D-1

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

APPENDIX

Chassis and Module Power and Heat Values

This appendix provides the power and heat numbers for the Catalyst 6500 series chassis and modules.

The following power requirements and heat dissipation tables are provided:

•Chassis and fan trays—Table D-1

•IP phones—Table D-2

•Supervisor engines—Table D-3

•Policy Feature Cards (PFCs)—Table D-4

•Distributed Forwarding Cards (DFCs)—Table D-5

•Switch fabric modules—Table D-6

•10-Gigabit Ethernet modules—Table D-7

•Gigabit Ethernet modules—Table D-8

•10/100/1000 Ethernet modules—Table D-9

•Fast Ethernet switching modules—Table D-10

•10/100 Ethernet switching modules—Table D-11

•10BASE Ethernet switching modules—Table D-12

•FlexWAN and Enhanced FlexWAN modules—Table D-13

•Service modules—Table D-14

•Miscellaneous modules—Table D-15

Unless otherwise noted, the information in the following tables is measured under fully loaded

conditions (transceivers installed). Typical numbers are approximately 20 percent below the numbers

listed in these tables.

Note Module power is the output from the power supply (internal to the system). The AC-input power is the

input from the outlet to the power supply. The percentage difference between the two values is the

efficiency of the power supply.

D-2

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

Table D-1 Power Requirements and Heat Dissipation—Chassis and Fan Trays

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

Catalyst 6503 chassis

FAN-MOD-3 fan tray 0.80 34.00 43.00 145.00 46.00 156.00

FAN-MOD-3HS fan tray 2.98 125.16 156.45 534.28 168.23 574.49

Catalyst 6503-E chassis

WS-C6503-E-FAN fan tray11.37

3.10

57.54

130.20

71.93

162.75

245.62

555.79

77.34

175.00

264.11

597.63

Catalyst 6504-E chassis

FAN-MOD-4HS fan tray11.43

2.17

60.06

91.14

75.08

113.93

256.38

389.05

80.73

122.50

275.68

418.34

Catalyst 6506 chassis

WS-C6K-6SLOT-FAN fan tray 0.71 30.00 37.48 128.00 40.00 136.88

WS-C6K-6SLOT-FAN2 fan tray 2.00 84.00 105.00 359.00 113.00 386.00

Catalyst 6506-E chassis

WS-C6506-E-FAN fan tray12.35

3.35

98.70

140.70

123.40

175.88

421.33

600.61

132.66

189.11

453.04

645.82

Catalyst 6509 chassis

WS-C6K-9SLOT-FAN fan tray 1.10 46.00 58.00 196.00 62.00 212.00

WS-C6K-9SLOT-FAN2 fan tray 3.04 127.68 159.60 545.03 171.70 586.06

Catalyst 6509-E chassis

WS-C6509-E-FAN fan tray13.58

5.00

150.36

210.00

187.95

262.50

641.85

896.44

202.10

282.26

690.16

963.91

Catalyst 6509-NEB chassis

WS-C6K-NEB-FAN fan tray 7.00 294.00 368.00 1255.00 395.00 1349.00

D-3

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

Catalyst 6509-NEB-A chassis

FAN-MOD-092fan tray 5.75 242.00 302.00 1031.00 325.00 1108.00

Catalyst 6509-V-E chassis3

WS-C6509-V-E-FAN fan tray 5.75 242.00 302.00 1031.00 325.00 1108.00

Catalyst 6513 chassis

WS-C6K-13SLOT-FAN fan tray 1.58 73.00 146.00 499.00 157.00 536.00

WS-C6K-13SLOT-FAN2 fan tray 7.10 298.20 372.75 1272.94 400.81 1368.75

Catalyst 6513-E chassis

WS-C6513-E-FAN 7.10 298.20 372.75 1272.94 400.81 1368.75

1. Two sets of values are given for these fan trays. The Catalyst 6500-E series fan trays are designed to provide two levels of cooling. The lower

set of values shown are for chassis where modules that do not require the additional cooling capacity are installed. The higher set of values shown

are for chassis where either the WS-X6708-10G-3C or -3CXL, or the WS-X6716-10G-3C or -3CXL Ethernet modules are installed. Both of these

Ethernet modules require the fan tray’s additional cooling capacity.

