Chicago Pneumatic CP8609-B Merkblatt

Product Instructions

Printed Matter No. 6159991160

Date: 2024-01 Issue No. 01

Nutrunner

Model:

CP8609-B

CP8609-BT

CP8609-C

CP8609-CT

CP8609-xC

CP8609-xCT

WARNING

Read all safety warnings and instructions

Failure to follow the safety warnings and instructions may result in

electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference

2© Chicago Pneumatic - 6159991160

Table of Contents

Product Information ..............................................................................................................................3

General Information.........................................................................................................................3

Safety Signal Words.............................................................................................................3

Website ................................................................................................................................3

Overview .........................................................................................................................................3

Connected Version...............................................................................................................3

Product Description..............................................................................................................4

Technical data......................................................................................................................5

Service Overview ............................................................................................................................6

Disposal ...............................................................................................................................6

Installation..............................................................................................................................................7

Installation Instruction......................................................................................................................7

Operation................................................................................................................................................8

Operating Instructions .....................................................................................................................8

Special precaution................................................................................................................8

General Instructions .............................................................................................................8

Standalone Tools Menu .......................................................................................................8

Maintenance Menu...............................................................................................................9

Tools Information Menu .....................................................................................................10

Unit Selection Menu ...........................................................................................................10

Operating the tool...............................................................................................................10

Service..................................................................................................................................................12

Preventing ESD Problems.............................................................................................................12

Daily Inspection .............................................................................................................................12

Maintenance Instruction ................................................................................................................12

Troubleshooting ..................................................................................................................................13

Troubleshooting.............................................................................................................................13

Error Codes ...................................................................................................................................13

Nutrunner EN Product Information

Product Information

General Information

WARNING Risk of Property Damage or Severe Injury

Ensure that you read, understand and follow all instructions before operating the tool. Failure to follow all the

instructions may result in electric shock, fire, property damage and/or severe bodily injury.

►Read all Safety Information delivered together with the different parts of the system.

►Read all Product Instructions for installation, operation and maintenance of the different parts of the system.

►Read all locally legislated safety regulations regarding the system and parts thereof.

►Save all Safety Information and instructions for future reference.

Safety Signal Words

Safety signs have the following meaning:

DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious in-

jury.

WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious

injury.

CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if not

avoided, could result in minor or moderate injury.

NOTICE NOTICE is used to address practices not related to personal injury.

Website

Information concerning our Products, Accessories, Spare Parts and Published Matters can be found on the Chicago

Pneumatic website.

Please visit: www.cp.com.

Overview

Connected Version

To unblock functionalities of CP86 connected versions C, CQ and TC, scan the below QR code and download

CPLinQ to your device. Connect your tool to CPLinQ app.

Product Information EN Nutrunner

4© Chicago Pneumatic - 6159991160

Product Description

CP8609-BT

CP8609-B

1) Second Trigger 1) Display screen

2) Display screen 2) Settings buttons

3) Settings buttons 3) Reporting LEDs

4) Reporting LEDs 4) Reverse button

5) Reverse button 5) Principle trigger

6) Principle trigger 6) Blade

7) Blade

CP8609-C

CP8609-xC

1) Second Trigger 1) Second Trigger

2) Display screen 2) Display screen

3) Settings buttons 3) Settings buttons

4) Reporting LEDs 4) Reporting LEDs

5) Reverse button 5) Reverse button

6) Principle trigger 6) Principle trigger

7) Cup (Optional accessory - see below) 7) Cup (Optional accessory - see below)

Accessories

Accessory Part Number

Spring Loaded Cup 8940164622

Japanese Cup 8940167401

Nutrunner EN Product Information

Connected Version

CP86 series has two connected versions as given below:

• C

• CQ

• TC

To unblock functionalities of the CP86 connected versions C, CQ and TC, download CPLinQ to your device and

connect your tool to CPLinQ app.

