Data Sheet

Cisco SRW2008 8-Port Gigabit Switch: WebView

Cisco Small Business Managed Switches

High-performance, secure switching for small businesses

Highlights

●Eight high-speed ports to support bandwidth-intensive applications

●Strong security protects network traffic to keep unauthorized users off the network

●Intelligent QoS helps ensure a consistent network experience and supports networked

applications including voice, video, and data storage

●Simplified, web-based management for easy installation and configuration

Figure 1. Cisco SRW2008 8-Port Gigabit Switch: WebView

Product Overview

The Cisco®SRW2008 8-Port Gigabit Switch (Figure 1) brings Gigabit speeds to your users while

adding intelligence and security to the network. The eight 10/100/1000 Mbps ports enable you to

take advantage of the Gigabit Ethernet interfaces shipping in the current generation of servers,

workstations, and storage devices, in addition to supporting existing 10/100 Mbps clients. The

optional mini Gigabit Interface Converter (mini-GBIC) ports allow you to expand your network as

your business grows.

For security, the Cisco SRW2008 incorporates IEEE 802.1 VLANs, IEEE 802.1X port

authentication, and MAC-based filtering. The switch also has access control lists (ACLs), which

provide more granular security settings as well as improved QoS control through IEEE 802.1p,

Differentiated Services (DiffServ), or type of service (ToS) prioritization schemes. The enhanced

QoS capability, combined with the SRW2008’s advanced traffic-management features, helps

ensure clear and reliable voice and video communications.

WebView management software provides an intuitive, secure management interface, enabling you

to better utilize the comprehensive feature set of the Cisco SRW2008, for a better-optimized, more

secure network.

Data Sheet

Features

●Eight 10/100/1000 Gigabit Ethernet ports

●Two mini-GBIC slots for fiber and copper Gigabit Ethernet expansion

●16-Gbps, nonblocking, store-and-forward switching capacity

●Simplified QoS management using 802.1p, DiffServ, or ToS traffic prioritization

specifications

●ACLs for granular security and QoS implementation

●Configuration and monitoring from a standard web browser with WebView management

●Secure remote management of the switch via Secure Shell (SSH) and SSL encryption

●802.1Q-based VLANs enable segmentation of networks for improved performance and

security

●Private VLAN Edge (PVE) for simplified network isolation of guest connections or

autonomous networks

●Automatic configuration of VLANs across multiple switches through Generic VLAN

Registration Protocol (GVRP) and Generic Attribute Registration Protocol (GARP)

●User/network port-level security via 802.1X authentication and MAC-based filtering

●Increased bandwidth and added link redundancy with Link Aggregation Control Protocol

(LACP)

●Enhanced rate-limiting capabilities and storm control, including multicast, broadcast, and

flood control

●Port mirroring for noninvasive monitoring of switch traffic

●Jumbo frame support (10 KB)

●Simple Network Management Protocol (SNMP) versions 1, 2c, and 3 and Remote

Monitoring (RMON) support

●Fully rack mountable using the included rack-mounting hardware

Specifications

Table 1 contains the specifications, package contents, and minimum requirements for the Cisco

SRW2008P 8-Port Gigabit Switch.

Table 1. Specifications for the Cisco SRW2008P 8-Port Gigabit Switch: WebView/PoE

Specifications

Ports ●8 RJ-45 connectors for 10BASE-T/100BASE-TX/1000BASE-T with 2 Gigabit combo

ports shared between mini-GBIC ports and ports 7 and 8

●Console port

●Auto medium dependent interface (MDI) and MDI crossover (MDI-X)

●Auto negotiate/manual setting

Cabling type ●Unshielded twisted pair (UTP) Category 5 or better for 10BASE-T/100BASE-TX

●UTP Category 5 Ethernet or better for 1000BASE-T

LEDs Link/Act, Gigabit speed, System

Performance

Switching capacity 16 Gbps, nonblocking

Forwarding rate 11.9 mpps wire-speed performance

Layer 2

MAC table size 8000

Data Sheet

Number of VLANs 256 active VLANs (VLAN ID range is 4096)

VLAN ●Port-based and 802.1Q tag-based VLANs

●Management VLAN

Head-of-line (HOL) blocking HOL blocking prevention

Management

Web user interface Built-in web user interface for easybrowser-based configuration (HTTP/HTTPS)

