10.8 VOLT CORDLESS DRILL/DRIVER

Model

96299

OPERATING INSTRUCTIONS

Diagrams within this manual may not be drawn proportionally.

Due to continuing improvements, actual product may differ slightly from the product described herein.

Distributed exclusively by Harbor Freight Tools®.

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

manual or any artwork contained herein may be reproduced in any shape or form

without the express written consent of Harbor Freight Tools.

For technical questions or replacement parts, please call 1-800-444-3353.

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 2

PRODUCT SPECIFICATIONS

Power Source 1.3Ah Battery

Charge Time 5-7 Hours, after initial charge

Charger Input 120V ~60Hz

Chuck Type 3/8” Jacobs®Keyless Chuck

Torque Settings 23 clutch settings/1 drill setting

Variable Speed 0-500 RPM

Maximum Torque 80 in./lb.

Reversible Yes

Trigger Lock Yes

Weight 2.2 Pounds

Includes

1 Hex shank adapter

6 Phillips head bits

3 ﬂat head bits

Save This Manual

You will need this manual for the safety warnings and precautions, assembly, oper-

ating, inspection, maintenance and cleaning procedures, parts list and assembly diagram.

Keep your invoice with this manual. Write the invoice number on the inside of the front

cover. Keep this manual and invoice in a safe and dry place for future reference.

GENERAL SAFETY RULES

WARNING!

READ AND UNDERSTAND ALL INSTRUCTIONS

Failure to follow all instructions listed below may result

in electric shock, ﬁre, and/or serious injury.

SAVE THESE INSTRUCTIONS

Work Area

Keep your work area clean and well lit.1. Cluttered benches and dark areas

invite accidents.

Do not operate power tools in explosive atmospheres, such as in the pres-2.

ence of ﬂammable liquids, gases, or dust. Power tools create sparks which may

ignite the dust or fumes.

Keep bystanders and children away while operating a power tool.3. Distractions

can cause you to lose control. Protect others in the work area from debris such as

chips and sparks. Provide barriers or shields as needed.

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 3

Electrical Safety

Avoid body contact with grounded surfaces such as pipes, radiators, ranges,1.

and refrigerators. There is an increased risk of electric shock if your body is

grounded.

Do not expose power tools to rain or wet conditions.2. Water entering a power

tool will increase the risk of electric shock.

Do not abuse the Charger’s power cord. Never use the Power Cord to carry3.

the Charger or pull the Plug from an outlet. Keep the Power Cord away from

heat, oil, sharp edges, or moving parts. Replace damaged Power Cords im-

mediately. Damaged Power Cords increase the risk of electric shock.

Personal Safety

Stay alert. Watch what you are doing, and use common sense when operat-1.

ing a power tool. Do not use a power tool while tired or under the inﬂuence

of drugs, alcohol, or medication. A moment of inattention while operating power

tools may result in serious personal injury.

Dress properly. Do not wear loose clothing or jewelry. Contain long hair.2.

Keep your hair, clothing, and gloves away from moving parts. Loose clothes,

jewelry, or long hair can be caught in moving parts.

Avoid accidental starting. Be sure the Rotation Button (6) is in the locked3.

position before inserting the Battery. Carrying power tools with your ﬁnger on

the trigger, or inserting the Battery with the trigger depressed, invites accidents.

Do not overreach. Keep proper footing and balance at all times.4. Proper footing

and balance enables better control of the power tool in unexpected situations.

Use safety equipment. Always wear eye protection.5. Dust mask, nonskid safety

shoes, hard hat, or hearing protection must be used for appropriate conditions.

Always wear ANSI-approved safety goggles when working with this tool.

Tool Use and Care

Use clamps (not included) or other practical ways to secure and support the1.

workpiece to a stable platform. Holding the work by hand or against your body

is unstable and may lead to loss of control.

Do not force the tool. Use the correct tool for your application.2. The correct

tool will do the job better and safer at the rate for which it is designed.

