Central Machinery 91815 Bedienungsanleitung

TABLE SAABLE SA

ABLE SAABLE SA

ABLE SAW - 10 INCHW - 10 INCH

W - 10 INCHW - 10 INCH

W - 10 INCH

DIRECT DRIVEDIRECT DRIVE

DIRECT DRIVE

ASSEMBLY AND OPERATING INSTRUCTIONS

3491 MISSION OAKS BLVD., CAMARILLO, CA 93011

VISIT OUR WEB SITE AT HTTP://WWW.HARBORFREIGHT.COM

this manual or any artwork contained herein may be reproduced in any shape

or form without the express written consent of Harbor Freight Tools.

For technical questions and replacement parts,please call 1-800-444-3353

91815

Page 2SKU 91815

SPECIFICATIONS

Item Description

Power Requirements 115 VAC, 15 amps, 60 Hz

Power Cord Length: 43 inches; 14 AWG x 3C, 3-prong plug

Switch Type Toggle with pull-out key safety lock

Motor Capacity 1.5 HP, 5000 RPM (maximum)

Drive Type Gear drive

Saw Blade 10 inch, 36 teeth (included)

Arbor Size 5/8 inch

Cutting Angles 90 to 30 degrees (left / right) angle

0 to 60 degree (left / right) miter

Cutting Capacity 3-1/8 inches at 90 degrees;

2-1/8 inches at 45 degrees (tilt)

Rip Fence 28-1/4 (L) x 1-3/4 (W) x 2-1/2 (H) inch

Scale: 0 to 27-1/4 inches (right)

Fence-to-blade: 25-1/2 inches (maximum)

Base Dimensions 20-1/8 (L) x 22-5/8 (W) x 21-5/8 (H) inches

Table Dimensions 38-1/2 (W) x 22-1/4 (L) x 1-3/8 (H) inches

Overall Dimensions 20-1/8 (L) x 51-1/8 (W) x 38 (H) inches

Weight 165 lbs.

SAVE THIS MANUAL

You will need the manual for the safety warnings and precautions, assembly instructions,

operating and maintenance procedures, parts list and diagram. Keep your invoice with this

manual. Write the invoice number on the inside of the front cover. Keep the manual and

invoice in a safe and dry place for future reference.

GENERAL SAFETY RULES

WARNING!

READANDUNDERSTANDALLINSTRUCTIONS.Failure tofollowall instructions

listed below may result in electric shock, fire, and/or serious injury.

SAVETHESE INSTRUCTIONS

Work Area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite

accidents.

2. Do not operate power tools in explosive atmospheres, such as in the presence

of flammable liquids, gases, or dust. Power tools create sparks which may ignite

the dust or fumes.

3. Keep bystanders, children, and visitors away while operating a power tool.

Distractions can cause you to lose control. Protect others in the work area from

debris such as chips and sparks. Provide barriers or shields as needed.

Page 3SKU 91815

Electrical Safety

4. Avoid body contact with grounded surfaces such as pipes, radiators, ranges,

and refrigerators. There is an increased risk of electric shock if your body is

grounded.

5. Do not expose power tools to rain or wet conditions. Water entering a power tool

will increase the risk of electric shock.

6. Grounded tools must be plugged into an outlet properly installed and grounded

in accordance with all codes and ordinances. Never remove the grounding

prong or modify the plug in any way. Do not use any adapter plugs. Check with

a qualified electrician if you are in doubt as to whether the outlet is properly

grounded. If the tools should electrically malfunction or break down, grounding

provides a low resistance path to carry electricity away from the user.

7. Double insulated tools are equipped with a polarized plug (one blade is wider

than the other). This plug will fit in a polarized outlet only one way. If the plug

does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a

qualified electrician to install a polarized outlet. Do not change the plug in any

way. Double insulation eliminates the need for the three wire grounded power

cord and grounded power supply system.

8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools or

pull the Plug from an outlet. Keep the Power Cord away from heat, oil, sharp

edges, or moving parts. Replace damaged Power Cords immediately. Damaged

Power Cords increase the risk of electric shock.