2. Values given are per fan tray. The Catalyst 6509-NEB-A switch chassis ships with one fan tray installed by default. A second fan tray can be

installed in the chassis. The power and heat numbers for a chassis equipped with two fan trays are double the values listed.

3. Values given are per fan tray. The Catalyst 6509-V-E switch chassis ships with one fan tray installed by default. A second fan tray can be installed

in the chassis. The power and heat numbers for a chassis equipped with two fan trays are double the values listed.

Table D-2 Power Requirements and Heat Dissipation—IP Phones

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

Cisco IP Phone 7960 0.15 6.3 7.88 26.89 8.47 28.92

Cisco IP Phone 7940 0.15 6.3 7.88 26.89 8.47 28.92

Cisco IP Phone 7910 0.13 5.46 6.83 23.31 7.34 25.06

Table D-1 Power Requirements and Heat Dissipation—Chassis and Fan Trays (continued)

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

D-4

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

The module power values are based on 42 VDC. Power is distributed to each slot in the chassis from the

power supply’s 42 VDC output. Each module has DC-to-DC power supplies that convert the 42 VDC

into +2.5 VDC, +3.3 VDC, and +5 VDC to power the module. The 42 VDC is independent of the power

supply’s input voltage, either 110 VAC or 220 VAC.

Table D-3 lists the power and the heat numbers for the supervisor engines.

Table D-3 Power Requirements and Heat Dissipation—Supervisor Engines

Model Number/

Module Type

Module

Current (A)

@ 42 VDC

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

WS-X6K-SUP1A-2GE

Supervisor Engine 1A

1.70 71.40 89.25 304.79 95.97 327.73

WS-X6K-SUP1A-PFC

Supervisor Engine 1A with PFC

daughter card

2.50 105 131.25 448.22 141.13 481.96

WS-X6K-SUP1A-MSFC

Supervisor Engine 1A with PFC

and MSFC daughter cards

3.30 138.60 173.25 519.65 186.29 559.18

WS-X6K-SUP1A-MSFC2

Supervisor Engine 1A with PFC

and MSFC2 daughter cards

2.90 121.80 152.25 519.93 163.71 559.07

WS-X6K-S2-PFC2

Supervisor Engine 2 with PFC2

daughter card

3.06 128.52 160.65 548.62 172.74 589.91

WS-X6K-S2-MSFC2

Supervisor Engine 2 with PFC2

and MSFC2 daughter cards

3.46 145.32 181.65 620.33 195.32 667.03

WS-X6K-S2U-MSFC2

Supervisor Engine 2 with PFC2

and MSFC2 daughter

cards—Has 512 MB of DRAM

3.46 145.32 181.65 620.33 195.32 667.03

D-5

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

Model Number/

Module Type

Module

Current (A)

@ 42 VDC

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

WS-SUP32-10GE-3B

Supervisor Engine 32 with

PFC3B and MSFC2A daughter

cards

4.19 175.98 219.98 751.21 236.53 807.76

WS-SUP32-GE-3B

Supervisor Engine 32 with

PFC3B and MSFC2A daughter

cards

3.69 154.98 193.73 661.57 208.31 711.37

WS-S32-GE-PISA

Supervisor Engine 32 with

PFC3B and Programmable IP

Services Accelerator (PISA)

daughter cards.