Do not use the power tool if the trigger does not operate it.3. Any tool that cannot

be controlled with the trigger is dangerous and must be replaced.

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 4

Remove the battery from the tool and set the Rotation Button (6) to the cen-4.

ter, locked position, before making any adjustments, changing accessories,

or storing the tool. These preventive safety measures reduce the risk of starting

the tool accidentally.

Store idle tools out of reach of children and other untrained persons.5. Tools

are dangerous in the hands of untrained users.

Maintain the Cordless Drill/Driver with care. Keep drill bits sharp and clean.6.

Properly maintained accessories with a sharp cutting edge are less likely to bind

and are easier to control. Do not use a damaged tool or accessory. Tag damaged

tools “Do not use” until repaired.

Check for misalignment or binding of moving parts, breakage of parts, and any7.

other condition that may affect the tool’s operation. If damaged, have the tool

serviced before using. Many accidents are caused by poorly maintained tools.

Use only accessories that are recommended by the manufacturer for your8.

model. Accessories that may be suitable for one tool may become hazardous

when used on another tool.

Service

Tool service must be performed only by qualiﬁed repair personnel.1. Service

or maintenance performed by unqualiﬁed personnel could result in a risk of injury

and will void applicable warranties.

When servicing a tool, use only identical replacement parts. Follow instruc-2.

tions in this manual. Use of unauthorized parts or failure to follow maintenance

instructions may create a risk of electric shock or injury.

Note: Use of unauthorized parts and any service performed by unauthorized3.

personnel will void all applicable warranties.

SPECIFIC SAFETY RULES

Maintain a safe working environment.1. Keep the work area well lit. Make sure

there is adequate surrounding workspace. Always keep the work area free of ob-

structions, grease, oil, trash, and other debris. Do not use the Cordless Drill/Driver

in areas near ﬂammable chemicals, dusts, and vapors. Do not use this product in

a damp or wet location.

Maintain labels and nameplates on the Cordless Drill/Driver.2. These carry

important information. If unreadable or missing, contact Harbor Freight Tools for a

replacement.

When using the Cordless Drill/Driver, always maintain a ﬁrm grip on the tool3.

with both hands.

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 5

Hold the tool by its insulated gripping surfaces when performing an opera-4.

tion where the Cordless Drill/Driver may contact hidden wiring. Contact with

a “live” wire will make exposed metal parts of the Cordless Drill/Driver “live” and

shock the operator.

Do not use the Cordless Drill/Driver or Charger if it has been dropped, dam-5.

aged, left outdoors, or immersed in liquid.

To avoid electric shock, do not pull or carry the Charger by its Power Cord or6.

pull the Power Cord around sharp corners or edges. Do not unplug the Charger

by pulling on the Power Cord. Keep the Power Cord away from heated surfaces.

To avoid electrical shock, do not handle the Charger, the Adapter, or the Cord-7.

less Drill/Driver with wet hands.

Keep the Handles of the Cordless Drill/Driver dry, clean, and free from oil or8.

grease.

Avoid unintentional starting.9. Make sure you are prepared to begin work before

turning on the Cordless Drill/Driver.

Never leave the Charger unattended when it is plugged into an electrical outlet.10.

Unplug the Charger from its electrical outlet before leaving. Place the Charger on

a solid surface such as a garage ﬂoor; never place on anything ﬂammable.

PROPER BATTERY PACK CARE: Battery Pack (19) leakage may occur under11.

extreme usage or temperature conditions. If Battery Pack ﬂuid comes in contact

with skin, rinse with lemon juice and vinegar then wash with soap and water. If

the ﬂuid comes into contact with the eyes, ﬂush with water for several minutes and

contact a doctor immediately. Never burn the Battery Pack, as it can explode in a

ﬁre. Do not charge the Cordless Drill/Driver with a leaking Battery Pack. Contact

local solid waste authorities for instructions on correct disposal or recycling of the

Battery Pack.

