CEECO SSW-321-FP Bedienungsanleitung

SSW-321-FP-ISSUE4.0

MODEL SSW-321-FP

MINI WALL TELEPHONE

SERVICE MANUAL

Serving the Telephone Industry Since 1930

Communication Equipment 519 W South Park Street

& Engineering Company Okeechobee, FL 34972

Voice: 863-357-0798

Fax 863-357-0006

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

IMPORTANT INFORMATION

FOR

CUSTOMER

Please fill in before you continue.

The following information is necessary when calling CEECO for assistance.

MODEL NUMBER SSW-321-FP

SERIAL NUMBER

DATE MANUFACTURED

LOCATION INSTALLED

For us to better serve you, please have this information available when calling for

technical support.

CEECO

Communication Equipment and Engineering Company

519 W South Park Street

Okeechobee, FL 34972

863-357-0798- telephone

863-357-0006- facsimile

[email protected]

www.ceeco.net

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

TABLE OF CONTENTS

SECTION PAGE

1.0 INTRODUCTION................................................................................................... 4

2.0 GENERAL DESCRIPTION .................................................................................. 4

3.0 OPERATION .......................................................................................................... 4

4.0 RECOMMENDED TOOLS AND TEST EQUIPMENT .................................... 4

5.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS ..................... 5

6.0 TESTING................................................................................................................. 6

7.0 TROUBLESHOOTING GUIDE ........................................................................... 6

8.0 SPECIFICATIONS................................................................................................. 7

9.0 PARTS LIST ........................................................................................................... 8

10.0 FCC NOTICE.......................................................................................................... 9

11.0 REPAIR AND RETURN INFORMATION ....................................................... 10

12.0 WARRANTY POLICY ........................................................................................ 10

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

1.0 INTRODUCTION

The practices in this manual provide installation and maintenance information for

Model SSW 321-FP, which is a Stainless Steel Mini Wall Telephone designed for

Penal Institution applications.

The information in this manual is subject to change without notification.

For information not included in this manual, please call or write:

CEECO

Customer Service

519 W South Park Street

Okeechobee, FL 34972

863-357-0798- telephone

863-357-0006- facsimile

[email protected]

www.ceeco.net

2.0 GENERAL DESCRIPTION

The CEECO model SSW-321-FP is a Stainless Steel Wall Telephone equipped

with a metal button tone dial. The SSW-321-FP is designed for Penal Institution

applications. The armored-cord handset has an internal steel lanyard, which helps

guard against vandalism and helps to increase safety. The phone is not designed

for incoming calls and, therefore, does not have a ringer.

3.0 OPERATION

Lift the handset. After dial tone is heard dial your number using the keypad.

Normal phone operation follows.

4.0 RECOMMENDED TOOLS AND TEST EQUIPMENT

Volt/Ohm Meter

1/4" Nut Driver

Flat Blade Screw Driver

Security Tool CEECO Part Number 301-037

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

5.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS

5.1 Using a 301-037 security tool (sold separately), loosen and remove the

security screw.

5.2 The security tool is for a standard 5/32" button head screw generally used

on the framework of the phone booths.

5.3 Separate the cover assembly from the backplate assembly.

5.4 The backplate assembly may be installed on any standard backboard.

5.5 Run the inside station wire through the backplate assembly and terminate

on to the RJ11C terminal block on the backplate.

5.6 The use of a gas tube station protector is recommended. The station

ground should not exceed 50 ohms.

5.7 Plug the modular line cord from the cover assembly into the RJ11C

terminal block.

5.8 Dress the line cable away from the security screw and install the cover

assembly by inserting the tabs into the slots on top of the backplate.

5.9 Secure the cover assembly by tightening the security screw.

*****WARNING*****

A. Never install telephone wiring during a lightning storm.

B. Never install telephone jacks in wet locations unless the jack is

specifically designed for wet locations.

C. Never touch uninsulated telephone wires or terminals unless the

telephone line has been disconnected at the network interface.

D. Use caution when installing or modifying telephone lines.

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

6.0 TESTING

6.1 Connect the phone to a phone line or a DTMF phone test set.

6.2 Lift the handset, dial tone is heard.

6.3 Dial a number. (The transmitter is muted while the phone is dialing.)

DTMF tones should be heard and should register on the test set.

6.4 Normal phone conversation is allowed. Place the handset on hook.

The phone should hang up.

7.0 TROUBLESHOOTING GUIDE

Always visually check the phone for loose or shorted wires, damaged terminals or

damaged parts.

