CDA EVPK90 Technisches Datenblatt
2
Contents:
3 Important information
4 Important safety warnings
5 Using your extractor
6 Intensive function
6 Clean air function
7 Care and maintenance
8 Changing the charcoal filter
9 Changing a light bulb
10 Mains electricity connection
11 Electrical information
11 Troubleshooting
12 Installation - preparation
13 Ducting
14 Installation
15 Installation - assembly
16 Installation - mounting
18 If re-circulating
19 Energy eciency information
3
Important
The manufacturer cannot be held responsible for injuries
or losses caused by incorrect use or installation of this
product. Please note that the manufacturer reserves the
right to invalidate the guarantee supplied with this product
following incorrect installation or misuse of the appliance or
use in a commercial environment.
This appliance is not designed to be used by people
(including children) with reduced physical, sensorial or
mental capacity, or who lack experience or knowledge
about it, unless they have had supervision or instructions on
how to use the appliance by someone who is responsible
for their safety.
Under no circumstances should any external covers be
removed for servicing or maintenance except by suitably
qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault
with your appliance and to register your appliance for guarantee
purposes.
Appliance Model
Serial Number
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing appliance
recycling services. Disposing of a household appliance separately
avoids possible negative consequences for the environment and
health. It also enables the constituent materials to be recovered, saving
both energy and resources. As a reminder of the need to dispose of
household appliances separately, the product is marked with a crossed-
out wheeled dustbin.
Please note:
3
Declarations of Conformity:
This appliance has been manufactured to comply with all EU & UK statutory requirements and complies with all applicable legislation and following European directives:•The Low Voltage Directive 2014/35/EU•Electromagnetic Compatibility Directive 2014/30/EUThe product has been marked with the UKCA and CE symbols.This appliance is marked according to the European directive 2004/104/EC on Waste Electrical and Electronic equipment (WEEE).•Under no circumstances should the extractor be connected to any gas
ventilation system, flue system or hot air ducting system.
•Do not vent the extractor into an attic or loft space.
•Only house the extractor in rooms with adequate ventilation.
Remember that the extractor is powerful and whatever air is extracted
needs to be replaced.
•Do not tile the extractor in. It should be removable for service ormaintenance.
5
•Do not use silicone sealant to secure the hood to the wall.•You must be able to isolate the extractor from the mains electrical supply after installation.•Steam cleaners must not be used when cleaning this appliance.•The performance of your extractor will vary depending on a number of factors. These include: type of extraction, length of ducting, room volume, ventilation available and cleanliness of the filters.Using your extractor
For best performance, you should switch on the extractor 15 minutes
before starting to cook and leave it to run for approximately 15
minutes after the end of cooking.
Control Panel
A - Light key
B - Decrease speed key
C - Display
D - Increase speed key
E - Timer key
To switch the extractor light on and o
•Touch key “A”.
Fig. 1
ABCDE
6
To switch on the extractor
• Touch either key “B” or “D”. The appliance will switch on at the first
speed.
• To increase the speed touch key “D”.
• To switch the extractor o, touch and hold key “B” for two seconds
when the extractor is working at higher speeds, or touch key “B” at
speed one.
The intensive function
• The extractor is equipped with an intensive function which runs for
ten minutes before returning to the previous selected speed. To
activate the intensive function, touch key “D” at speed three. The
display will blink whilst the intensive function is on.
The timer
• The extractor is equipped with a timer that allows the extractor to
run for 15 minutes before switching o automatically.
• To activate the timer, touch key “E”. The display will flash a decimal
point when the timer is on. Please note: The timer cannot be
activated when the intensive function is on.
The clean air function
• The extractor is equipped with a clean air function that switches on
the motor for ten minutes every hour at speed one.
• To activate the clean air function, touch key “E” for two seconds
when the appliance is o. To return to normal function, touch either
key “B” or “D”. To switch o the clean air function, touch key “E”.
The display “C” will light up in sections whilst the motor is running,
and will show the letter “C” during the fifty minutes when the motor
is not running.
7
Care and maintenance
IMPORTANT: DO NOT PERFORM
MAINTENANCE OR CLEANING OF
THE EXTRACTOR WITHOUT FIRST
SWITCHING OFF THE ELECTRICITY
SUPPLY.
Cleaning
You should use a nonabrasive cleaner.
Any abrasive cleaner (including Cif) will
scratch the surface and could erase the
control panel markings.
You can clean your extractor eectively
by simply using a dilute solution of
water and mild detergent and drying to
a shine with a clean cloth.
Cleaning the grease filter
The grease filters should be kept clean to minimise the risk of fire.
When the display flashes alternating the speed selected with the letter
“A”, or at least once a month, you should remove and clean the grease
filters with hot soapy water. You can also wash the grease filters in
a dishwasher, ensuring that you place them in an upright position to
prevent damage from other items in the dishwasher. After rinsing
and drying, replace the filters. After the grease filters have been
replaced, the electronic memory must be reset by touching key “A” for
approximately five seconds, until the letter “A” stops flashing.
Fig. 2
Fig. 3
8
To remove the grease filters
1. Pull open the handle on each grease filter as shown in fig. 2. It will
release at the handle side.
2. Lower the grease filter to remove it completely.
To replace the grease filters
Repeat the steps above in reverse order.
Please note: Cleaning the grease filters in a dishwasher may lead to
discolouration. This is normal and does not constitute a fault with the
appliance.
Changing the charcoal filter (re-circulating only)
When the display flashes alternating the speed selected with the letter
“F”, the charcoal filters must be replaced. After the charcoal filter has
been replaced, the electronic memory must be reset by touching key
“A” for approximately five seconds, until the letter “F” stops flashing.
To attach a new charcoal filter, first remove the grease filters as
described above. Then oer up the charcoal filter to the side of the
motor as shown in fig. 3 and turn it clockwise until it locks into place.
Repeat with the other charcoal filter on the other side of the motor.
Then replace the grease filters.
9
Changing the light
IMPORTANT: THE LIGHT BULBS SHOULD ONLY BE CHANGED BY
CDA AUTHORISED SERVICE AGENTS. IF ONE OR MORE OF YOUR
BULBS FAIL, CONTACT CDA CUSTOMER CARE TO ARRANGE A
SERVICE VISIT.
DO NOT TOUCH THE LIGHT BULBS IMMEDIATELY AFTER USE AS
THE BULB MAY BE WARM/HOT.
Do not touch bulbs or adjacent areas during or straight after pro-
longed use of the lights.
The light is designed for use during cooking and not for general room
illumination. Extended use of the light can reduce the life span of the
bulb.
10
DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
USE A 3 AMP FUSE
Mains electricity
connection
THIS APPLIANCE MUST BE
CONNECTED TO THE MAINS SUPPLY
BY A COMPETENT PERSON, USING
FIXED WIRING VIA A DOUBLE POLE
SWITCHED FUSED SPUR OUTLET
AND PROTECTED BY A 3A FUSE.
The appliance must be connected by a
qualified electrician, who is a member
of the N.I.C.E.I.C. and who will comply with the I.E.T.
and local regulations.
The wires in the mains lead of this appliance are coloured in
accordance with the following code:
BLUE = NEUTRAL, BROWN = LIVE.
As the colours of the wires in the mains lead for the appliance may
not correspond with the coloured markings identifying the terminals
connecting to the fused spur, proceed as follows:
•The wire which is coloured blue must be connected to the terminal
marked N (Neutral), or coloured black.
•The wire which is coloured brown must be connected to the
terminal marked L (Live), or coloured red.
NOTE: USE A 3A FUSE
