Cisco ASR 1001-X Handbuch

Cisco ASR 1001-X Router Hardware Installation Guide

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

CONTENTS

CHAPTER 1

Cisco ASR 1001-X Router Overview 1

Hardware Features of the Cisco ASR 1001-X Router 1

Cisco ASR 1001-X Overall Chassis Front View 2

Cisco ASR 1001-X Router LEDs 3

Cisco ASR 1001-X Management Storage Connections 5

Cisco ASR 1001-X Chassis Rear View 5

Cisco ASR 1001-X SPA GE and TE Ports 6

Field-Replaceable Units for the Cisco ASR 1001-X Router 6

Cisco Product Identification Standard 7

Unique Device Identifier 7

SPA Slot Numbering 9

Serial Number and PID/VID Label Location 9

CHAPTER 2

Cisco ASR 1001-X Router Supported Hardware Components 11

Supported Hardware Components 11

Supported Half-Height SPAs 12

Supported Small Form-Factor Pluggable (SFP and SFP+) Transceivers 14

Supported NIMs 15

NIM-SSD 16

NIM-T1/E1 16

Cisco ASR 1001-X Router Power Supplies 17

Power Supplies for the Cisco ASR 1001-X Router 17

Cisco ASR 1001-X Power Supply Fans 18

Cisco ASR 1001-X Router AC Power Supply 18

Cisco ASR 1001-X Router DC Power Supply 18

AC/DC Power System Input Range and Voltage for the Cisco ASR 1001-X Router 19

Power Cords Supported by the Cisco ASR 1001-X Router 20

Cisco ASR 1001-X Router Hardware Installation Guide

iii

CHAPTER 3

Preparing Your Site for Installation 23

Prerequisites and Preparation 23

Site Planning Checklist 24

Safety Guidelines 24

Safety Warnings 25

Safety Recommendations 25

Compliance Requirements 25

Cautions and Regulatory Compliance Statements for NEBS 26

Standard Warning Statements 27

General Safety Warnings 28

Site Planning 31

General Precautions 31

Site Selection Guidelines 31

Site Environmental Requirements 31

Physical Characteristics 32

Site Power Guidelines 33

Electrical Circuit Requirements 34

Site Cabling Guidelines 35

Console Port Connections 35

USB Serial Console 36

Interference Considerations 36

Electromagnetic Interference 36

Radio Frequency Interference 37

Lightning and AC Power Fault Interference 37

Rack-Mounting Guidelines 37

Precautions for Rack-Mounting 38

General Rack-Selection Guidelines 38

Guidelines for 23-in. (Telco) Racks 39

Equipment Rack Guidelines 39

Locating for Safety 39

Locating for Easy Maintenance 39

Locating for Proper Airflow 40

Preventing Electrostatic Discharge Damage 40

Electrical Safety 41

Cisco ASR 1001-X Router Hardware Installation Guide

Contents

Chassis-Lifting Guidelines 41

Tools and Equipment 42

Unpacking and Verifying Shipping Contents 42

Checking the Shipping Container Contents 43

Cisco ASR 1001-X Router Installation Checklist 44

CHAPTER 4

Cisco ASR 1001-X Router Power Up and Initial Configuration 47

Checking Conditions Prior to System Startup 47

Powering Up the Cisco ASR 1001-X Router 48

Performing the Initial Configuration on the Router 50

Using the Cisco setup Command Facility 50

Completing the Configuration 53

Using the Cisco IOS-XE CLI--Manual Configuration 54

Configuring the Router Hostname 55

Configuring the Enable and Enable Secret Passwords 56

Configuring the Console Idle Privileged EXEC Timeout 57

Examples 58

Gigabit Ethernet Management Interface Overview 58

Default Gigabit Ethernet Configuration 59

Configuring Gigabit Ethernet Interfaces 59

Saving Your Router Configuration 61

Verifying the Initial Configuration 62

Powering Off the Cisco ASR 1001-X Router Safely 62

Environmental Monitoring and Reporting Functions 63

Cisco ASR1001-X Router Alarm Monitoring 63

Environmental Monitoring 64

Fan Failures 65

Reporting Functions 66

CHAPTER 5

Upgrading the ROMMON and CPLD 71

Upgrading the ROMMON 71

Compatibility Requirements 71

Checking the Current ROMMON Version 71

Upgrading the ROMMON for the Cisco ASR 1001-X Router 72

Example: Upgrading a ROMMON 73

Cisco ASR 1001-X Router Hardware Installation Guide

Contents

Compatible ROMMON Releases 75

Resolved Caveats 75

Hardware the Require a CPLD Upgrade 75

Upgrading the CPLD 76

Checking Hardware and Software Compatibility 77

Using Cisco Feature Navigator 77

CHAPTER 6

Cisco ASR 1001-X Router License Verification 79

Viewing the Cisco IOS License Level 79

