Product Overview

This chapter describes the Cisco ME 6500 series Ethernet switches and contains these sections:

•Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S), page 1-1

•Cisco ME 6524 Ethernet Switch (ME-C6524GT-8S), page 1-8

Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)

The ME 6524 Ethernet switch (ME-C6524GS-8S) is a member of the Cisco ME 6500 series Ethernet

switches. The Cisco ME 6524 Ethernet switch (ME-C6524GS-8S) is a 1.5 RU horizontal chassis with

24 SFP downlink ports and 8 SFP uplink ports. Table 1-1 lists the features of the Cisco ME 6524

Ethernet switch (ME-C6524GS-8S) chassis. Table 1-2 lists the specifications of the Cisco ME 6524

Ethernet switch (ME-C6524GS-8S) chassis. Table 1-3 lists the front panel LEDs and their meanings.

Figure 1-1 shows the front view of the chassis with the major features identified; Figure 1-2 shows the

rear view of the chassis with the major features identified.

Table 1-1 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S) Features

Feature Description

Chassis 1.5 RU height, fixed configuration chassis

Modules Fixed configuration chassis; modules cannot be installed in the chassis.

Fan Tray •Supports one hot swappable fan tray (FAN-C6524). The fan tray

contains seven fans for chassis cooling. The individual fans are not

replaceable.

•Fan tray FAN LED

–

Green—Fan tray is operating normally.

–

Red—One or more individual fans have failed.

Power Supplies •Supports one or two power supplies. The following power supplies are

supported:

–

PWR-400W-DC (400 W DC-input power supply)

•Power supply LEDs—Refer to Table A-1 on page A-1 for LED colors

and their meanings.

1-2

Cisco ME 6500 Series Ethernet Switch Installation Guide OL-8900-01

Chapter 1 Product Overview

Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)

Pluggable transceivers supported •SFP transceivers. The 8 uplink ports support the following SFP

transceiver types:

–

GLC-T—1000BASE-T

–

GLC-SX-MM—1000BASE-SX

–

GLC-LH-SM—1000BASE-LX/LH

–

GLC-ZX-SM—1000BASE-ZX

–

GLC-BX-D—1000BASE-BX10-D

–

GLC-BX-U—1000BASE-BX10-U

–

GLC-FE-100BX-D—100BASE-BX10-D

–

GLC-FE-100BX-U—100BASE-BX10-U

–

CWDM-SFP-xxxx—CWDM SFP transceivers

The 24 downlink ports support the following SFP transceiver types:

–

GLC-T—1000BASE-T

–

GLC-SX-MM—1000BASE-SX

–

GLC-LH-SM—1000BASE-LX/LH

–

GLC-ZX-SM—1000BASE-ZX

–

GLC-BX-D—1000BASE-BX10-D

–

GLC-BX-U—1000BASE-BX10-U

–

GLC-FE-100BX-D—100BASE-BX10-D

–

GLC-FE-100BX-U—100BASE-BX10-U

Note Refer to Appendix B for SFP transceiver cabling distances and

additional information.

Front panel LEDs The chassis front panel has the following LEDs:

•PS1

•PS2

•FAN

•STATUS

•Downlink ports (24 LEDs)

•CompactFlash Activity

•Uplink ports (8 LEDs)

Note Refer to Table 1-3 for LED colors and their meanings.

Table 1-1 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S) Features (continued)

Feature Description

1-3

Cisco ME 6500 Series Ethernet Switch Installation Guide

OL-8900-01

Chapter 1 Product Overview Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)

RESET switch A recessed switch allows the user to reset the system.

Console port A single console port allows the user access to the command-line interface.

The console port has an RJ-45 connector.

USB ports The switch has two USB ports:

•Port 1 is a device port with a Type B USB connector. A standard

USB 1.1 host, such as a PC, can plug into this port.

•Port 2 is a host port with a Type A USB connector. A standard USB 1.1

device, such as Flash memory, can plug into this port.

PCMCIA slot Type 2 CompactFlash devices can be installed in this slot.

Downlink ports The chassis front panel has 24 downlink ports. An SFP transceiver must be

installed for the port to operate. Cable type and recommended cabling

distance are determined by the type of SFP transceiver installed in the

downlink port.

Uplink ports The chassis front panel has 8 uplink ports. An SFP transceiver must be

installed for the port to operate. Cable type and recommended cabling

distance are determined by the type of SFP transceiver installed in the uplink

port.