12. WARNING! Some dust created by power sanding, sawing, grinding, drilling, and

other construction activities, contain chemicals known (to the State of California) to

cause cancer, birth defects or other reproductive harm. Some examples of these

chemicals are: lead from lead-based paints, crystalline silica from bricks and cement

or other masonry products, arsenic and chromium from chemically treated lumber.

Your risk from these exposures varies, depending on how often you do this type of

work. To reduce your exposure to these chemicals: work in a well ventilated area,

and work with approved safety equipment, such as dust masks that are specially

designed to ﬁlter out microscopic particles. (California Health & Safety Code §

25249.5, et seq.)

13. WARNING! People with pacemakers should consult their physician(s) before

using this product. Operation of electrical equipment in close proximity to a heart

pacemaker could cause interference or failure of the pacemaker.

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 6

GROUNDING

WARNING!

Improperly connecting the grounding wire can result in the risk of electric shock.

Check with a qualiﬁed electrician if you are in doubt as to whether the outlet is

properly grounded. Do not modify the power cord plug provided with the tool.

Never remove the grounding prong from the plug. Do not use the tool if the

power cord or plug is damaged. If damaged, have it repaired by a service facil-

ity before use. If the plug will not ﬁt the outlet, have a proper outlet installed by

a qualiﬁed electrician.

GROUNDED TOOLS: TOOLS WITH THREE PRONG PLUGS

Tools marked with “Grounding Required” have a three wire cord and three prong1.

grounding plug. The plug must be connected to a properly grounded outlet. If

the tool should electrically malfunction or break down, grounding provides a low

resistance path to carry electricity away from the user, reducing the risk of electric

shock. (See Figure A.)

The grounding prong in the plug is connected through the green wire inside the2.

cord to the grounding system in the tool. The green wire in the cord must be the

only wire connected to the tool’s grounding system and must never be attached to

an electrically “live” terminal. (See Figure A.)

Your tool must be plugged into an appropriate outlet, properly installed and grounded3.

in accordance with all codes and ordinances. The plug and outlet should look like

those in the following illustration. (Se Figure A.)

FIGURE A FIGURE B.

DOUBLE INSULATED TOOLS: WITH TWO PRONG PLUGS

Tools marked “Double Insulated” do not require grounding. They have a special1.

double insulation system which satisﬁes OSHA requirements and complies with

the applicable standards of Underwriters Laboratories, Inc., the Canadian Standard

Association, and the National Electrical Code. (See Figure B.)

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 7

Double insulated tools may be used in either of the 120 volt outlets shown in the2.

preceding illustration. (See Figure B.)

EXTENSION CORDS

Grounded1. tools require a three wire extension cord. Double Insulated tools can

use either a two or three wire extension cord.

As the distance from the supply outlet increases, you must use a heavier gauge2.

extension cord. Using extension cords with inadequately sized wire causes a seri-

ous drop in voltage, resulting in loss of power and possible tool damage.

(See Chart A, next page.)

The smaller the gauge number of the wire, the greater the capacity of the cord. For3.

example, a 14 gauge cord can carry a higher current than a 16 gauge cord.

(See Chart A.)

When using more than one extension cord to make up the total length, make sure4.

each cord contains at least the minimum wire size required. (See Chart A.)

If you are using one extension cord for more than one tool, add the nameplate5. am-

peres and use the sum to determine the required minimum cord size.

(See Chart A.)

If you are using an extension cord outdoors, make sure it is marked with the sufﬁx6.

“W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.

Make sure your extension cord is properly wired and in good electrical condition.7.

Always replace a damaged extension cord or have it repaired by a qualiﬁed electri-

cian before using it.

Protect your extension cords from sharp objects, excessive heat, and damp or wet8.

areas.

RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*

(120 OR 240 VOLT)

NAMEPLATE

AMPERES

(at full load)

EXTENSION CORD LENGTH

25 Feet 50 Feet 75 Feet 100 Feet 150 Feet

0 – 2.0 18 18 18 18 16

2.1 – 3.4 18 18 18 16 14

3.5 – 5.0 18 18 16 14 12

5.1 – 7.0 18 16 14 12 12

7.1 – 12.0 18 14 12 10 -

12.1 – 16.0 14 12 10 - -

16.1 – 20.0 12 10 - - -

Chart A * Based on limiting the line voltage drop to ﬁve volts at 150% of the rated amperes.

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 8

Lithium Battery Charging Safety

Do not leave unattended while charging.1.

Battery charging should be done by adults only.2.

Charge on non-ﬂammable surface and keep away from ﬂammable items.3.

Turn charger off when battery is charged, and unplug charger from battery-powered4.

device.

Disconnect AC wall chargers from outlets while not in use.5.

If battery-powered device has been damaged, immediately stop use, unplug, and6.

safely move away from ﬂammable materials.

Follow instructions for charging battery. Do NOT charge longer than7.

recommended.

SYMBOLOGY

Double Insulated

Canadian Standards Association

Underwriters Laboratories, Inc.

V~ Volts Alternating Current

AAmperes

n0xxxx/min. No Load Revolutions per Minute (RPM)

UNPACKING

When unpacking, check to make sure that the product is complete and undamaged.

If any parts are missing or broken, please call Harbor Freight Tools at the number shown

on the cover of this manual as soon as possible.

REV 08c

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 9

CHARGING

The Battery Pack (19) requires charging before the initial use. The recommended1.

initial charge time is twelve hours, prior to initial use of the Cordless Drill/Driver.

Place the Charger on a solid surface such as a garage ﬂoor; never on anything

ﬂammable.

Note: Always switch to a fresh battery when tool performance begins to diminish. Severe

heat is destructive to batteries; the more heat generated, the faster the battery will

lose power. A battery that gets too hot can be permanently damaged. Never over-

discharge a battery by using the tool after performance decreases. Never attempt to

discharge a battery by continuing to pull the trigger. When tool performance begins

to diminish, stop the tool, recharge the battery, and use a fully charged battery for

optimal performance.

When the Battery Pack-after initial charge-requires recharging, it must charge for2.

ﬁve to seven hours in order to operate at full power.

Charging room temperature: 50° F. – 104° F.3.

Depress both buttons at the rear of the Battery Pack and slide the unit down to4.

detach from the Drill/Driver.

5. The Battery Pack can only ﬁt into the Charger (20) in one position, insert into Char-

ger, plug Charger into Adapter (21), and plug

Adapter into any standard electrical outlet.

While charging, the Battery Pack, Charger,6.

and Adapter may become warm to the touch.

This is normal, and does not indicate a prob-

lem.

When the Battery Pack is in the Charger,7.

both the red and green lights on the Charger

will be illuminated while charging, when the

Battery Pack is fully charged the red light

will turn off, indicating that the Battery Pack

is ready for use. Once the Battery Pack is

fully charged, unplug the Charger from the

electrical outlet and remove the Battery Pack

from the Adapter.

Battery

Pack (19)

Adapter

(21)

Charger

(20)

SKU 96299 For technical questions, please call 1-800-444-3353. PAGE 10

OPERATING INSTRUCTIONS

NOTE: For additional information regarding the parts listed in the following pages, refer to

the Parts List & Assembly Diagram.

WARNING! Remove the Battery Pack (19) from the tool and set the Rotation

Button (6) to its center, locked, position before making any adjustments, changing acces-

sories, or storing the tool.

Battery Pack

(19)

Trigger (12)

Gear Box with

Torque Ring (2)

Rotation Button (6)

Chuck (1)

In order to use the included screwdriver bits, you must ﬁrst attach the Bit Adapter1.

(22) into the Chuck (1). With the Chuck (1) pointing away from you, turn the Chuck

(1) counterclockwise. Insert the shank of the Bit Adapter (22) all the way into the

Chuck (1). Turn the Chuck (1) clockwise to lock the Bit Adapter (22) in place.