Configuring the Throughput Level 80

Viewing License Information 81

Per Port Counted License (10-GE Interfaces) 87

10-GE Interface Evaluation License Features 88

CHAPTER 7

Removing and Replacing FRUs from the Cisco ASR 1001-X Router 91

Removing and Replacing the Cisco ASR 1001-X Router Power Supplies 91

Removing AC Power Supplies from the Cisco ASR 1001-X Router 92

Installing AC Power Supplies in the Cisco ASR 1001-X Router 94

Removing DC Input Power from the Cisco ASR 1001-X Router 96

Installing DC Input Power on the Cisco ASR 1001-X Router 97

Wiring the DC Input Power Source 98

Removing and Replacing Cisco ASR 1001-X Router USB Flash Memory Stick or Secure

Token 101

Removing and Replacing the Cisco ASR 1001-X Router DIMM 102

Removing and Replacing the Cisco ASR 1001-X Router DIMM Memory Module 102

Removing a Cisco ASR 1001-X Router DIMM 103

Replacing a Cisco ASR 1001-X Router DIMM 105

Removing and Replacing a Cisco ASR 1001-X Router SPA 108

Electrostatic Discharge Prevention 108

Removing a Shared Port Adapter 109

Replacing a Shared Port Adapter 110

Removing and Replacing a NIM on the Cisco ASR 1001-X Router 111

Removing a NIM 112

Replacing a NIM 113

Removing and Replacing an SSD from the NIM-SSD Module 113

Cisco ASR 1001-X Router Hardware Installation Guide

Contents

Removing an SSD from the NIM-SSD Module 114

Installing an SSD into the NIM-SSD Module 116

Repacking the Router 118

CHAPTER 8

Cisco ASR 1001-X Router Specifications 119

Cisco ASR 1006 Router Specifications 119

Cisco ASR 1006 Router Memory and Storage Options 120

Cisco ASR 1006 Router Ethernet RJ-45 Port Pinouts 120

Cisco ASR 1006 Router MGMT Ethernet Port Pinouts 121

Cisco ASR 1006 Router BITS Port Signals and Pinouts 121

Cisco ASR 1006 Router Console Port Signals and Pinouts 122

Cisco ASR 1006 Router Auxiliary Port Signals and Pinouts 123

Cisco ASR 1006 Router DB-25 Pinout Assignments for Alarm Relays 123

Cisco ASR 1004 Router Specifications 124

Cisco ASR 1004 Router Memory and Storage Options 125

Cisco ASR 1004 Router Ethernet RJ-45 Port Pinouts 125

Cisco ASR 1004 Router MGMT Ethernet Port Signals and Pinouts 126

Cisco ASR 1004 Router Console Port Signals and Pinouts 126

Cisco ASR 1004 Router Auxiliary Port Signals and Pinouts 127

Cisco ASR 1004 Router BITS Port Signals and Pinouts 127

Cisco ASR 1004 Router DB-25 Pinout Assignments for Alarm Relays 128

Cisco ASR 1002 Router, Cisco ASR 1002-F Router, and Cisco ASR 1002-X Router

Specifications 128

Cisco ASR 1002 Router Mgmt Ethernet RJ-45 Port Pinouts 129

Cisco ASR 1002 Router Console Port Signals and Pinouts 130

Cisco ASR 1002 Router Auxiliary Port Signals and Pinouts 131

Cisco ASR 1002 Router BITS Port Signals and Pinouts 131

Cisco ASR 1002-X Router BITS Port Signals and Pinouts 132

Cisco ASR 1002-X Router BNC GPS Ports 132

Cisco ASR 1002-X Router Time of Day Port Pinout 133

Cisco ASR 1013 Router Specifications 133

Cisco ASR 1013 Router Memory and Storage Options 135

Cisco ASR 1013 Router Ethernet RJ-45 Port Pinouts 135

Cisco ASR 1013 Router MGMT Ethernet Port Signals and Pinouts 135

Cisco ASR 1013 Router Console Port Signals and Pinouts 136

Cisco ASR 1001-X Router Hardware Installation Guide

vii

Contents

Cisco ASR 1013 Router Auxiliary Port Signals and Pinouts 136

Cisco ASR 1013 Router BITS Port Signals and Pinouts 137

Cisco ASR 1013 Router DB-25 Pinout Assignments for Alarm Relays 137

Cisco ASR 1001-X Router Specifications 138

Cisco ASR 1001-X Router Memory and Storage Options 139

CHAPTER 9

Cisco ASR 1001-X Router Signals and Pinouts 141

Management Ethernet Port Signals and Pinouts 141

Console Port Signals and Pinouts 142

Auxiliary Port Signals and Pinouts 142

Cisco ASR 1001-X Router Hardware Installation Guide

viii

Contents

CHAPTER 1

Cisco ASR 1001-X Router Overview

The Cisco ASR 1000 Series Aggregation Services Routers are mid-range edge routers that establish a new

price-to-performance class offering benefits to both enterprise and service providers alike. The Cisco ASR

1000 Series Aggregation Services Routers portfolio is based on an innovative custom-built ASIC called

Quantum Flow Processor that aggregates services at scale.