Table 1-1 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S) Features (continued)

Feature Description

1-4

Cisco ME 6500 Series Ethernet Switch Installation Guide OL-8900-01

Chapter 1 Product Overview

Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)

Table 1-2 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S) Speciﬁcations

Item Specification

Environmental

Temperature, ambient

operating Certified for operation: 32˚ to 104˚F (0˚ to 40˚C)

Designed and tested for operation: 32˚ to 130˚F (0˚ to 55˚C)

Note The Cisco ME 6524 Ethernet switch is equipped with internal air

temperature sensors that generate a minor alarm at 104˚F (40˚C) and

a major alarm at 131˚F (55˚C).

Temperature, ambient

nonoperating and storage –4˚ to 149˚F (–20˚ to 65˚C)

Thermal transition 0.5˚C per minute (hot to cold)

0.33˚C per minute (cold to hot)

Humidity (RH), ambient

(noncondensing) operating 5% to 90%

Humidity (RH), ambient

(noncondensing)

nonoperating and storage

5% to 95%

Altitude, operating Certified for operation: 0 to 6500 feet (0 to 2000 m)

Designed and tested for operation: –200 to 10,000 feet (–60 to 3000 m)

Shock and vibration This switch complies with Network Equipment Building Systems (NEBS)

(Zone 4 per GR-63-Core) in the following areas:

•Earthquake environment and criteria

•Office vibration and criteria

•Transportation vibration and criteria

Shock

•Operational—5 G 30 ms, half-sine (IEC 68-2-27)

•Nonoperational—20 G, 7.5 ms, trapezoidal

Vibration

Operational—3 Hz to 500 Hz,

Power Spectral Density (PSD)-0.0005 G2/Hz at 10 Hz and 200 Hz.

5 dB/octave roll off at each end. 0.5 hours per axis (1.12 Grms).

Acoustic Noise 64 to 76 dB. International Organization for Standardization (ISO) 7779:

Bystander position operating to an ambient temperature of 86˚F (30˚C).

1-5

Cisco ME 6500 Series Ethernet Switch Installation Guide

OL-8900-01

Chapter 1 Product Overview Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)

Physical Characteristics

Dimensions (H x W x D) •2.58 x 17.29 x 19.00 in. (6.54 x 43.92 x 48.26 cm).

•Chassis requires 1.5 RU1.

•Chassis can be mounted in 19-inch equipment racks that meet

ANSI/EIA 310-D and ETS 300-119 standards.

Weight 29.13 lb (13.21 kg).

Airflow •FAN-C6524—110 CFM

Note To maintain proper air circulation through the switch chassis, we

recommend that you maintain a minimum 6-inch (15 cm) separation

between a wall and the chassis air intake or a wall and the chassis air

exhaust. You should also allow a minimum separation of 12 inches

(30.5 cm) between the hot air exhaust on one chassis and the air

intake on another chassis. Failure to maintain adequate air space can

cause the chassis to overheat and the system to fail.

1. RU = rack units

Table 1-3 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S) Front Panel LEDs

LED Color/Meaning

PS1

(Power supply 1)

Green—Power supply is on and the input and output voltages are OK.

Red—The power supply has a fault.

Off—The power supply is off or is not installed.

PS2

(Power supply 2)

Green—Power supply is on and the input and output voltages are OK.

Red—The power supply has a fault.

Off—The power supply is off or is not installed.

FAN Green—Fan tray is operating normally.

Red—One or more individual fans in the fan tray have failed.

STATUS Green—The system is operating normally.

Red—A fault has been detected in the system.

Amber—System is booting up.

Off—The system is not powered up.

Table 1-2 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S) Speciﬁcations (continued)

Item Specification

1-6

Cisco ME 6500 Series Ethernet Switch Installation Guide OL-8900-01

Chapter 1 Product Overview

Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)

Figure 1-1 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)—Front View

Uplink port

(8 LEDs)

Green—The link is established and operational.

Amber—The port is disabled.

Blinking amber—The system has detected a fault with the link.

Off—No link is established or the SFP transceiver is not installed.

Downlink port

(24 LEDs)

Green—The link is established and operational.

Amber—The port is disabled.

Blinking amber—The system has detected a fault with the link.

Off—No link is established or the SFP transceiver is not installed.

