Char-Griller 5650 Bedienungsanleitung

5650/5072_OM_A1

OWNER’S MANUAL

LP Gas & Charcoal Grill

Keep your receipt with this manual for Warranty.

CUSTOMER SERVICE

1-912-638-4724

Service@CharGriller.com

Models 5650 and 5072

Patented

Contents of this manual are Trademarked and Copyrighted by Char-Griller | A&J Manufacturing.

Using the information contained in this manual without consent of Char-Griller and/or A&J

Manufacturing is strictly prohibited.

5650/5072_OM_A1

WARNING

WARNING:

Improper installation, adjustment, alteration, service, or maintenance could cause injury or

property damage. Read the installation, operation, and maintenance instructions thoroughly before

assembling or servicing this equipment.

Failure to follow these instructions could result in re or explosion that could cause property

damage, personal injury, or death.

DANGER:

DO NOT use gas grill for indoor cooking or heating. TOXIC fumes can accumulate and cause

asphyxiation. Do not use in or on boats or recreational vehicles.

WARNING:

Accessible parts may be very hot. Keep young children away. Read the instruction literature before

using the appliance. The use of unauthorized parts can create unsafe conditions and environment.

A propane gas cylinder is required for operation. This gas grill is not intended for

commercial use.

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. IF YOU ARE

ASSEMBLING THIS UNIT FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM OR

HER TO SAVE FOR FUTURE REFERENCE. FOR CUSTOMER SERVICE, CALL 912-

638-4724.

For use outdoors and in well-ventilated areas.

PROP 65 WARNING:

WARNING: This product is equipped to operate on propane

gas which contains benzene, a chemical known to the

Stateof California to cause cancer, birth defects, or other

reproductive harm. This product and combustion by-

products produced when using this product contain

chemicals known to the State of California to cause cancer,

birth defects, or other reproductive harm.

LP Gas & Charcoal Grill

5650/5072_OM_A1

STOP! CALL FIRST!

DO NOT RETURN PRODUCT TO STORE.

CALL (912) 638-4724 or email us at: Service@Char-

Griller.com. This product has been built to the highest

quality standards.

If you have any questions not addressed in these in-

structions, have service or usage-related questions, or

want to order replacement parts, contact our Custom-

er Service Center.

Have your grill’s serial number ready (located on the

back of the grill body or on the leg) when calling.

NOTE: The use and installation of this product must conform to local codes or, in absence of local

codes, the National Fuel Gas Code, ANSI Z223.1/NFPA54.

IMPORTANT NOTICE: Read all instructions prior to assembly and use. Read and understand all

warnings and precautions prior to operating your grill.

5650/5072_OM_A1

IMPORTANT SAFETY WARNINGS

READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE

ASSEMBLING AND OPERATING YOUR GRILL

Read the following instructions carefully and be sure your barbecue is properly assembled,

installed and maintained. Failure to follow these instructions may result in serious bodily injury

and/or property damage. If you have any questions concerning assembly or operation, consult

your dealer or LP gas company.

When used, always place the appliance and gas bottle on at level ground. Grill can be used

with gas cylinders between 24lb to 33lb (11kg to 15kg). Grill will perform better if propane or LPG

mixtures are used. Butane can be used, but because of the rate of the appliance the cylinder will

tend to freeze and supply gas at reduced pressures, affecting grill performance.

DO NOT move the appliance during use.

DO NOT attempt to disconnect any gas ttings while barbecue is in use.

DO NOT use gas bottle if the bottle and/or valve are damaged, rusty, or dented as this may be

hazardous. Contact your supplier to have it checked.

DO NOT lean over an open grill and be mindful of hands/ngers near the edge of the cooking

area.

Should a re occur, turn off all gas burners, close the lid, and stand back from grill until re is out.

Should ames go out while in operation, turn off all gas valves and leave lid open.

Return to grill after ve minutes and try to relight the burners – following lighting instructions. Keep

children and pets away from grill when in use. Some parts of the grill will become very hot.

When cleaning the valves and burners, be careful not to stretch the valve orices or burner ports.

Move gas hoses as far away as possible from hot surfaces and dripping hot grease.

Gas may still be present in a cylinder that appears to be empty. Adhere to proper transportation/

storage of the cylinder at all times.

If gas is leaking from cylinder, move away from cylinder immediately and call your gas supplier or

re department. DO NOT try to address problem yourself.

DO NOT use a ame to check for gas leaks.

DO check for gas leaks and any obstructions to burners before use. This is especially important

after a period of storage or non-use.

The exible tube should be changed whenever it is damaged or cracked or by expiration date

printed on the tubing. Or, change tube every ve (5) years.

Always connect or replace cylinder in a well-ventilated area, and never in the presence of a ame,

LP Gas & Charcoal Grill

5650/5072_OM_A1

spark or heat source.

Grill must be kept away from ammable materials.

Turn off gas supply at gas container after use.

Do not alter this grill in any manner.

