CDA rv961 Referenzhandbuch
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
rv961 Range Cooker
Manual for Installation, Use and Maintenance
2
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking. Any other use could be dangerous
and may lead to premature failure of the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
3
CE Declarations of Conformity:
This appliance has been designed, constructed and marketed in
compliance with safety requirements of EEC Directive 2006/95/
EEC (Low voltage) and requirements of EMC Directive 2004/108/EEC.
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to EEC/89/109.4
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority dierentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
4
User Information
• Read the instructions carefully before using the cooker.
• Keep the instructions in a safe place for future reference.
• Follow the instructions for first use (page 6).
• Always use oven gloves when removing shelves and trays from the
cooker.
• Always grill with the door closed.
• Do not grill food containing fat without using the grill pan grid.
• Do not use the grill pan for roasting.
• Do not place cooking utensils or plates directly on the oven base.
• Do not cover the grill pan grid or the oven walls with aluminium foil.
• Do not store inflammable substances or items that cannot withstand
heat (such as wood, paper, cloths, spray cans, etc.) in the storage
drawer.
• Do not attempt to repair the internal workings of your oven.
• Cookers become hot during and immediately after use. Do not
touch the oven internal parts or the hob until the appliance has
been allowed to cool.
• After use, ensure that all the control knobs are switched o.
• Keep children away from the cooker when in use and immediately
after use.
• This cooker has been designed for use only as a cooking appliance.
Any other use (e.g. heating rooms) should be considered incorrect
and therefore dangerous.
• Never put cooking foil or plastic materials on the ceramic surface
when the hob is hot. These materials could melt and cause damage
to the hob.
• Never use the hob top for storage.
5
• Pan handles should never stand out beyond the edge of the
worktop. This will help ensure children cannot reach them.
• Do not use pans with rough bases (e.g. cast iron) as these may
scratch the hob surface.
• Do not switch on the hob zones without cookware in place.
• Do not lean over the hob when it is in use.
• Follow the cleaning instructions carefully.
• Ensure any base of the saucepan is clean and dry before placing it
on the hob to prevent damage to the surface of the hob.
• The appliance is not intended to be operated by any means of an
external timer or separate remote-control system.
• Do not use the hob if the glass surface is cracked or damaged,
to prevent risk of electric shock. Disconnect it from the power
supply.
When correctly installed, your product meets all safety
requirements laid down for this type of product. However, special
care should be taken around the rear or the underneath of the
appliance as these areas are not designed or intended to be
touched and may contain sharp or rough edges that could cause
injury.
6
Before First Use
Before using the ovens for the first time we recommend that you
clean them with soapy water, rinse carefully and then heat on each
of the below programmes at maximum temperature for the specified
time. A slightly unpleasant smell may be produced, caused by grease
remaining on the oven elements from the production process.
Please note:
• This range cooker has been fitted with a cooling fan to achieve
maximum eciency and to maintain low surface temperatures. The
cooling fan will switch on automatically when the ovens reach a
preset temperature and switch o automatically when the ovens
have cooled suciently, even after the ovens are switched o.
• The range cooker is equipped with a safety thermostat which will
switch o the ovens to prevent overheating. Overheating can be
caused by incorrect use of an oven or defective components. If
an oven switches o due to overheating, wait for the oven to cool
down before using it again. If the error continues, contact CDA
Customer Care.
15 minutes grill 60 minutes fan oven 60 minutes
conventional oven
7
Fig. 1
Hob:
1. Front left dual zone 1.0/2.2kW / 140/210mm
2. Rear left zone 1.2kW / 140mm
3. Centre dual zone 1.1/2.0kW 140x250mm
4. Rear right zone 1.8kW / 180mm
5. Front right zone 1.2kW / 140mm
6. Residual heat indicators
Control panel:
7. Timer control
8. Left oven function control
9. Left oven temperature control
10. Right oven function control
11. Front left dual zone control
12. Rear left zone control
13. Centre dual zone control
14. Rear right zone control
15. Front right zone control
1
43
2
5
15
7 8 9 10 11 12 13 14
00 00
00 00
00
6
8
How to Use the Hob
The ceramic surface of the hob allows fast transmission of heat
vertically from the heating elements under the glass to the pans on
the hob top.
The heat does not spread horizontally, so the hob top remains
relatively cool only a few centimetres from the zone in use.
Please note:
The heating elements are equipped with a temperature limiter that will
switch the element o to prevent damage to the hob.
The temperature limiter may also operate when incorrect pans
are used or pans are poorly positioned. This will aect cooking
performance.
The temperature limiter can be seen in the zone as the straight line
out from the centre of the element. This is not a fault with the hob.
Using the single zones
The heating element is formed of a coil of resistant material which
reaches the required cooking temperature quickly.
Before using the hob, first check the hob and the pan are clean and
dry, then place the pan correctly onto the zone.
The power level for each zone can be regulated by turning the
control knob to the required level between 0 (o) and MAX
(maximum).
9
Using the dual zones
The dual zones are formed of two separate coils of resistant material.
To turn on the dual zone, turn the control knob fully clockwise to
the position.
Residual heat indicators
The hob is equipped with residual heat indicators which warn when
any of the zones are hot to the touch, both during and after cooking.
A light will show on the display to indicate a zone is hot until the zone
is at a safe temperature to touch, when the residual heat indicator will
switch o.
Please note:
You should avoid touching the zones when the hob is in use, or
when a residual heat indicator is on.
In the event of a power cut, the residual heat indicators will illuminate
after the power supply is restored. However, when there is no power
supply to the hob the residual heat indicators will not work, so extra
care must be taken.
10
Ecient Use of Your Hob
The hob is equipped with zones of dierent sizes, designed to
accommodate most shapes and sizes of pan. For best results, only
use pans with flat bottoms and choose appropriate zones depending
on the sizes of the pans. The most ecient use of the hob is shown
below, where the pans and zones are correctly chosen.
Use pan lids where possible to minimize the energy usage of your
appliance.
Turn o each zone a few minutes before the end of cooking time.
The residual heat in the zones will continue to cook the food for the
remaining cooking time.
It is very important that the pans used on the hob are made of a
suitable material and have the correct type of base. The base should
be flat and smooth, as any rough part on the pan base could scratch
the ceramic hob top.
Zone Size Minimum Pan Size (cm) Maximum Pan Size (cm)
140 mm 14 16
180 mm 16 20
220 mm 20 24
fig.2