9. When operating a power tool outside, use an outdoor extension cord marked

“W-A” or “W”. These extension cords are rated for outdoor use, and reduce the risk

of electric shock.

Personal Safety

10. Stay alert. Watch what you are doing, and use common sense when operating a

power tool. Do not use a power tool while tired or under the influence of drugs,

alcohol, or medication. A moment of inattention while operating power tools may

result in serious personal injury.

11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep

your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or

long hair can be caught in moving parts.

12. Avoid accidental starting. Be sure the Power Switch is off before plugging in.

Carrying power tools with your finger on the Power Switch, or plugging in power tools

with the Power Switch on, invites accidents.

13. Remove adjusting keys or wrenches before turning the power tool on. A wrench

or a key that is left attached to a rotating part of the power tool may result in personal

injury.

Page 4SKU 91815

14. Do not overreach. Keep proper footing and balance at all times. Proper footing

and balance enables better control of the power tool in unexpected situations.

15. Use safety equipment. Always wear eye protection. Dust mask, nonskid safety

shoes, hard hat, or hearing protection must be used for appropriate conditions.

Tool Use and Care

16. Use clamps (not included) or other practical ways to secure and support the

workpiece to a stable platform. Holding the work by hand or against your body is

unstable and may lead to loss of control.

17. Do not force the tool. Use the correct tool for your application. The correct tool

will do the job better and safer at the rate for which it is designed.

18. Do not use the power tool if the Power Switch does not turn it on or off. Any tool

that cannot be controlled with the Power Switch is dangerous and must be replaced.

19. Disconnect the Power Cord Plug from the power source before making any

adjustments, changing accessories, or storing the tool. Such preventive safety

measures reduce the risk of starting the tool accidentally.

20. Store idle tools out of reach of children and other untrained persons. Tools are

dangerous in the hands of untrained users.

21. Maintain tools with care. Keep cutting tools sharp and clean. Properly

maintained tools with a sharp cutting edge are less likely to bind and are easier to

control. Do not use a damaged tool. Tag damaged tools “Do not use” until repaired.

22. Check for misalignment or binding of moving parts, breakage of parts, and any

other condition that may affect the tool’s operation. If damaged, have the tool

serviced before using. Many accidents are caused by poorly maintained tools.

23. Use only accessories that are recommended by the manufacturer for your

model. Accessories that may be suitable for one tool may become hazardous when

used on another tool.

Service

24. Tool service must be performed only by qualified repair personnel. Service or

maintenance performed by unqualified personnel could result in a risk of injury.

25. When servicing a tool, use only identical replacement parts. Follow

instructions in the

“Inspection, Maintenance, And Cleaning”

section of this

manual. Use of unauthorized parts or failure to follow maintenance instructions may

create a risk of electric shock or injury.

Page 5SKU 91815

SPECIFIC SAFETY RULES FOR THE TABLE SAW

1. Maintain labels and nameplates on the Table Saw.These carry important information.

If unreadable or missing, contact Harbor Freight Tools for a replacement.

2. Always wear ANSI approved safety impact eye goggles and heavy work gloves when

using the Table Saw. Using personal safety devices reduce the risk for injury.Safety

impact eye goggles and heavy work gloves are available from Harbor Freight Tools.

3. Maintain a safe working environment. Keep the work area well lit. Make sure there is

adequate surrounding workspace. Always keep the work area free of obstructions,

grease, oil, trash, and other debris. Do not use a power tool in areas near flammable

chemicals, dusts, and vapors. Do not use this product in a damp or wet location.

4. Avoid unintentional starting. Make sure you are prepared to begin work before turning

on the Table Saw.

5. Do not force the Table Saw.This tool will do the work better and safer at the speed

and capacity for which it was designed.

6. Always unplug the Table Saw from its electrical outlet before performing and

inspection, maintenance, or cleaning procedures.

7. After cutting, wait until the saw blade comes to a complete stop before removing stock

from the table, reaching around the saw blade, or leaving the area.

