Challenger X J750 Bedienungsanleitung
1
USER’S MANUAL
CHALLENGER X
RECREATIONAL ELECTRIC SCOOTER
MODEL: J750
Please read this manual completely before riding your scooter
www.challengermobility.com
2
3
TABLE OF CONTENTS
INTRODUCTION ………………………………………………………………………………4
SAFETY NOTICES ……………………………………………………………………….......5
SCOOTER COMPONENTS OVERVIEW ………………………………………………… 8
HANDLEBAR DISPLAY …………………………………………………………………….9
CHARGING THE BATTERIES …………………………………………………………..10
ASSEMBLY INSTRUCTIONS ……………………………………………………………11
RIDING INSTRUCTIONS ………………………………………………………………..15
CARE & MAINTENANCE …………………………………………………………………16
BASIC TROUBLESHOOTING …………………………………………………………..17
TECHNICAL SPECIFICATIONS ……………………………………………………….18
LIMITED WARRANTY …………………………………………………………………...19
PRODUCT REGISTRATION ……………………………………………………………..21
4
Introduction
Thank you for investing in a Challenger X recreational scooter. This scooter is the latest
innovation in electric mobility providing absolute safety; for both its rider and the
environment.
This scooter features a sleek design while maintaining safety standards that are required
of any mobility product. Its internal components have been designed to provide optimal
performance while maintaining high-efficiency. The Challenger X also includes multiple
features that increase overall functionality, yet simple to manage.
In order to get the most of your Challenger X, please read and follow all instructions,
warnings, and notes in this owner’s manual and all other accompanying literature before
using it for the first time. Improper use of the scooter could result in harm, or traffic
accidents.
The manufacturer disclaims all responsibilities for any personal injury or property damage
which may occur as a result of improper or unsafe use of this product.
This owner’s manual includes operation instructions for every aspect of the scooter
including assembly, safety instructions, as well as instructions for how to deal with possible
accidents.
If there is any information in this manual which you do not understand, or if you require
additional assistance for setup or operation, please contact your authorized dealer.
By accepting delivery of this product, you promise that you will not change, alter, or
modify this product or remove or render inoperable or unsafe any guards, shields, or other
safety features of this product; fail, refuse, or neglect to install any retrofit kits from time
to time provided by Challenger Mobility to enhance or preserve the safe use of this
product.
Please keep this owner’s manual in a proper place or on the scooter. If other people use
the scooter, please be sure to provide this copy.
NOTICE:
This owner’s manual is compiled from the latest specifications and product information
available at the time of publication. We reserve the right to make changes as they become
necessary. As designs change, some illustrations and pictures in the manual may not
correspond to the scooter that you purchased.
Any changes to our products may cause slight variations between the illustrations and
explanations in this manual and the product you have purchased. The latest/current
version of this manual is available on this website:
www.ChallengerMobility.com
5
Safety Notices
Read the Owner’s Manual
Do not operate your Challenger X Scooter for the first time without completely reading and
understanding this owner’s manual. The user should be familiar with the operation of this
scooter, and keep the safety notices in mind.
The same traffic rules for pedestrians apply to the use of this scooter.
This product does not conform to Federal Motor Vehicle Standards and is not intended for
operation on public streets, roads or highways.
For your safety, please follow the rules that apply to pedestrians.
1. Ride on sidewalks or pedestrian areas only.
2. At the end of a sidewalk, be aware of the cars on the road.
3. Be extremely cautious when driving your scooter around heavy traffic streets or
shopping malls.
4. Always obey pedestrian traffic signals.
Practice operating your scooter
Until you are familiar with the operation of your scooter, please practice in a wide and open
area, like a park. To prevent the possibility of falling off your scooter while driving, bear in
mind the scooters driving motion, such as whether it is accelerating, stopping, turning,
reversing, or going up or down inclines.
1. Please set the speed dial to the lowest speed initially.
2. Be sure someone is accompanying you and watches for traffic while you are driving on
the road for the first time.
3. Be sure you are able to control and operate your scooter safely and confidently before
changing to a higher speed.
Passenger Limitation
Do not carry any passengers on your scooter (including children). Do not use this scooter
to carry or transport goods. Stay within the specified weight capacity of your scooter.
Exceeding the weight capacity voids your warranty.
Pre-Ride Safety Check
Please carry out daily inspections. Refer to Section “Care & Maintenance” for inspection
procedures. Always make sure your scooter’s batteries are fully charged before operating.
Make sure the throttle lever is secure before turning on your scooter and check for proper
tire inflation.
Wear approved Gear
While wearing a helmet is not required, it is still advised for safety precaution. Always wear
shoes when riding your scooter.
6
Do not use a mobile phone or other wireless communication device while
driving.
Also, do not charge a mobile phone or other electrical devices from your scooter.
Do not stretch your body out on the scooter
Such action may cause you to lose your balance or be injured. Also, pay attention
to loose clothing that could get tangled in the wheels.
Do not use your scooter under any of these circumstances:
The road is muddy or has loose gravel
The road is bumpy, narrow, or snow covered
The road is beside a canal or waterway without fencing or hedges
Do not drive your scooter after consuming alcohol or when fatigued
Do not drive your scooter at night or in inclement weather
Additionally, avoid holes in the road where your wheels may get stuck.
Do not make sudden turns.
Do not ride on an escalator or in elevators.
Be careful driving on or near ramps and inclines
Be careful while driving up a steep incline.
When riding up or down an incline, please drive slowly.
Do not drive through any holes in the road.
Do not pass through water covering the road unless the water is less than
1 in. deep.
Please drive slowly on roads with drops or dips.
Do not make sudden turns while drive on gravel roads or ramps.
Maximum Weight Limitation
Refer to “Maximum Weight Capacity” in the “SPECIFICATIONS” section for details.
Overloading your scooter will lead to damage to, or malfunction of, your scooter.
This could cause the scooter to become a safety hazard. The warranty does not
cover damage from overloading.
7
WARNINGS:
Always keep your feet on the scooter platform when moving.
Never carry or wear anything which obstructs your vision, or would interfere
with the proper scooter operations.
Never ride your scooter while under the influence of alcohol or other drugs.
Persons without excellent vision, balance, coordination, reflex, muscle and
bone strength and good decision-making capabilities should not use this
product.
Avoid riding in bad weather, when visibility is obscured, at dusk or in the
dark, or when you are very tired. Each of these conditions increases the risk
of accident.
Always maintain a comfortable stopping distance from all other riders,
vehicles and objects.
Minors without adult supervision should not use this product.
Persons unwilling or unable to take responsibility for their own actions should
not use this product.
8
Scooter Components Overview
1.Hand Brakes
2.Front Basket
3.Front Motor-Wheel
4.LED Headlight
5.Standard Seat
6.Removable Floor Mat
7.Rear Wheel
8.Charging Port
9
Handlebar Display
1.Speed Limit Switch
2.Power Light
3.Headlight Indicator
4.Power gage
5.Forward/Reverse Button
6.Horn Switch
7.Key Switch/Light Switch
8.Throttle Knob
10
Charging the Batteries
Before you ride the mobility scooter for the first time you must charge the batteries
for 6—8 hours using the supplied charger.
To charge the batteries, plug the charger into the charger port of scooter at the lower
left, then plug the charger into a wall outlet.
When you plug the charger into the A/C outlet the red light on the charger will come
on, it will become green after a complete charge.
