FUNCTIONS
INSTALLATIONS
1. Insert the power line into the support.
Fasten with bolts and nuts as fig 1. 2. Fix a ground wire with bolt then
arrange the power line and loadcell
line as fig 2.
Power
line
Bushing
Ground wire
Bolt
Nut
Washer Head
Ground wire
Power line
Load cell
wire
fig. 1 fig. 2
9
8
3. Insert the support cover into the
support as fig 3. 4. Attach the head to the support.
Insert and fasten stop bolt as fig 4.
Support
Stop bolt
Support
cover
1. General Weighing
Wait until the display becomes zero state.
NET NET
Place the commodity on
the platter. Remove the commodity
from the platter.
NET NET NET
Place the container on the
platter. Press the key. Place the commodity in the
container.
NET NET NET
Remove the commodity
from the platter. Remove the container from
the platter, then you will
see tare weight with “
-
”.
Press “ ” key.
2. Weighing with Tare
Tare is the weight of container being used for a commodity.
The key subtracts the weight of the container.
ERROR MESSAGES
To help the customer’s understanding, this scale warns the user with proper error
message.
Please refer to the table below.
An error of the initial ZERO range
Failure of returning the normal mode
Failure of the analog module
Failure of the digital module
Condition codes are broken
1.Make sure the platter is empty
2.Make sure there is a platter on the scale
Call your CAS dealer
Call your CAS dealer
Call your CAS dealer
Call your CAS dealer
ERROR REASON SOLUTIONS
Err 1
Err 2
Err 10
Err 11
Err 12
OPERATIONS
When you turn on the power switch, the scale will count “00000” to “99999”.
Then the scale will read “0.00” in the weight display. This is called the ZERO
state. If the scale is not ZERO state though there is nothing on the platter,
press the key.
The display indicates if the scale is at zero or if there is a tare entered into the
scale by way of a and NET lamps.
fig. 3 fig. 4
2. Electrical conditions for LVD (Low Voltage Directive) testing.
Power source: AC 220V ~ 240V 50Hz, 250mA, 10W
Insulation class:
3. Environment Conditions for non-automatic weighing instrument.
This product is intended to be “indoor use”.
Altitude: less 2000m
Temperature range: 10°C 40°C
Maximum RH 80% (31°C), decreasing linearly to 50% RH at 40°C.
Supply voltage fluctuations: 10% of the normal voltage.
Installation category:
Pollution degree:
4. Capacity: 30kg 10g, 60kg 20g, 150kg 50g
5. How to connect the power supply
The power switch is located on the left side of the scale. Make sure that the
power switch is “OFF”.
Plug the scale into AC socket and make sure that the socket’s power is within
the scale’s operating range. Turn the power switch “ON”.
6. The socket-outlet shall be installed near the equipment and shall be easily
accessible.
7. Do not pour water directly on the scale. Use the plastic cleaner to clean your
scale.
8. Changes or modifications not expressly approved by manufacturer for
compliance could void the user’s authority to operate the equipment.
; Above statements can be applied to CE marked product.
11
10
SPECIFICATIONS
MODEL
CAPACITY
DISPLAY:
WEIGHT
DISPLAY DESIGNATORS
MAXIMUM TARE
POWER SOURCE
POWER CONSUMPTION
PLATTER SIZE (mm)
PRODUCT SIZE (mm)
Notice: Specifications are subject to change for improvement
without notice.
DB-1H
30kg 5/10g 60kg 10/20g 150kg 20/50g
Vacuum Fluorescent Display
5 DIGIT
and NET
-30.00kg -60.00kg -99.95kg
110/220V, 50/60Hz
APPROX. 10W
530(W) 406(D)
420(W) 635(D) 765(H)
IEC 417. NO. 5032
IEC 417. NO. 5019
ALTERNATING CURRENT
PROTECTIVE CONDUCTOR TERMINAL
SYMBOL PUBLICATION DESCRIPTION
1. Symbol Description
SPECIFICATIONS FOR CE MARKED PRODUCT