2.96 124.32 155.40 530.69 167.10 570.64

WS-S32-10GE-PISA

Supervisor Engine 32 with

PFC3B and Programmable IP

Services Accelerator (PISA)

daughter cards

2.97 124.74 155.93 532.48 167.66 572.56

WS-SUP720

Supervisor Engine 720 with

PFC3A daughter card and

integrated MSFC3 and switch

fabric

7.50 315.0 393.75 1344.66 423.39 1445.87

WS-SUP720-3B

Supervisor Engine 720 with

PFC3B daughter card and

integrated MSFC3 and switch

fabric

6.72 282.24 350.80 1204.81 379.35 1295.5

WS-SUP720-3BXL

Supervisor Engine 720 with

PFC3BXL daughter card and

integrated MSFC3 and switch

fabric

7.82 328.44 410.55 1402.03 441.45 1507.56

VS-S720-10G-3C

Supervisor Engine 720-10GE

with PFC3C daughter card and

integrated MSFC3 and switch

fabric

8.05 338.10 422.63 1443.26 454.44 1551.90

VS-S720-10G-3CXL

Supervisor Engine 720-10GE

with PFC3CXL daughter card

and integrated MSFC3 and

switch fabric

8.65 363.30 454.13 1550.84 488.31 1667.57

Table D-3 Power Requirements and Heat Dissipation—Supervisor Engines (continued)

D-6

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

Table D-4 lists the power and the heat numbers for the Policy Feature Cards (PFCs).

Table D-5 lists the power and the heat numbers for the Distributed Forwarding Cards (DFCs).

Table D-4 Power Requirements and Heat Dissipation—Policy Feature Cards (PFCs)

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

WS-F6K-PFC3A

Policy Feature Card 3A

2.25 94.50 118.13 403.40 127.02 433.76

WS-F6K-PFC3B

Policy Feature Card 3B

1.47 61.74 77.18 263.55 82.98 283.39

WS-F6K-PFC3BXL

Policy Feature Card 3BXL

2.57 107.94 134.93 460.77 145.08 495.45

VS-F6K-PFC3C

Policy Feature Card 3C

1.90 79.80 99.75 340.65 107.26 366.29

VS-F6K-PFC3CXL

Policy Feature Card 3CXL

2.50 105.00 131.25 448.22 141.13 481.96

Table D-5 Power Requirements and Heat Dissipation—Distributed Forwarding Cards (DFCs)

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

WS-F6K-DFC

Distributed Forwarding Card

2.10 88.20 110.25 376.50 118.55 404.84

WS-F6K-DFC3A

Distributed Forwarding Card 3A

2.57 107.94 134.93 460.77 145.08 495.45

WS-F6K-DFC3B

Distributed Forwarding Card 3B

1.67 70.14 87.68 299.41 94.27 321.95

WS-F6K-DFC3BXL

Distributed Forwarding

Card 3BXL

2.38 99.96 124.95 426.70 134.35 458.82

WS-F6700-CFC

Centralized Forwarding Card

0.75 31.5 39.38 134.47 42.34 144.59

D-7

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

Table D-6 lists the power and the heat numbers for the switch fabric modules.

WS-F6700-DFC3A

Distributed Forwarding Card 3A

3.0 126 157.5 537.86 169.35 578.35

WS-F6700-DFC3B

Distributed Forwarding Card 3B

2.7 113.40 141.75 484.08 152.42 520.51

WS-F6700-DFC3BXL

Distributed Forwarding

Card 3BXL

3.3 138.60 173.25 591.65 186.29 636.18

WS-F6700-DFC3C

Distributed Forwarding Card 3C

for use on CEF720 modules.

Supported only with Supervisor

Engine 720 and Supervisor

Engine 720-10GE

1.65 69.30 86.63 295.82 93.15 318.09

WS-F6700-DFC3CXL

Distributed Forwarding

Card 3CXL for use on CEF720

modules. Supported only with

Supervisor Engine 720 and

Supervisor Engine 720-10GE.

2.35 98.70 123.38 421.33 132.66 453.04

Table D-5 Power Requirements and Heat Dissipation—Distributed Forwarding Cards (DFCs) (continued)

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

Table D-6 Power Requirements and Heat Dissipation—Switch Fabric Modules

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

WS-C6500-SFM

Switch Fabric Module

2.79 117.18 146.5 500.2 157.5 537.86

WS-X6500-SFM2

Switch Fabric Module 2

3.09 129.78 162.23 554 174.4 595.7

D-8

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

Table D-7 lists the power and the heat numbers for the 10-Gigabit Ethernet modules.

