Citizen AN3371-54E Bedienungsanleitung

Thank you for your purchase of this Citizen watch.

Before using the watch, please read this instruction manual carefully to

ensure correct use.

After reading the manual, store it in a safe place for future reference.

■Before using the watch

This instruction manual explains the usage of calibers 051*, 051C, 0540 and

0560. Conﬁrm your watch’s caliber No. following the instruction below.

To check the movement number

A case number is engraved on the case back.

(Figure on the right)

The first 4 digits of the case number represent

the movement number of the watch.

In the example on the right, “1234” is the

movement number.

Engraving position example

1234-567890

The engraving position may differ

depending on watch model.

CONTENTS

■Before using the watch ..............1

■Main components

Caliber 051* ..................................3

Caliber 051C .................................4

Caliber 0540..................................5

Caliber 0560..................................6

■Setting the watch

Caliber 051*/051C.........................7

Caliber 0540..................................8

Caliber 0560..................................9

■Setting the date

Caliber 051*/051C/0540/0560.....10

■Chronograph operation

Caliber 051* ................................11

Caliber 051C ...............................12

Caliber 0540................................13

Caliber 0560................................14

■Adjusting the chronograph

Caliber 051*/051C/0540..............16

Caliber 0560................................18

■Precautions ...............................20

■Maintenance .............................26

■Battery handling ......................27

■Information ...............................28

■Tachymeter ................................29

■Speciﬁcations ...........................30

■Main Components

Chronograph

second hand

051*

Chronograph minute

hand

Crown

Hour hand

Chronograph hour

hand

Small second hand

Minute hand

Button B

Button A

Chronograph

second hand

051C

Chronograph minute

hand

Crown

Hour hand

Chronograph hour

hand

Small second hand

Minute hand

Button B

Button A

Chronograph

second hand

0540

Chronograph minute

hand

Crown

Hour hand

Small second hand

Minute hand

Button B

Button A

24 hour hand

The Chronograph 1/20 second hand functions as one step movement to conﬁrm

normal watch operation when the chronograph is not being used.

When stopped, this hand can be re-started by pressing button A.

Chronograph

second hand

0560

Chronograph minute

hand

Crown

Hour hand

Chronograph hour

hand

Chronograph 1/20

second hand

Minute hand

Button B

Button A

1. Pull the crown out to position (2) to stop the small second hand at “0” sec.

2. Turn the crown to set the minute/hour hands to the desired time.

* The date changes at 12:00 AM each day. Pay attention to AM and PM when

setting the time.

3. Push the crown in to position (0) to start the hands again.

* To stop the movement and reduce the power consumption, pull the crown

out to position (2).

■Setting the watch

051*

Crown

Hour hand

Small second hand

Minute hand

051C

1. Pull the crown out to position (2) to stop the small second hand at “0” sec.

2. Turn the crown to set the minute/hour hands to the desired time.

* The 24-hour hand is synchronized with the hour hand.

Use the 24-hour time display as a reference to conﬁrm a.m. and p.m. setting.

3. Push the crown in to position (0) to start the hands again.

* To stop the movement and reduce the power consumption, pull the crown

out to position (2).

0540

Crown

Hour hand

Small second hand

Minute hand

24-hour hand

1. Pull the crown out to position (2).

2. Turn the crown to set the minute/hour hands to the desired time.

* The date changes at 12:00 AM each day. Pay attention to AM and PM when

setting the time.

3. Push the crown in to position (0) to start the hands again.

* To stop the movement and reduce the power consumption, pull the crown

out to position (2).

0560

Crown

Hour hand

Minute hand

1. Pull out the crown to position (1).

2. Turn the crown until the desired date appears.

* Do not set the date between 9:00PM and 1:00AM. Otherwise, the date may

not change properly.

3. Push the crown back to position (0) after setting the date.

■Setting the date

051*

Crown

0540 0560

Crown

The current date is indicated

here.

051C