Technical data

CP8609-B CP8609-BT CP8609-C CP8609-CT CP8609-xC CP8609-xCT

Free Speed (rpm) 15 15 15 15 15 15

Max. Ambient Storage Tempera-

ture (°C)

60 -60 60 60 60 60

Min. Ambient Storage Tempera-

ture (°F)

-4 -4 -4 -4 -4 -4

Min. Ambient Storage Tempera-

ture (°C)

-20 -60 -20 -20 -20 -20

Max. Ambient Storage Tempera-

ture (°F)

140 140 140 140 140 140

Min. Ambient Operating Tempera-

ture (°C)

0 0 0 0 0 0

Min. Ambient Operating Tempera-

ture (°F)

32 32 32 32 32 32

Max. Ambient Operating Tempera-

ture (°C)

60 60 60 60 60 60

Max. Ambient Operating Tempera-

ture (°F)

140 140 140 140 140 140

Max. Recommended Ambient

Charging Temperature (°C)

45 45 45 45 45 45

Max. Recommended Ambient

Charging Temperature (°F)

113 113 113 113 113 113

Min. Recommended Ambient

Charging Temperature (°C)

0 0 0 0 0 0

Min. Recommended Ambient

Charging Temperature (°F)

32 32 32 32 32 32

Max. Torque Rev. (Nm) 900 900 900 900 900 900

Max. Torque Rev. (ft.lb) 665 665 665 665 665 665

Square Size (") 1 1 1 1 1 1

Battery capacity (Ah) 2.5 2.5 2.5 2.5 2.5 2.5

Battery voltage(V) 36 36 36 36 36 36

Weight(kg) 5.8 5.8 5.6 5.6 6.9 6.9

Weight(lb) 12,7 12,7 12,3 12,3 15.2 15.2

W (mm) 77 77 77 77 77 77

W (") 3 3 3 3 3 3

L (mm) 380 380 380 380 495 495

L (") 14.96 14.96 14.96 14.96 19.5 19.5

L1 (mm) 437 437 491 491 605 605

L1 (") 17.2 17.2 19.33 19.33 23.82 23.82

H (mm) 218 218 218 218 218 218

H (") 8.6 8.6 8.6 8.6 8.6 8.6

H1 (mm) 285 285 285 285 285 285

H1 (") 11.22 11.22 11.22 11.22 11.22 11.22

Product Information EN Nutrunner

6© Chicago Pneumatic - 6159991160

Service Overview

Disposal

• The disposal of this equipment must follow the legislation of the respective country.

• All damaged, badly worn or improperly functioning devices MUST BE TAKEN OUT OF OPERATION.

Nutrunner EN Installation

Installation

Installation Instruction

Battery Pack and Charger

It is recommended to use following battery pack and charger with the CP86 models:

Battery Pack Charger

CP36XP25 (8940176068) CP18-36CH (8940176069)

Battery Wake up

Remove the white protective sticker and plug the battery to the recommended charger.

Battery Installation

1. Attach the battery pack to the tool. Press it until a locking sound can be clearly heard.

2. To remove the battery pack press the button on the battery and push it out.

Operation EN Nutrunner

8© Chicago Pneumatic - 6159991160

Operation

Operating Instructions

Special precaution

WARNING Crushing Hazard

The Dual trigger forces the user to use both hands to operate the tool. If not used, the operator can accidentally

start the tool while adjusting the reaction bar, thus resulting in a serious hand injury.

►Make sure the tool cannot be started once the Dual trigger has been released.

►Always test the tool by first releasing the trigger of the Dual trigger, then push the trigger of the tool. If the

tool starts; stop work.

General Instructions

The tool may only be used together with the associated torque reaction bar, which is adapted to the screw joint appli-

cation concerned.

WARNING Crushing Hazard

Check the rotational direction of the tool before start! A start in an unexpected rotational direction can cause

bodily injury or property damage. Moving parts can crush and cut.

►Make sure that the rotational direction of the tool is correct before starting the tool.

►Keep hands and fingers away from moving parts.

Standalone Tools Menu

CP8609-BT

CP8609-CT

CP8609-xCT

CP8609-B

CP8609-C

CP8609-xC

1) Battery level/Bluetooth connection (C, CQ, TC version) 1) Second Trigger

2) Action for button 2) Battery level/Bluetooth connection (C, CQ, TC version)

3) Button for menu navigation an 3) Action for button

4) Action for button 4) Button for menu navigation an

5) Application Information 5) Action for button

6) Tool 6) Application Information

7) Tool

Nutrunner EN Operation

1. Press the menu button. Access following menus by pressing navigation buttons.

• Maintenance

• Tool Infos

• Select unit

• Calibration

2. When screen shows "Back" on display, press menu button to return on the main menu.

Maintenance Menu

Operation EN Nutrunner

10 © Chicago Pneumatic - 6159991160

Tools Information Menu

Unit Selection Menu

Operating the tool