8. Never walk away and leave the saw running.

9. When making rip cuts, feed the stock into the blade against the direction of the blade

rotation.

10. Always use a push stick (not included) when ripping small or thin stock.

11. Keep saw blade sharp and free of all rust and pitch.

12. Always use the Anti-kickback Pawl (17) attachment when making rip cuts.

13. Always use the saw fence, blade guard, splitter, and anti-kickback fingers for

lengthwise sawing. Never push stock being cut by hand. Never disable the Blade

Guard (10).

14. Tighten and lock all adjusting (saw blade positioning) screws before operating.

15. Keeps hands out of the path of the saw blade during operation.

16. Only use ten (10) inch saw blades with 5/8 inch arbor on this machine.

17. Always secure the stock being cut with clamps whenever possible.

18. Make sure that the Switch is in the OFF position before plugging the line cord into the

electrical outlet.

19. Never cut more than one piece of stock at a time, for any type of cut.

20. Provide proper support for the stock based on its size and the type of operation to be

performed.

(1)

Page 6SKU 91815

21. Many saw accidents are caused by dull, badly set, and improperly filed cutting blades;

gum or resin adhering to the cutting blade; and by saw blade misalignment with the

fence. Such conditions can cause the stock to stick, jam, stall the saw blade, or kick

back at the operator. Never cut anything other than wood with the included Saw

Blade; cutting hard materials can cause the carbide blade to shatter and break apart.

WARNING: Never attempt to free a stalled saw blade without first turning OFF theTable

Saw and unplugging the Line Cord from the outlet.

22. Avoid awkward hand positions (i.e., crossing arms during operation) in which a

sudden slip could cause your hand to move into the moving saw blade.

23. Before making any adjustments to the Table Saw, the Switch should be in the OFF

position and the Switch locked OFF.

24. Never turn theTable Saw ON before clearing the table and work surface of all objects

(tools, scraps of wood, etc.), except the stock to be cut.

25. Avoid Kickback of stock:

- For rip cuts, the saw blade must be exactly parallel to the fence to prevent pinching

or heeling. Use the stock Separator (27) on the output side of the stock cut.

- Only feed the stock against the rotation of the saw blade.

- Keep the stock firmly on the table while cutting.

26. When making rip cuts:

- Push only on the main section of stock, between the saw blade and the fence.

- Always use a push stick, never your hands.

- Do not release the stock before the cut is complete, and push beyond the saw blade.

- Always push the stock through the saw blade, never pull it through from the opposite

direction.

- Always use the anti-kickback claws.

- Do not rip stock that is bowed, warped, or has nonparallel edges.

- Never reach over or behind the saw blade.

27. The use of abrasive, cut off, or wire wheels can be dangerous and must not be used.

28. Never perform any sawing operation freehand.

29. Before each use, check all nuts, bolts, and screws for tightness.Vibration during

cutting may cause these to loosen.

30. Keep extension cord off the ground and away from water.

Note: Performance of this tool may vary depending on variations in local line voltage. Exten-

sion cord usage may also affect tool performance.

Page 7SKU 91815

WARNING! Some dust created by power sanding, sawing, grinding, drilling, and

other construction activities, contain chemicals known (to the State of California) to

cause cancer,birth defects or other reproductive harm. Some examples of these chemi-

cals are:lead from lead-based paints,crystalline silica from bricks and cement or other

masonry products, arsenic and chromium from chemically treated lumber. Your risk

from these exposures varies, depending on how often you do this type of work. To

reduce your exposure to these chemicals:work in a well ventilated area, and work with

approved safety equipment, such as those dust masks that are specially designed to

filter out microscopic particles.

(California Health & Safety Code 25249.5, et seq.)

WARNING! People with pacemakers should consult their physician(s) before us-

ing this product. Electromagnetic fields in close proximity to a heart pacemaker could

cause interference to,or failure of the pacemaker. In addition,people with pacemakers

should adhere to the following:

•Avoid operating power tools alone.

•Don’t use a power tool with the power switch locked on.