PROBLEM: NO DIAL TONE POSSIBLE CAUSE:

LINE CORD

RJ11C CONNECTOR

NETWORK

HANDSET

DIAL PC BOARD

PROBLEM: DIAL TONE IS DISTORTED POSSIBLE CAUSE:

NETWORK

HANDSET

DIAL PC BOARD

PROBLEM: TRANSMITTER DOES NOT POSSIBLE CAUSE:

TURN ON HANDSET

NETWORK

DIAL PC BOARD

PROBLEM: PHONE DOES NOT DIAL POSSIBLE CAUSE:

DIAL PC BOARD

KEYPAD

PROBLEM: RINGER DOES NOT OPERATE POSSIBLE CAUSE:

RINGER

NETWORK

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

8.0 SPECIFICATIONS

INPUT POWER: C.O. Line Powered

LOOP CURRENT: 23mA min to 80mA max

IMPEDANCE: 600 ohms

SIGNALING: DTMF, 70ms tone, 50ms spacing

HEARING AID

COMPATIBLE: Meets EIA standards

ENVIRONMENTAL: Temperature 0°C to 50°C

Humidity 20%-90% non-condensating

RINGER EQUIVALENCY: 0.4A

TYPE JACK: RJ11C

TELEPHONE COVER: Brushed 16 gauge Stainless Steel

DIMENSIONS: 5" Wide x 10 3/4" High x 5 1/2" deep

(Handset on hook)

MOUNTING: Vertical surface mount

WEIGHT: 6lbs.

FCC REGISTRATION: BW-88T7-13717-TE-T

UL LISTED NO.: 6OF5

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

9.0 PARTS LIST

QUANTITY PART NUMBER DESCRIPTION

1 321-020 Stainless Steel Mini Housing

1 735-100 Model 730 Metal Button Tone Dial

1 301-106-18 18" Handset with Armored Cord

with internal steel lanyard

1 301-009 Network

1 301-581 Tongue and Bracket Assembly

1 301-588 Hookswitch Cradle

2 301-570 Microswitch Assembly

1 301-018 Modular Cord

1 321-015 Stainless Steel Backplate

1 321-016 1/4" - 20 x 3/4" Security Screw

1 308-015 Swivel

1 301-052 Grommet

1 301-054 Modular Jack

ACCESSORIES:

1 301-037 Security Tool

OPTIONS:

1 301-106-29 or 29" Handset with Armored Cable

withInternalSteelLanyard

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

10.0 FCC NOTICE

10.1 FCC REGISTRATION AND REPAIR INFORMATION

Your new telephone has been registered with the Federal Communication

Commission (FCC) in accordance with Part 68. The FCC requires that

you be advised of certain requirements involving the use of this telephone.

10.2 CONNECTION WITH THE NATIONWIDE TELEPHONE NETWORK

The FCC requires that you connect this telephone to the Nationwide

Telephone Network through a registered jack provided by the Telephone

Company in your area. This jack is a modular outlet, which you can order

from your local telephone company.

10.3 NOTIFICATION TO THE TELEPHONE COMPANY

Before connecting this telephone, the FCC requires that you notify your

local telephone company business office. The number is in the front of

your phone book.

Tell them:

The "line" to which you will connect the telephone (that is, your phone

number) and the telephone's FCC registration number and ringer

equivalence number. These numbers are listed in section 8.00.

The FCC further requires that you notify your local telephone company,

when permanently disconnecting this telephone.

Issue 4.0

CEECO

Communication Equipment and Engineering Company

PROPRIETARY

11.0 REPAIR AND RETURN INFORMATION

11.1 WARRANTY REPAIR

Any device returned requiring warranty service, repair or credit must be

accompanied with a "Return Material Authorization" (RMA) Form. It

must include: RMA Number, return shipping instructions, original

purchase order number, serial number and special marking instructions. A

tag with the trouble observed must be attached to the defective unit. This

information must be inside the shipping container.

11.2 DIRECT ALL INQUIRES TO:

CEECO

Repair Department

863-357-0798- telephone

863-357-0006- facsimile

[email protected]

www.ceeco.net

11.3 NON-WARRANTY REPAIR

CEECO will repair equipment out of warranty for a set charge plus parts.

The customer must pay the shipping costs both directions.

11.4 RETURN FOR CREDIT

Material may be returned for credit only with prior approval. Material

authorized for return is subject to a 20% restocking charge based on the

manufacturer's list price. Return Material Authorization must be

requested no later than 30 days after original shipment. Items returned for

credit must be returned in their original shipping container.

12.0 WARRANTY POLICY