The Cisco ASR 1001-X Router is a part of the Cisco ASR 1000 Series and offers a compact form factor that

consumes less rack space and power while offering 20 Gbps forwarding throughput. The Cisco ASR 1001-X

Router supports all the general-purpose routing and security features of the Cisco ASR 1000 Series

Aggregation Services Routers.

•Hardware Features of the Cisco ASR 1001-X Router, page 1

•Field-Replaceable Units for the Cisco ASR 1001-X Router, page 6

•Cisco Product Identification Standard, page 7

•SPA Slot Numbering, page 9

•Serial Number and PID/VID Label Location, page 9

Hardware Features of the Cisco ASR 1001-X Router

The Cisco ASR 1001-X Router supports:

•Up to 16 GB (8 GB in the base configuration) of DDR3 error-correcting code-protected field- replaceable

memory, with single-bit error correction and multi-bit error detection.

•A nonmodular and fixed Embedded Services Processor (ESP) with a default throughput of 2.5 Gbps

that is upgradable with a software-activated performance license of 5 Gbps, 10 Gbps, or 20 Gbps.

•Up to 8 Gbps security and crypto processing through a dedicated security processor.

•RJ-45 console ports and auxiliary ports, and a mini USB console port.

•One copper Ethernet 10/100/1000 Mbps network management port.

•An embedded USB (eUSB) flash module that supports 8 GB of nonvolatile Flash storage.

•Two USB 2.0 ports for USB flash sticks or USB secure tokens (secure key distribution).

Cisco ASR 1001-X Router Hardware Installation Guide

•Stratum 3E network clocking per GR-1244-CORE, using 1588, 10 GE, GE, SPA, or Network Interface

Module (NIM) interfaces as timing sources.

•Six built-in 1 GE SFP-only interfaces (do not support SFP+), and two built-in 10 GE SFP+ interfaces

(support only 10-GE rate) that support SyncE.

•One half-height SPA bay.

•Software redundancy using Dual IOS, similar to all the other nonhardware redundant routers from the

Cisco ASR 1000 Series Aggregation Services Router family.

•LED indicators for Ethernet and console status, as well as visual system state indications.

•Command-line interface (CLI), alarm, network management, logging, statistics aggregation, and on-board

failure logging (OBFL).

•Environmental chassis management.

•10 MB ternary content-addressable memory (TCAM).

•Up to 20 Gbps sustained forwarding data traffic through the chassis.

•One Network Interface Module (NIM) bay.

The NIM bay supports the T1/E1 NIMs and the Solid State Device (SSD) NIM assembly and drive.Note

•Field-replaceable units (FRU) with online insertion and removal (OIR).

Cisco ASR 1001-X Overall Chassis Front View

The following figure shows the front of the Cisco ASR 1001-X Router.

Figure 1: Cisco ASR 1001-X Router Front View

Shared port adapter slot7NIM slots1

USB port 08

CON—One mini eUSB

por

USB port 19

PWR—Power LED

Cisco ASR 1001-X Router Hardware Installation Guide

Cisco ASR 1001-X Router Overview

Cisco ASR 1001-X Overall Chassis Front View

Andere Handbücher für ASR 1001-X

Inhaltsverzeichnis

Andere Cisco Netzwerk-Router Handbücher

Cisco

Cisco 2600XM Series Bedienungsanleitung

Cisco

Cisco ASR 5000 Bedienungs- und Wartungshandbuch

Cisco

Cisco 12406 series Bedienungsanleitung

Cisco

Cisco 1760 - VPN Bundle Router Handbuch

Cisco

Cisco ASR1004 - ASR 1004 Modular Expansion Base Handbuch

Cisco

Cisco 520-T1 - Small Business Pro SR Secure Router Bedienungsanleitung

Cisco

Cisco ASR 914 Bedienungsanleitung

Cisco

Cisco IOS Router Bedienungsanleitung

Cisco

Cisco 4331 Bedienungsanleitung

Cisco

Cisco RV042 - Small Business Dual WAN VPN Router Bedienungsanleitung

Cisco

Cisco WS-C2960-24LC-S Bedienungsanleitung

Cisco

Cisco 2811 - Voice Security Bundle Router Bedienungsanleitung

Cisco

Cisco IR809 Bedienungsanleitung

Cisco

Cisco Nexus 7000 Series Bedienungsanleitung

Cisco

Cisco VS-C6509E-S720-10G Bedienungsanleitung

Cisco

Cisco Cable Mgmt Bracket Cisco 7513/7576 Bedienungsanleitung

Cisco

Cisco 12410 series Bedienerhandbuch

Cisco

Cisco 1751 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

Cisco

Cisco ASR 1000 Series Bedienungsanleitung

Cisco

Cisco A9K-SIP-700 Handbuch

Cisco

Cisco Linksys X2000 V2 Bedienungsanleitung

Cisco

Cisco RV120W Bedienungsanleitung

Cisco

Cisco ASR 5500 Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

LevelOne

LevelOne FBR-1416 Bedienungsanleitung

Dynacord

Dynacord Promatrix 6000 Bedienungsanleitung

Lorex

Lorex F5D8230-4 Bedienungsanleitung