•If powered via a power cord be certain that the tool is properly grounded. A ground

fault interrupt (GFCI) system is also a good precaution. This inexpensive device is

a good safety measure because it prevents a sustained electrical shock.

•Properly maintain and inspect all tools before use to avoid electrical shock.

GROUNDING

Note:This tool comes with a 3-prong grounded plug.

WARNING!

Improperlyconnecting thegroundingwire canresult inthe riskofelectricshock.

Check with a qualified electrician if you are in doubt as to whether the outlet is

properly grounded. Do not modify the power cord plug provided with the tool or

product.Never remove the grounding prong from the plug.Do not use the tool if

the power cord or plug is damaged. If damaged, have it repaired by a service

facility before use.If the plug will not fit the outlet,have a proper outlet installed

by a qualified electrician.

Grounded Tools: Tools withThree Prong Plugs

1. Tools marked with “Grounding Required” have a three wire cord and three prong

grounding plug. The plug must be connected to a properly grounded outlet.If the tool

should electrically malfunction or break down, grounding provides a low resistance

path to carry electricity away from the user, reducing the risk of electric shock. (See

Figure A.)

Page 8SKU 91815

2. The grounding prong in the plug is connected through the green wire inside the cord to

the grounding system in the tool.The green wire in the cord must be the only wire

connected to the tool’s grounding system and must never be attached to an electrically

“live” terminal. (See Figure A.)

3. Your tool must be plugged into an appropriate outlet, properly installed and grounded

in accordance with all codes and ordinances. The plug and outlet should look like

those in the following illustration. (See Figure A.)

Figure A.Three-prong Outlet Figure B.Two-prong Outlet

Double InsulatedTools:Tools withTwo Prong Plugs

4. Tools marked “Double Insulated” do not require grounding.They have a special double

insulation system which satisfies OSHA requirements and complies with the

applicable standards of Underwriters Laboratories, Inc., the Canadian Standard

Association, and the National Electrical Code. (See Figure B above.)

5. Double insulated tools may be used in either of the 120 volt outlets shown in the

following illustration. (See Figure B above.)

EXTENSION CORDS

Grounded

tools require a three wire extension cord.

Double Insulated

tools can use

either a two or three wire extension cord.

2. As the distance from the supply outlet increases, you must use a heavier gauge

extension cord. Using extension cords with inadequately sized wire causes a serious

drop in voltage, resulting in loss of power and possible tool damage. (See Table A.)

3. The smaller the gauge number of the wire, the greater the capacity of the cord. For

example, a 14 gauge cord can carry a higher current than a 16 gauge cord. (See

Table A.)

4. When using more than one extension cord to make up the total length, make sure

each cord contains at least the minimum wire size required. (See Table A.)

5. If you are using one extension cord for more than one tool, add the nameplate

amperes and use the sum to determine the required minimum cord size. (See Table

A.)

Page 9SKU 91815

6. If you are using an extension cord outdoors, make sure it is marked with the suffix“W-

A” (“W” in Canada) to indicate it is acceptable for outdoor use.

7. Make sure your extension cord is properly wired and in good electrical condition.

Always replace a damaged extension cord or have it repaired by a qualified electrician

before using it.

8. Protect your extension cords from sharp objects, excessive heat, and damp or wet

areas.

Table A

RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*

(120 VOLT)

NAMEPLATE

AMPERES

(At Full Load) EXTENSION CORD LENGTH

Feet 50

Feet 75

Feet 100

Feet 150

Feet

0 – 2.0 18 18 18 18 16

2.1 – 3.4 18 18 18 16 14

3.5 – 5.0 18 18 16 14 12

5.1 – 7.0 18 16 14 12 12

7.1 – 12.0 16 14 12 10 -

12.1 – 16.0 14 12 10 --

16.1 – 20.0 12 10 - - -

* Based on limiting the line voltage drop to five volts at 150% of the rated amperes.

SYMBOLOGY

Table B

(1)

Page 10SKU 91815

UNPACKING

When unpacking, check to make sure that all the parts are included.Refer to the Assembly

section, and the Assembly Drawing and Parts List at the end of this manual.