Do not touch metal parts of grill until it has completely cooled (about 45 minutes) to avoid burns,

unless you are wearing protective gear (BBQ mittens, pot holders, etc.).

Note that parts sealed by manufacturer or its agent must not be altered.

When assembling the grill, position the connection exible tube so that it is protected against

twisting.

Grill must be kept away from ammable materials.

Stay away from any source of ignition when changing gas container.

When assembling the grill, do not obstruct ventilation openings of grill’s container compartment.

We reserve the right to make minor technical adjustments to the device.

When cooking with oil/grease, do not allow the oil/grease to exceed 350°F (177°C). Do not store

or use extra cooking oil in the vicinity of this or any other appliance.

Never ll the cylinder beyond 80% full. Not following the above information exactly may result in a

re causing death or serious injury.

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open ame.

3. Open Lid.

4. If odor continues, keep away from the appliance and immediately call your gas

supplier or your re department.

Do not store or use gasoline or other ammable liquids or vapors within 25 feet

(9m) of this or any other appliance. An LP cylinder not connected should be stored a

minimum of 10 feet (3m) away from the appliance.

5650/5072_OM_A1

CAUTION

This grill is for use with propane gas only (propane gas cylinder not included).

Never attempt to attach this grill to the self-contained propane system of a camper trailer, motor

home or house.

Never use charcoal or lighter uid with gas grill.

Do not use gasoline, kerosene or alcohol for lighting. The LP gas supply cylinder must be

constructed and marked in accordance with the specications for propane gas cylinders of the

U.S. Department of Transportation (DOT) CFR 49.

This grill is not intended for use on recreation vehicles and/or boats.

Do not use grill unless it is completely assembled and all parts are securely fastened and

tightened.

Keep all combustible items and surfaces at least 36 inches (91.4cm) away from grill at all times.

DO NOT use this grill or any gas product near unprotected combustible constructions.

Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials,

gasoline and other ammable vapors and liquids.

Never keep a lled container in a hot car or car trunk. Heat will cause gas pressure to increase,

which may open relief valve and allow gas to escape.

Keep grill’s valve compartment, burners and circulating air passages clean. Inspect grill before

each use.

WARNING

This grill is for outside use only, and should not be used in a building, garage, or any other

enclosed area.

The use of alcohol, prescription or non-prescription drugs may impair the operator’s ability to

properly assemble or safely operate the grill.

Always open grill lid slowly and carefully as heat and steam trapped within the grill can burn you

severely.

Always place grill on a hard, level surface far away from combustibles. An asphalt or blacktop

surface may not be acceptable for this purpose.

Do not leave a lit grill unattended. Keep children and pets away from grill at all times.

Do not place grill on any type of tabletop surface.

Do not use grill in high winds.

LP Gas & Charcoal Grill

5650/5072_OM_A1

Disconnect the propane tank (LP tank) by rst turning off valve on top of propane tank, turn off

burner valves, then disconnect regulator from valve on propane tank by turning plastic connector

counter clockwise. Unscrew wing-bolt in bottom shelf to release the tank for removal.

DANGER

Liquid propane (LP) gas is ammable and hazardous if handled improperly. Know its

characteristics before using any propane product.

Propane Characteristics: ammable, explosive under pressure, heavier than air and settles in

pools and low areas.

In its natural state, propane has no odor. For your safety, an odorant has been added.

Contact with propane can cause freeze burns to skin.

This grill is shipped from the factory for propane gas use only.

Never use a propane cylinder with a damaged body, valve, collar or footing.

Dented or rusted propane cylinders may be hazardous and should be checked by your propane

gas supplier.

5650/5072_OM_A1

CUATION: Handles are Hot

CAUTION: Handles are Hot

LP Gas & Charcoal Grill

5650/5072_OM_A1

WARRANTY INFORMATION

Char-Griller® Gas Grill

Char-Griller® will repair or replace any defective part of its Grills for a period of up to one (1)

year from the date of purchase.

Char-Griller® will also repair or replace the charcoal grill body (lid and bottom half) and gas grill

lid of its grillers/smokers if the metal is rusted through or burned through for a period up to ve

(5) years from date of purchase.

Char-Griller® will repair or replace the gas grill body if the metal is rusted through or burned

through for a period up to one (1) year from date of purchase.

Char-Griller® gas grill burners have a ve (5) year warranty from the date of purchase.

Proof of purchase, proof of purchase date and prepaid return of the item in question may be

required. Misuse, abuse, or commercial use nullies all warranties. Paint/nish is not warranted.

Products are not warranted against rust.

The warranty is for replacement of defective parts only. Manufacture will not be responsible

for damage resulting from accident, alteration, misuse, abuse, hostile environments, improper

installation, installation not in accordance with local codes of service of unit.

This limited warranty does not cover any scratches, dents , corrosion or discoloring by heat,

abrasive and chemical cleaners nor any components used in the installation of the appliance.

Save your receipt for all warranty claims.

5650/5072_OM_A1

PARTS LIST

Model 5650
