Casio DT-800RF Technisches Dokument
Supported Equipment Manual
For the DT-800RF Device Manufactured by Casio
Copyright ©1996 - 2006 by Connect, Inc.
All rights reserved. This document may not be reproduced in full or in part, in any form,
without prior written permission of Connect Inc., 1701 Quincy Avenue, Suites 5 & 6,
Naperville, IL 60540.
Connect, Inc. makes no representation or warranties with respect to the contents
of this document and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Further, Connect, Inc.
reserves the right to revise this publication and to make changes to it from time to
time without obligation to notify any person or organization of such revision or
changes.
Trademarks
PowerNet OpenAir™, OpenAir Linux™, OpenAir Windows™, OpenAir 400™,
PowerNet Twin Client™, and PowerNet AirLinc™ are trademarks of Connect,
Inc.
Other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.
Production
This manual was written, edited, and produced by:
Connect, Inc.
1701 Quincy Avenue,
Suites 5 & 6
Naperville, IL 60540
www.connectrf.com
Printed in the U.S.A.
Please let us know about any errors in this document at:
http://207.241.78.223/isoxpert/calltrak.nsf/WebTracking?OpenForm
Table of Contents
Chapter 1 • Introduction............................................................................................. 1-1
Description………………… ..........................................................................................1-1
Picture………………………...........................................................................................1-2
Setup Requirements…….. ...........................................................................................1-2
Accessories……………….............................................................................................1-2
Operating System………… ..........................................................................................1-4
Chapter 2 • Terminal Setup........................................................................................ 2-1
Running Setup from a Download File ........................................................................2-1
Installation………………… ...........................................................................................2-2
Running the Manager……………………………………………………………………….2-4
Quick Start………………… ...........................................................................................2-5
Configuring the Manager....................................................................................2-5
Configuring the Terminal for Download..............................................................2-9
Terminal Settings .............................................................................................2-10
Starting a Telnet Session .................................................................................2-11
Standard Setup…………….........................................................................................2-12
Setup Using Twin Client Manager....................................................................2-12
Terminal Setup Using Twin Client Menus ........................................................2-18
Authorizing PowerNet.......................................................................................2-20
Software Management……........................................................................................2-22
Auto-Configuration ...........................................................................................2-22
Chapter 3 • Keypad Configuration ............................................................................ 3-1
Keypad Figures…………… ..........................................................................................3-1
Keypad Table……………… ..........................................................................................3-4
Chapter 4 • Error Message Resolution Guide .......................................................... 4-1
Supported Equipment Manual
•
March, 2006 iii
This page is intentionally blank.
iv Supported Equipment Manual
•
March, 2006
Chapter 1 • Introduction
Description
The DT-800RF has a versatile high-speed scanning (100 scans per second) that
ensures a rapid first-time read rate and high data integrity. Its combination of
distance and contact laser scanning allows bar codes to be easily read even when
badly printed on curved and irregular surfaces. Amongst the lightest weight
terminals in its class, the compact lightweight design of the DT-800RF reduces
operator fatigue over extended usage periods. Its backlit display can be illuminated,
enabling readings to be clearly seen in the darkest of work environments.
This terminal has a world-class water splash proof (IPX II standard) that provides
continuous operations, even in the rain. Using the latest multi-drop communications
technology, data can be collected at many different networked points connected to a
single PC. Low-power circuitry and an automatic power-off feature conserve battery
life to the maximum and provide more usage time before replacement. A
rechargeable battery reduces the need to dispose of dead batteries and helps to
conserve the environment.
The DT-800RF’s 160 x 160-dot screen displays extensive lines of information. This
touch screen can also be used for entering data quickly and easily. You may choose
between 2.6 or 10 Mbytes of memory to meet your specific requirements. Control
functions (such as “Help” or “Send”) can be assigned to the DT-800RF special
function keys to further enhance operation.
Master I/O boxes, including SCSI or Ethernet connection, allow the configuration of
a large-scale system with satellite I/O boxes for high speed, large volume data
transfer. The DT-800RF can be set to read all common bar code symbologies with a
narrow bar width as small as 0.125mm. Infrared communications on this terminal
allow data to be downloaded or uploaded without the need to connect any cables,
thus ensuring trouble-free connection to a host system.
For more information, contact www.casio.com.
Supported Equipment Manual
•
March, 2006
1-1
Introduction
Setup Requirements
Installation of PowerNet Twin Client requires, at a minimum, the following:
• A Pentium-class processor
• 32 MB of RAM
• 10 MB of free hard disk space available
• Microsoft Windows 95, 98, ME, XP, or NT/2000 operating system
Accessories
The following accessories are available for the DT-800RF:
I/O Box
• DT-860IOE (satellite I/O box)
• DT-865IOE (master I/O box)
Charger (Single-Pack)
• DT-820CHGE (Quick charger)
Lithium Ion Battery Pack
• DT-823LI
Supported Equipment Manual •March, 2006
1-2
Accessories
AC Adaptors
• DT-9020ADPG (AC adaptor (230V) for DT-820CHGE)
• DT-9020ADPU (AC adaptor (120V) for DT-820CHGE)
• DT-825ADP-G (AC adaptor (230V) for I/O boxes)
• DT-825ADP-U (AC adaptor (120V) for I/O boxes)
Cables
• DT-881RSC-E: RS232C Modem cable
• DT-882RSC-E: RS232C Cross cable
(between DT860IO-E and PC: 25pin male)
• DT-883RSC-E: RS232C Cross cable
(between DT860IO-E and PC: 25pin female)
• DT-887AX: RS232C Cross cable
(between DT860IO-E and PC: 9pin female)
• DT-888RSC: Modular Cable
• DT-889AX: Cable (between DT-800RF and PC)
• SB-751HF: SCSI cable
(between DT865IO-E and PC: Centro 50pin full male)
• SB-752HH: SCSI cable
(between DT865IO-E and PC: Centro 50pin half male)
• SB-753HP: SCSI cable
(between DT865IO-E and PC: Pin type half 50pin male)
Supported Equipment Manual
•
March, 2006
1-3
Introduction
Operating System
Version of the Operating System
The version of the operating system on a DT-800RF terminal is 2.00.
Finding the Version of the Operating System
The version of operating system will appear on a terminal screen when the terminal is
rebooted. For rebooting instructions, see Command Mode Boot in the Quick Start
section.
Supported Equipment Manual •March, 2006
1-4
Chapter 2 • Terminal Setup
Running Setup from a Download File
The downloaded file is a compressed archive. After extraction using a utility such as
WinZip or PKWARE, folders are created on the hard disk as shown in the following
figure.
Click on the Disk1 folder to view the files as shown in the following figure.
Click on the Setup application and proceed to the following section entitled Installation
for further instructions.
Supported Equipment Manual
•
March, 2006 2-1
Terminal Setup
Installation
The InstallShield wizard runs and presents the following screen.
Click on Next to begin the installation process.
Supported Equipment Manual •March, 2006
2-2