Table 1-3 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S) Front Panel LEDs (continued)

LED Color/Meaning

1STATUS LEDs 2Console port (RJ-45 connector)

3Downlink ports LEDs 4USB ports

5PCMCIA slot 6Uplink ports LEDs

7ESD ground connector 8Uplink ports (SFP transceivers required)

9Downlink ports (SFP transceivers required)

147977

Catalyst 6524GS

PS1

USB FLASH

PS2

FAN

STATUS

CONSOLE

10 11

12 13

14 15

15 17

18 19

20 21

22 23

26 27

28 29

30 31

910

11 12

13 14

15 16

17 18

19 20

21 22

23 24

25 26

27 28

29 30

31 32

987

1-7

Cisco ME 6500 Series Ethernet Switch Installation Guide

OL-8900-01

Chapter 1 Product Overview Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)

Figure 1-2 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)—Rear View

1System ground pad/NEBS ground location 2Power supplies

3Fan tray 4Power supply status LEDs

5Power supply terminal block 6Power on/off switch

147978

INPUT

OUTPUT

OK FAN

INPUT

OUTPUT

OK FAN

456

1-8

Cisco ME 6500 Series Ethernet Switch Installation Guide OL-8900-01

Chapter 1 Product Overview

Cisco ME 6524 Ethernet Switch (ME-C6524GT-8S)

The Cisco ME 6524 Ethernet switch (ME-C6524GT-8S) is a member of the Cisco ME 6500 series

Ethernet switches. The Cisco ME 6524 Ethernet switch (ME-C6524GT-8S) is a 1.5 RU horizontal

chassis with 24 10/100/1000 downlink ports and 8 1000BASE SFP uplink ports. Table 1-4 lists the

features of the Cisco ME 6524 Ethernet switch (ME-C6524GT-8S) chassis. Table 1-5 lists the

specifications of the Cisco ME 6524 Ethernet switch (ME-C6524GT-8S) chassis. Table 1-6 lists the

front panel LEDs and their meanings. Figure 1-3 shows the front view of the chassis with the major

features identified; Figure 1-4 shows the rear view of the chassis with the major features identified.

Table 1-4 Cisco ME 6524 Ethernet Switch (ME-C6524GT-8S) Features

Feature Description

Chassis 1.5 RU height, fixed configuration chassis

Modules Fixed configuration chassis; modules cannot be installed in the chassis.

Fan Tray •Supports one hot swappable fan tray (FAN-C6524). The fan tray

contains seven fans for chassis cooling. The individual fans are not

replaceable.

•Fan tray FAN LED

–

Green—Fan tray is operating normally.

–

Red—One or more individual fans have failed.

Power Supplies •Supports one or two power supplies. The following power supplies are

supported:

–

PWR-400W-DC (400 W DC-input power supply)

•Power supply LEDs—Refer to Table A-1 on page A-1 for LED colors

and their meanings.

Pluggable transceivers supported •SFP transceivers. The 8 uplink ports support the following SFP

transceivers:

–

GLC-T—1000BASE-T

–

GLC-SX-MM—1000BASE-SX

–

GLC-LH-SM—1000BASE-LX/LH

–

GLC-ZX-SM—1000BASE-ZX

–

GLC-BX-D—1000BASE-BX10-D

–

GLC-BX-U—1000BASE-BX10-U

–

GLC-FE-100BX-D—100BASE-BX10-D

–

GLC-FE-100BX-U—100BASE-BX10-U

–

CWDM-SFP-xxxx—CWDM SFP transceivers

Note Refer to Appendix B for SFP transceiver cabling distances and

additional information.

1-9

Cisco ME 6500 Series Ethernet Switch Installation Guide

OL-8900-01

Chapter 1 Product Overview Cisco ME 6524 Ethernet Switch (ME-C6524GT-8S)

Front panel LEDs The chassis front panel has the following LEDs:

•PS1

•PS2

•FAN

•STATUS

•Downlink ports (24 LEDs)

•CompactFlash Activity

•Uplink ports (8 LEDs)

Note Refer to Table 1-3 for LED colors and their meanings.

RESET switch A recessed switch allows the user to reset the system.

Console port A single console port allows the user access to the command-line interface.

The console port has an RJ-45 connector.

USB ports The switch has two USB ports:

•Port 1 is a device port with a Type B USB connector. A standard

USB 1.1 host, such as a PC, can plug into this port.

•Port 2 is a host port with a Type A USB connector. A standard USB 1.1

device, such as Flash memory, can plug into this port.

PCMCIA slot Type 2 CompactFlash devices can be installed in this slot.

Downlink ports The chassis front panel has 24 downlink ports. These are 10/100/1000 ports

using RJ-45 female connectors.

