CSG2 DEAD MAN
COMMAND
Cod.
220523
CHIAROSCURO SASdi Girelli Marco & C.
C.So General A. Cantore 23 - 38061 Ala (TN) Italy
Pag.
5 of 20
2IDENTIFICATION OF THE MANUFACTURER
The plate fixed on the side of the actuator contains all the identification data of the ST40 actuator. Fig.3.1
Example of label (the data shown are purely indicative, the real values are shown in the label of the
equipment placed on the automation itself).
3INFORMATION ON TECHNICAL ASSISTANCE AND MAINTENANCE
To report faults, contact the Assistance Center:
CHIAROSCURO SAS di Girelli Marco & C.
C.so General A.Cantore 23 - 38068 Ala (TN) Italia
Tel: +39 0464 424715 fax: +39 0464 712027
email : info@chiaroscuro.eu sito: www.chiaroscuro.eu
For communications or requests for information or spare parts, send the form "ORDER OF SPARE PARTS,
TROUBLESHOOTING, INFORMATION" to the service center
3.1 RACCOMANDATIONS
3.2 EXTRAORDINARY MAINTENANCE
On the label, applied to all the motors, there are indications
concerning the model of motor used, the operating voltages,
the absorption, the speed of movement, the degree of
electrical protection, the operating temperatures, the lot
number and the year of production of the engine and the
European brand certification
To maintain the duration of the guarantee, the customer must scrupulously follow the
instructions indicated in this manual. Otherwise, we will not be held responsible for any
problems or malfunctions of the appliance (in this regard, carefully read the guarantee
The manufacturer, in order to adapt the equipment to technological progress and
specific production needs, may decide, without prior notice, to make changes to it
without this entailing the obligation to update the production and previous manuals.
Furthermore, if the illustrations in this manual differ slightly from the equipment in your
possession, the safety and operating indications of the same are always guaranteed.
In the event of an error, contact the service center indicating the model, code and serial
number of the equipment.
In the event that defects / malfunctions are found, do not try to repair the equipment but
contact the service center indicating the model, code and serial number of the
User: Contact the electromechanical operator in case of breakages or malfunctions .
Electromechanical operator: Identify malfunctions and if necessary contact the service
center indicating the model, code and serial number of the equipment. Use the service
request form - spare parts.