The Chuck accepts up to 3/8” diameter bits. Insert the appropriate bit for your2.

application and tighten the Chuck ﬁrmly. Follow the same procedure as use for at-

taching the Bit Adapter (22). Never insert one of the included Bits (23) directly

into the Chuck. A smaller gauge than 3/8” will not be ﬁrmly secured and may

result in injury or property damage.

Secure the workpiece in place, using a vise or clamps (not included).3.

Warning! Never change Torque Setting while drill is still rotating, as this can damage the

Cordless Drill/Driver.

Decide on which setting to choose for application:4.

Inhaltsverzeichnis

Andere Chicago Electric Bohren Handbücher

Chicago Electric

Chicago Electric 68126 Installationshandbuch

Chicago Electric

Chicago Electric 3670 Bedienungsanleitung

Chicago Electric

Chicago Electric 60495 Montageanleitung

Chicago Electric

Chicago Electric 68169 Installationshandbuch

Chicago Electric

Chicago Electric 93632 Installationshandbuch

Chicago Electric

Chicago Electric 45338 Bedienungsanleitung

Chicago Electric

Chicago Electric VARIABLE SPEED 18 VOLT CORD- LESS DRILL/HAMMER DRILL... Bedienungsanleitung

Chicago Electric

Chicago Electric 68851 Montageanleitung

Chicago Electric

Chicago Electric 66006 Installationshandbuch

Chicago Electric

Chicago Electric 98179 Montageanleitung

Chicago Electric

Chicago Electric ITEM 62427 Bedienungsanleitung

Chicago Electric

Chicago Electric 46804 Bedienungsanleitung

Chicago Electric

Chicago Electric 1/2" variable Speed Reversible HEAVY DUTY DRILL... Montageanleitung

Chicago Electric

Chicago Electric 47991 Installationshandbuch

Chicago Electric

Chicago Electric 69360 Installationshandbuch

Chicago Electric

Chicago Electric 97907 Installationshandbuch

Chicago Electric

Chicago Electric 93632 Bedienungsanleitung

Chicago Electric

Chicago Electric 45338 Installationshandbuch

Chicago Electric

Chicago Electric 93142 Bedienungsanleitung

Chicago Electric

Chicago Electric 1/2" variable Speed Reversible HEAVY DUTY DRILL... Montageanleitung

Chicago Electric

Chicago Electric 94434 Bedienungsanleitung

Chicago Electric

Chicago Electric 42564 Bedienungsanleitung

Chicago Electric

Chicago Electric 95877 Montageanleitung

Chicago Electric

Chicago Electric 93449 Bedienungsanleitung

Beliebte Bohren Handbücher anderer Marken

Makita

Makita BDF456 Bedienungsanleitung

Black & Decker

Black & Decker LDX220 Bedienungsanleitung

Hitachi

Hitachi DH 40MA Bedienungsanleitung

Challenge

Challenge JO Technisches Referenzhandbuch

Makita

Makita LXFD01 Bedienungsanleitung

Festool

Festool T18+3 Bedienungsanleitung

Milwaukee

Milwaukee M12 FPDX-202X Bedienungsanleitung

EINHELL

EINHELL TE-RH 32 E Bedienungsanleitung

Makita

Makita DHP484 Bedienungsanleitung

Makita

Makita FD05 Bedienungsanleitung

Bosch

Bosch PSB 530 RA Bedienungsanleitung

Maximum

Maximum 054-1359-4 Bedienungsanleitung

Makita

Makita HP332D Bedienungsanleitung

Raider

Raider RDP-HD31H Bedienungsanleitung

Bort

Bort BPM-1400x2 Bedienungsanleitung

Black & Decker

Black & Decker 7266 Bedienungsanleitung

KENT USA

KENT USA TRD1230 Bedienungsanleitung

Bosch

Bosch GSB 19-2 RE Bedienungsanleitung