Note For the WS-X6502-10GE and WS-X6704-10GE Ethernet modules, the values shown are for the

baseboard only. When the baseboard has a CFC or DFC3 daughter card installed, you must add the

daughter card power to the baseboard power to get the total slot power. For the WS-X6708-10G-3C,

WS-X6708-10G-3CXL, WS-X6716-10G-3C , and the WS-X6716-10G-3CXL Ethernet modules, the

values shown include the factory installed WS-F6700-DFC3C or WS-F6700-DFC3CXL daughter cards.

Table D-7 Power Requirements and Heat Dissipation—10-Gigabit Ethernet Modules

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

WS-X6502-10GE

2-port 10-Gigabit Ethernet

module

3.30 138.60 173.25 591.65 186.29 636.18

WS-X6704-10GE

4-Port 10-Gigabit Ethernet

module

6.28 263.76 329.70 1125.93 354.52 1210.67

WS-X6708-10G-3C

8-Port 10-Gigabit Ethernet

module with WS-F6700-DFC3C

daughter card.

10.58 444.36 555.45 1896.86 600.49 2050.66

WS-X6708-10G-3CXL

8-Port 10-Gigabit Ethernet

module with

WS-F6700-DFC3CXL daughter

card.

11.28 473.76 592.20 2022.36 640.22 2186.34

WS-X6716-10G-3C

16-Port 10-Gigabit Ethernet

module with WS-F6700-DFC3C

daughter card.

10.90 457.80 572.25 1954.23 615.32 2101.33

WS-X6716-10G-3CXL

16-Port 10-Gigabit Ethernet

module with

WS-F6700-DFC3CXL daughter

card.

11.60 487.20 609.00 2079.74 654.84 2236.27

WS-X6716-10T-3C

16-Port 10-Gigabit Ethernet

module with WS-F6700-DFC3C

daughter card.

11.53 484.26 605.33 2067.18 650.89 2222.78

WS-X6716-10T-3CXL

16-Port 10-Gigabit Ethernet

module with

WS-F6700-DFC3CXL daughter

card.

12.23 513.66 642.08 2192.69 690.40 2357.73

D-9

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

Table D-8 lists the power and the heat numbers for the Gigabit Ethernet modules.

Table D-8 Power Requirements and Heat Dissipation—Gigabit Ethernet Modules

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

WS-X6316-GE-TX

16-port 1000BASE-T Gigabit

Ethernet module

5.15 216.3 270.38 923.33 290.73 992.83

WS-X6408A-GBIC

8-port 1000BASE-X Gigabit

Ethernet module

2.00 84.00 105.00 358.58 112.90 385.56

WS-X6416-GBIC

16-port 1000BASE-X Gigabit

Ethernet module

2.81 118.02 147.53 503.8 158.63 541.72

WS-X6416-GE-MT

8-port 1000BASE-SX Gigabit

Ethernet module

2.50 105.00 131.25 448.22 141.13 481.96

WS-X6516-GBIC

16-port 1000BASE-X Gigabit

Ethernet module

3.40 142.80 178.50 609.58 191.94 655.46

WS-X6516A-GBIC

16-port 1000BASE-X Gigabit

Ethernet module

3.62 152.04 190.05 649.02 204.35 697.87

WS-X6724-SFP

24-Port 1000BASE-X Ethernet

module

2.23 99.66 117.08 399.81 125.89 429.90

WS-X6748-SFP

48-Port 1000BASE-X Ethernet

module

5.32 223.44 279.30 953.81 300.32 1025.60

WS-X6816-GBIC

16-Port1000BASE-X Gigabit

Ethernet module

3.84 161.28 201.60 688.46 216.77 740.28

D-10

Catalyst 6500 Series Switches Installation Guide

OL-5781-08

Appendix D Chassis and Module Power and Heat Values

Table D-9 lists the power and the heat numbers for the 10/100/1000 Ethernet switching modules.