SNMP SNMP versions 1, 2c, and 3 with support for traps

SNMP MIBs RFC1213 MIB-2, RFC2863 interface MIB, RFC2665 Ether-like MIB, RFC1493 bridge MIB,

RFC2674 extended bridge MIB (P-bridge, Q-bridge), RFC2819 RMON MIB (groups 1, 2, 3,

and 9 only), RFC2737 entity MIB, RFC 2618 RADIUS client MIB RFC 1215 traps

RMON Embedded RMON software agent supports 4 RMON groups (history, statistics, alarms, and

events) for enhanced traffic management, monitoring, and analysis

Firmware upgrade Web browser upgrade (HTTP) and Trivial File Transfer Protocol (TFTP)

Port mirroring Traffic on a port can be mirrored to another port for analysis with a network analyzer or

RMON probe

Other management ●Traceroute

●SSL

●SSH

●RADIUS

●Port mirroring

●TFTP upgrade

●SSL security for web user interface

●Dynamic Host Configuration Protocol (DHCP) client

●BOOTP

●Simple Network Time Protocol (SNTP)

●Xmodem upgrade

●Cable diagnostics

●Ping

●Telnet client (SSH secure support)

Security

IEEE 802.1X 802.1X - RADIUS authentication; MD5 encryption

Access control ACLs - Drop or rate limit based on:

●Source and destination MAC-based

●Source and destination IP address

●Protocol

●ToS/DSCP

●Port

●VLAN

●Ethertype

Availability

Link aggregation

●Link aggregation using IEEE 802.3ad LACP

●Up to 8 ports in up to 8 groups

Storm control Broadcast, multicast, and unknown unicast

Spanning Tree ●IEEE 802.1D Spanning Tree, IEEE 802.1w Rapid Spanning Tree

●IEEE 802.1s Multiple Spanning Tree

Internet Group Management

Protocol (IGMP) snooping IGMP (versions 1 and 2) snooping limits bandwidth-intensive video traffic to only the

requestors. Supports 256 multicast groups

QoS

Priority levels 4 hardware queues

Scheduling Priority queuing and weighted round-robin (WRR)

Data Sheet

Class of service ●Port based

●802.1p VLAN priority based

●IPv4/v6 IP precedence/ToS/DSCP based

●TCP/User Datagram Protocol (UDP) port based

●DiffServ

●Classification and re-marking ACLs

Rate limiting ●Ingress policer

●Egress rate control

Standards 802.3 10BASE-T Ethernet, 802.3u 100BASE-TX Fast Ethernet, 802.3ab 1000BASE-T

Gigabit Ethernet, 802.3z Gigabit Ethernet, 802.3x flow control, 802.3ad LACP, 802.1d

Spanning Tree Protocol (STP), 802.1Q/p VLAN, 802.1w Rapid STP, 802.1s Multiple STP,

802.1X port access authentication

Environmental

Dimensions

W x H x D 11 x 1.75 x 6.69 in.

(279 x 45 x 170 mm)

Unit weight 2.20 lb (1 kg)

Power External AC power adapter

Certification FCC Part 15 Class A, CE Class A, UL, cUL, CE mark, CB

Operating temperature 32º to 104ºF (0º to 40ºC)

Storage temperature -4º to 158ºF (-20º to 70ºC)

Operating humidity 10% to 90%

Storage humidity 10% to 95%

Package Contents

●Cisco SRW2008P 8-Port Gigabit Switch

●AC power adapter and cord

●Rack-mounting kit

●CD with user guide in PDF format

●Registration card

●Console cable

Minimum Requirements

●Web-based utility: Microsoft Internet Explorer (version 5.5 or later)

●Category 5 Ethernet network cables

●Operating system: Windows 2000, XP, or later

Product Warranty

5-year limited hardware warranty with return to factory replacement and 90-day limited software warranty

Cisco Limited Warranty for Cisco Small Business Series Products

This Cisco Small Business product comes with a 5-year limited hardware warranty with return to

factory replacement and a 90-day limited software warranty. In addition, Cisco offers software

application updates for bug fixes and telephone technical support at no charge for the first 12

months following the date of purchase. To download software updates, go to:

http://www.cisco.com/go/smallbiz.

Product warranty terms and other information applicable to Cisco products are available at

http://www.cisco.com/go/warranty.

For More Information

For more information on Cisco Small Business products and solutions, visit:

http://www.cisco.com/smallbusiness.

Data Sheet

Printed in USA C78-502486-00 11/08