If any parts are missing or broken, please call Harbor Freight Tools at the number on the

cover of this manual as soon as possible.

ASSEMBLY INSTRUCTIONS

Stand Assembly

Note: Hand tighten the nuts and bolts during assembly.

1. Attach the Stand Legs (62) to the StandTop (60) front and rear pieces using sixteen 5/

16”x 5/8” Carriage Bolts (61), 5/16”FlatWashers (59), 5/16”LockWashers (39), and 5/

16” Hex Nuts (58).Refer to Figure C., below.

2. Attach the Cross Braces (63) to the left and right sides of the Stand Legs (62), and

Cross Braces (64) to the front and rear sides of the Stand Legs (62).Use eight 5/16” x

5/8” Carriage Bolts (61), 5/16” Flat Washers (59), 5/16” Lock Washers (39), and 5/16”

Hex Nuts (58).

The longer Cross Braces must be under the longer StandTop pieces as shown below.

Figure C.Stand Assembly

Inhaltsverzeichnis

Andere Central Machinery Gesehen Handbücher

Central Machinery

Central Machinery 94652 Bedienungsanleitung

Central Machinery

Central Machinery 97099 Installationshandbuch

Central Machinery

Central Machinery 93012 Bedienungsanleitung

Central Machinery

Central Machinery 03179 Bedienungsanleitung

Central Machinery

Central Machinery 41311 Bedienungsanleitung

Central Machinery

Central Machinery 93380 Bedienungsanleitung

Central Machinery

Central Machinery 66435 Installationshandbuch

Central Machinery

Central Machinery 93762 Bedienungsanleitung

Central Machinery

Central Machinery 93491 Bedienungsanleitung

Central Machinery

Central Machinery 32208 Installationshandbuch

Central Machinery

Central Machinery 99553 Installationshandbuch

Central Machinery

Central Machinery 93012 Montageanleitung

Central Machinery

Central Machinery 41889 Kurzanleitung

Central Machinery

Central Machinery 32206 Betriebsanleitung

Central Machinery

Central Machinery 93012 Bedienungsanleitung

Central Machinery

Central Machinery 67595 Installationshandbuch

Central Machinery

Central Machinery 93507 Bedienungsanleitung

Central Machinery

Central Machinery 93762 Montageanleitung

Central Machinery

Central Machinery 60500 Montageanleitung

Central Machinery

Central Machinery 45804 Bedienungsanleitung

Central Machinery

Central Machinery 92658 Bedienungsanleitung

Central Machinery

Central Machinery 90597 Bedienungsanleitung

Central Machinery

Central Machinery 04333 Bedienungsanleitung

Central Machinery

Central Machinery 62519 Montageanleitung

Beliebte Gesehen Handbücher anderer Marken

RIDGID

RIDGID BS1400 Bedienungsanleitung

ATIKA

ATIKA BWS 400-2 Bedienungsanleitung

RGC

RGC FS20 Bedienungsanleitung

Makita

Makita M2300 Bedienungsanleitung

IMET Spa

IMET Spa BASIC 300 PLUS SHI Bedienungsanleitung

IMET Spa

IMET Spa SIRIO 370 AF-E Bedienungsanleitung

Optimum

Optimum OPTisaw CS 275 Bedienungsanleitung

Makita

Makita BPB180 Bedienungsanleitung

Stihl

Stihl MS 462 C-M Bedienungsanleitung

AEG

AEG TS 250 K Bedienungsanleitung

Meec tools

Meec tools 004665 Bedienungsanleitung

Makita

Makita LS1018L Bedienungsanleitung

Ryobi

Ryobi RCS1400 Bedienungsanleitung

DeWalt

DeWalt DCS391 Bedienungsanleitung

Sealey

Sealey SA72 Bedienungsanleitung

skilsaw

skilsaw SPT88 Montageanleitung

Urrea

Urrea SI810 Abmessungen und Installationsanleitung

EINHELL

EINHELL BKG 210/1 Bedienungsanleitung