Table D-9 Power Requirements and Heat Dissipation—10/100/1000 Ethernet Switching Modules

Model Number/

Module Type

Module

Current (A)

Module

Power

(Watts)

AC DC

AC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

DC-Input

Power

(Watts)

Heat Diss.

(BTU/HR)

WS-X6148-GE-TX

48-port 10/100/1000 Ethernet

module

2.47 104.0 130.0 443.0 139.0 476.0

WS-X6148V-GE-TX

48-port 10/100/1000 Ethernet

module with

WS-F6K-VPWR-GE PoE

daughter card

2.89 121.38 151.72 518.14 163.15 557.14

WS-X6148-GE-45AF

48-port 10/100/1000 Ethernet

module with WS-F6K-GE48-AF

PoE daughter card

2.65 111.30 139.13 475.11 149.60 510.87

WS-X6148A-GE-TX

48-port 10/100/1000 Ethernet

module

2.5 105.0 131.25 448.22 141.13 481.96

WS-X6148A-GE-45AF

48-port 10/100/1000 Ethernet

module with WS-F6K-GE48-AF

PoE daughter card

2.68 112.56 140.70 480.49 151.29 516.66

WS-X6516-GE-TX

16-port 10/100/1000 Ethernet

module

3.45 144.90 181.13 618.54 194.76 665.10

WS-X6548-GE-TX

48-port 10/100/1000 Ethernet

module

2.98 125.16 156.45 534.28 168.23 574.49

WS-X6548V-GE-TX

10/100/1000 Ethernet module

with WS-F6K-VPWR-GE PoE

daughter card

3.40 142.80 178.50 609.58 191.94 655.46

WS-X6548-GE-45AF

48-port 10/100/1000 Ethernet

module with WS-F6K-GE48-AF

PoE daughter card

3.16 132.72 165.90 566.55 178.39 609.19

WS-X6748-GE-TX

10/100/1000 Ethernet module

7.00 294.00 367.50 1255.01 395.16 1349.48

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Cisco Schalten Handbücher

Cisco

Cisco 2960-48TC - Catalyst Switch Handbuch

Cisco

Cisco Catalyst 3120G Gebrauchsanweisung

Cisco

Cisco Nexus 93180YC-FX Handbuch

Cisco

Cisco Catalyst 9300X Handbuch

Cisco

Cisco Nexus 9808 NX-OS Handbuch

Cisco

Cisco Catalyst 3560V2-24PS Bedienungsanleitung

Cisco

Cisco Catalyst 2960-S Series Handbuch

Cisco

Cisco Cisco mds 9216 - fabric switch Bedienungsanleitung

Cisco

Cisco ME 6500 Bedienungs- und Sicherheitshinweise

Cisco

Cisco NIM-ES2-8 Bedienungsanleitung

Cisco

Cisco 2950-12 - Catalyst Switch Abmessungen

Cisco

Cisco Catalyst 2960-XR Bedienungsanleitung

Cisco

Cisco SRW224G4P - Small Business Managed Switch Kurzanleitung

Cisco

Cisco WS X4148 RJ21 - Catalyst 4000 Series 10/100 Telco... Bedienungsanleitung

Cisco

Cisco WS-C3560E-24PD-E Installationshandbuch

Cisco

Cisco 6500 - Catalyst Series 10 Gigabit EN Interface Module... Bedienungsanleitung

Cisco

Cisco Catalyst Series Switch 2940 Bedienungsanleitung

Cisco

Cisco Catalyst 3920 Bedienungsanleitung

Cisco

Cisco Catalyst 2955 Series Bedienungsanleitung

Cisco

Cisco ME 3400 Series Handbuch

Cisco

Cisco 3750 - Catalyst EMI Switch Installationshandbuch

Cisco

Cisco 8800 Series Bedienungsanleitung

Cisco

Cisco MDS 9000 Series Installationshandbuch

Cisco

Cisco 3020 - Cisco Catalyst Blade Switch Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