Uplink ports The chassis front panel has 8 uplink ports. An SFP transceiver must be

installed for the port to operate. Cable type and recommended cabling

distance are determined by the type of SFP transceiver installed in the uplink

port.

Table 1-4 Cisco ME 6524 Ethernet Switch (ME-C6524GT-8S) Features (continued)

Feature Description

1-10

Cisco ME 6500 Series Ethernet Switch Installation Guide OL-8900-01

Chapter 1 Product Overview

Cisco ME 6524 Ethernet Switch (ME-C6524GT-8S)

Table 1-5 Cisco ME 6524 Ethernet Switch (ME-C6524GT-8S) Speciﬁcations

Item Specification

Environmental

Temperature, ambient

operating Certified for operation: 32˚ to 104˚F (0˚ to 40˚C)

Designed and tested for operation: 32˚ to 130˚F (0˚ to 55˚C)

Note The Cisco ME 6524 Ethernet switch is equipped with internal air

temperature sensors that generate a minor alarm at 104˚F (40˚C) and

a major alarm at 131˚F (55˚C).

Temperature, ambient

nonoperating and storage –4˚ to 149˚F (–20˚ to 65˚C)

Thermal transition 0.5˚C per minute (hot to cold)

0.33˚C per minute (cold to hot)

Humidity (RH), ambient

(noncondensing) operating 5% to 90%

Humidity (RH), ambient

(noncondensing)

nonoperating and storage

5% to 95%

Altitude, operating Certified for operation: 0 to 6500 feet (0 to 2000 m)

Designed and tested for operation: –200 to 10,000 feet (–60 to 3000 m)

Shock and vibration This switch complies with Network Equipment Building Systems (NEBS)

(Zone 4 per GR-63-Core) in the following areas:

•Earthquake environment and criteria

•Office vibration and criteria

•Transportation vibration and criteria

Shock

•Operational—5 G 30 ms, half-sine (IEC 68-2-27)

•Nonoperational—20 G, 7.5 ms, trapezoidal

Vibration

Operational—3 Hz to 500 Hz,

Power Spectral Density (PSD)-0.0005 G2/Hz at 10 Hz and 200 Hz.

5 dB/octave roll off at each end. 0.5 hours per axis (1.12 Grms).

Acoustic Noise 64 to 76 dB. International Organization for Standardization (ISO) 7779:

Bystander position operating to an ambient temperature of 86˚F (30˚C).

Andere Handbücher für ME 6500

Inhaltsverzeichnis

Andere Cisco Schalten Handbücher

Cisco

Cisco WS X4148 RJ21 - Catalyst 4000 Series 10/100 Telco... Bedienungsanleitung

Cisco

Cisco SFS 7012 InfiniBand Installationshandbuch

Cisco

Cisco 3020 - Cisco Catalyst Blade Switch Bedienungsanleitung

Cisco

Cisco 3750 - Catalyst EMI Switch Merkblatt

Cisco

Cisco LightStream 100 Bedienungsanleitung

Cisco

Cisco Catalyst 3550 Bedienungsanleitung

Cisco

Cisco 8800 Series Bedienungsanleitung

Cisco

Cisco Catalyst 3550 Bedienungsanleitung

Cisco

Cisco 3750G-12S - Catalyst Switch - Stackable Handbuch

Cisco

Cisco Nexus 3000 series Bedienungsanleitung

Cisco

Cisco 3560G-24PS - Catalyst Switch Abmessungen

Cisco

Cisco SR2024 - Small Business Unmanaged Switch Bedienungsanleitung

Cisco

Cisco SF250-48HP Bedienungsanleitung

Cisco

Cisco IE 4000 Bedienungsanleitung

Cisco

Cisco MDS 9000 Series Bedienungsanleitung

Cisco

Cisco 3750 - Catalyst EMI Switch Bedienungsanleitung

Cisco

Cisco Nexus 93108TC-FX3P Handbuch

Cisco

Cisco Catalyst 3750-E Series Bedienungsanleitung

Cisco

Cisco 6509 - Catalyst Chassis Switch Bedienungsanleitung

Cisco

Cisco SRW2008P Bedienungsanleitung

Cisco

Cisco Business 250 Series Bedienungsanleitung

Cisco

Cisco Catalyst 2960 Series Bedienungsanleitung

Cisco

Cisco 4900M - Catalyst Switch Bedienungsanleitung

Cisco

Cisco Meraki MS350 Series Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
