Cherry G84-4700 Gebrauchsanweisung

Main Applications

Desktop

-Numerical input

-Control systems

-Frequent entry of numbers

-Extension for notebook computer

Key Features

•Programmable 21-key numeric layout

•Equally suitable for left- and

righthanded users

•Low space requirements

•All keys can be user-defined with

up to 24 characters per key

•4 additional user-programmable function

keys, can be labeled individually

•Digits can be entered independently

of the status of the Num Lock in the

system (operation on notebook PC)

•Variable decimal separator [.], [,], [00],

or [000]

•External standard keyboard

can be connected

•Matches design of Cherry keyboards

G84-4100

•Uses mechanical keys from our ML

series with high-precision key action;

small physical dimensions:

•Reliability: MTBF: 550,000 hours

Main Part Numbers

G84-4700LPBUS-0

Light grey, PS/2 interface,

21 programmable keys, 4 relegendable,

ML keyswitches, second PS/2 port

for keyboard

G84-4700LPBUS-2

Black, PS/2 interface,

21 programmable keys, 4 relegendable,

ML keyswitches, second PS/2 port

for keyboard

G84-4700 LUCUS-0

Light grey, USB interface,

21 programmable keys, 4 relegendable,

ML keyswitches

G84-4700 LUCUS-2

Black, USB interface,

21 programmable keys 4 relegendable,

ML keyswitches

(1) International Layouts

US Belgian/Swiss

English (US)/English (UK)

DE Germany

DK Danish/Norwegian

ES Spain

FR France

IT Italy

SF Sweden/Finland

Other versions available on request.

Desktop Products

G84-4700 Compact

Programmable Keypad

Compact Keypad Featuring MX Technology

with Gold Crosspoint Contacts

Technical Data

Power Supply

3.3-5.0 VDC ± 10% SELV

Current Input

typ. 50 mA

Connecting Cable

approx. 1.75 m long

Weight

approx. 260 g

Storage Temperature

-20°C to 60°C

Connection Diagram

Operating Temperature

0°C to 50°C

Dimensions of Housing

90 x 132 x 36 mm

Cherry MX Switches with Gold

Crosspoint Contacts

Actuation Characteristics

Soft contact

For information on repairs or

warranty status contact:

Cherry Technical Support

Phone: 800.510.1689

E-Mail: [email protected]

G84-4700 PRB (1)

Desktop Products

G84-4700 Compact

Programmable Keypad

Contact

Call, fax or visit our

website for more information.

Last Update: 10/28/08

Cherry Electrical Products

11200 88th Avenue

Pleasant Prairie, WI 53158

Phone: 262.942.6500

Web: www.cherrycorp.com

E-Mail: [email protected]

Fax: 262.942.6566

The manufacturer accepts no

liability for errors or non-availability,

and reserves the right to change

specifications without prior notice.

Technical data relates to product

specifications only. Features may

differ from those described.

Only drawings combined with

product specifications shall be

deemed binding.
